242Z
AVI322 / 321 / 311
Network Camera Series
Quick Guide
All lead-free products offered by the company comply with the requirements of the
European law on the Restriction of Hazardous Substances (RoHS) directive, which
means our manufacture processes and products are strictly "lead-free" and without the
hazardous substances cited in the directive.
The crossed-out wheeled bin mark symbolizes that within the European Union the
product must be collected separately at the product end-of-life. This applies to your
product and any peripherals marked with this symbol. Do not dispose of these products
as unsorted municipal waste. Contact your local dealer for procedures for recycling this
equipment.
Please read instructions thoroughly before operation and retain it for future reference.
For the actual display & operation, please refer to your product in hand.
AVI322, 321, 311 quick_V1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avtech AVI322
Summary of Contents for Avtech AVI322
- Page 1 242Z AVI322 / 321 / 311 Network Camera Series Quick Guide All lead-free products offered by the company comply with the requirements of the European law on the Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly “lead-free” and without the hazardous substances cited in the directive.
-
Page 2: Package Contents
PACKAGE CONTENTS 1. PACKAGE CONTENTS AVI322 / 321 ‧ ◎ In the camera package: □ Speed dome camera □ User Manual □ CD-ROM disc (including user manuals & CMS software “Video Viewer”) ◎ In the bracket package (Optional) : Wall mounting screws x 4 Wall plugs x 4 □... -
Page 3: Installation And Setup
INSTALLATION & SETUP 2. INSTALLATION & SETUP 2.1 CONNECTOR OVERVIEW CONNECTOR DESCRIPTION Power Connector Connect the DC 12V adapter for power supply. Video Output Connector Connect to the video input connector of your monitor with a video cable (i.e. a RCA line with the BNC connector, or a coaxial line) for video output. - Page 4 INSTALLATION & SETUP 2.2 Install the Hardware (For AVI322 / 321) Before installation, you need the following items before installation: Bracket & mounting base (supplied with the bracket sales package) ‧ The accessory packages supplied with the bracket sales package, including: ‧...
- Page 5 INSTALLATION & SETUP 2.3 Install the Hardware (For AVI311) Before installation, you need the following items before installation: The accessory package which includes: ‧ (1) Wall mounting screws (2) Wall plugs (3) Decoration covers Power Drill or screwdriver ‧ STEP 1: Mount the camera to the ceiling. Attach the camera to the ceiling, and fasten the camera with the supplied 3 screws.
- Page 6 STEP 3: Connect the power, video, audio, RJ11, RJ45 connectors. Please refer to Step 4 in “2.2 Install the Hardware (For AVI322 / 321)”. 2.4 Log In and Access the Camera Step 1.
- Page 7 INSTALLATION & SETUP ‧ Search the available IP address to login Double-click “ ” icon on your PC desktop to enter the Video Viewer control panel. By defaults, the “Address Book” ( ) panel will be displayed on the right side of the Video Viewer control panel. Click ”...
-
Page 8: Video Viewer Basic Operation
VIDEO VIEWER BASIC OPERATION 3. VIDEO VIEWER BASIC OPERATION 3.1 The Live View Page After setting up the network information, login user name and password, double-click “ ” on the PC desktop to open and log into the Video Viewer control panel. You will see a screen similar to the following with 6 major sections: ‧... -
Page 9: Address Book
VIDEO VIEWER BASIC OPERATION 3.2 Address Book This view is displayed when the Video Viewer is activated for you to log in / out the network camera from the current address list, or search the available IP address as follows: Address Book Search Click to view the pre-defined network camera access details. -
Page 10: Manual Record
VIDEO VIEWER BASIC OPERATION Click to search and view the available IP address(es) for the network connection. You can choose one address to add into the address book, edit the details, or update the address list. Button Function Description Select from the available IP address list, and click this button. Key in the Add into network camera access information needed, and click “Apply”... - Page 11 VIDEO VIEWER BASIC OPERATION 3.4 Playback To play a recording, click “ ” (Miscellaneous Control) → “ ” (Status List), and select the “Record” tab. A list of all the recordings will be shown by defaults, and you can also sort out the logs you want to speed up the search time.
