Explanation of specialist terms:
Climb and descent ("collective pitch / throttle"):
This controls the model's climb and descent.
Yaw:
The model's movement around the vertical axis; the
helicopter rotates to right or left.
Pitch axis:
The model's movement around the lateral axis,
forward or reverse flight
Roll:
The model's movement around the longitudinal axis,
sideways movement to right or left
Mode 1:
Function assignment of control movements relative
to the sticks.
In this case collective pitch / motor speed (throttle)
and roll are controlled by the right-hand stick; pitch-
axis and tail rotor by the left-hand stick.
Mode 2:
Function assignment of control movements relative
to the sticks.
In this case collective pitch / motor speed (throttle)
and tail rotor are controlled by the left-hand stick;
pitch-axis and roll by the right-hand stick.
Dual Rate:
Switchable travel reduction for control movements.
Binding:
Creating the radio link between transmitter and
receiver.
Operating Instructions, BLUE ARROW 1.0 3D RTF 2.4 GHz No. S2523
Contents
Explanation of specialist terms / Contents
Safety Notes
Set contents / Specification / Recommended accessories
Transmitter description Mode 1
Transmitter description Mode 2
Transmitter LCD screen / Transmitter settings /
Collective pitch / throttle settings
Motor connections / Flybarless check
Charging the battery / LiPo battery safety notes
Pre-flight preparations
Trim adjustments in Mode 1 / Mode 2
Controlling the model
Important advice / The first few flights
Exploded drawing
Replacement parts
Page No.
3
4, 5
6
7
8
9
10
11
12, 13
14
15
16
17
18, 19
3
