ROBBE blue arrow 1.0 3D Operating Instructions Manual page 7

Transmitter description* (Mode 1) - The mode select switch** is located on the back of the transmitter
(*Complete operating instructions for the J6 transmitter can be found in the Download area at www.robbe.com)
Aerial
Battery display
Hover throttle setting
3D switch SW (B)
Throttle off switch SW (A)
Pitch-axis trim
Stick
Pitch-axis / tail rotor
Tail rotor trim
Mode button
END button
LCD screen
Operating Instructions, BLUE ARROW 1.0 3D RTF 2.4 GHz No. S2523
Neckstrap lug
Operating display
Gyro gain
switch
Trainer
switch
Servo travel reduction
Stick
Collective pitch / motor speed
and roll
On / Off switch
Push-button
Level select
Adjustment
** After
changing mode
you must switch
the transmitter off
and then on again,
in order to activate
the new mode.
Throttle trim
Roll trim
7
