- Page 1 USER MANUAL MODEL 1110ARC Asynchronous, RS-232 Fiber Optic Rack Card Modem Part #07M1110ARC-A Doc #018022U, Rev. B Revised 1/23/08 An ISO-9001 Certified Company SALES OFFICE (301) 975-1000 TECHNICAL SUPPORT (301) 975-1007 http:www.patton.com...
-
Page 2: Radio And Tv Interference
The Model 1110ARC has been tested and found to comply with the limits for a Class A computing device in accordance... - Page 3 NOTE: Packages received without an RMA number will not be accepted. Patton Electronics' technical staff is also available to answer any questions that might arise concerning the installation or use of your Model 1110ARC. Technical Service hours: 8AM to 5PM EST, Monday through Friday.
-
Page 4: General Information
“Controlled by RTS”. Four pairs of bi-level LED indicators monitor TD, RD, RTS and CD. A single LED monitors power. The Model 1110ARC is designed to mount in Patton’s 2U high 19” rack chassis. This 16-card chassis has a switchable 120/240 volt power supply and mounts cards in a mid-plane architecture: The front “brains”... - Page 5 Figure 1. Model 1110ARC front card jumper locations JP1 and JP2: RTS/CTS Delay The combined settings for jumpers JP1 and JP2 determine the amount of delay between the time the Model 1110ARC “sees” RTS and when it sends CTS. JP3: Carrier Detect The settings for jumper JP3 determines whether carrier detect is enabled or disabled.
- Page 6 3.2 REAR CARD SETTINGS The Model 1110ARC is compatible with two dual-fiber interface cards, one with dual ST connectors and one with dual SMA connectors. Both cards use an HD-26 female for the RS-232 interface. The jumpers on both interface cards function identically. Figure 2 (below) shows the location of the jumpers.
- Page 7 DTE Shield (Pin 1) & FRGND (JB1) In the connected (closed) position, this strap links DB-25 pin 1 and frame ground. In the open (disconnected) position, pin 1 is “lifted” from frame ground. Position 1&2 = DTE Shield (Pin 1) and FRGND connected Position 2&3 = DTE Shield (Pin 1) and FRGND not connected...
-
Page 8: Installation
This section describes the functions of the Model 1000R16 rack chassis, tells how to install front and rear Model 1110ARC cards into the chassis, and provides instructions for connecting the interface cables. 4.1 THE MODEL 1000R16 RACK CHASSIS The 1000R16 Rack Chassis (Figure 4, below) has sixteen short range modem card slots, plus its own power supply. - Page 9 4.2 INSTALLING THE MODEL 1110ARC INTO THE CHASSIS The Model 1110ARC is comprised of a front card and a rear card. The two cards meet inside the rack chassis and plug into each other via mating 50 pin card edge connectors. Use the following steps as a...
-
Page 10: Fiber Connections
4.3.1 RS-232 CONNECTION The RS-232 port on the rear card of the Model 1110ARC is wired as a DCE, and uses a female HD-26 connector. The HD-26 is an alternate connector according to the EIA RS-232E specification, and the pin-out is the same as a standard DB-25. Pin 26 is not used. -
Page 11: Operation
The green “RTS” and “CD” indicators glow solid to show the control signal is on. The red “RTS” and “CD” indicators glow solid to show the control signal is off. When the 1110ARC is connected to a DTE, RTS will glow green for an incoming signal on RS-232 pin 4. - Page 12 PATTON MODEL 111OARC SPECIFICATIONS Transmission Line: Transmission Mode: Interfaces: Data Rates: Distance: RTS/CTS Delay: Receiver Sensitivity: Coupled Power Output: -20 to -25 dBm Optic Wavelength: LED Indicators: Connectors: Temperature Range: Altitude: Humidity: Weight: Dimensions: APPENDIX A Dual optical cable Asynchronous, half or full duplex, point-to- point EIA RS-232, CCITT V.24 0 - 19.2 Kbps...
- Page 13 PATTON MODEL 1110ARC FACTORY REPLACEMENT PARTS The Patton Model 1110ARC rack system features interchangeable rear half cards, power cords/fuses for international various operating environments and other user-replaceable parts. Model numbers and descriptions for these parts are listed below: Patton Model # 1000RPEM...120/240V Rear Power Entry Module...
- Page 14 APPENDIX C PATTON MODEL 1110ARC PIN CONFIGURATIONS UNIVERSAL D-26 INTERFACE (DCE WIRING) 8- (CD) Carrier Detect Data Terminal Ready - (20) 7- (SG) Signal Ground 6- (DSR) Data Set Ready 5- (CTS) Clear to Send 4- (RTS) Request to Send...
- Page 15 APPENDIX C PATTON MODEL 1110ARC BLOCK DIAGRAM Copyright © 1998 Patton Electronics Company All Rights Reserved...
