Paradyne MIM-4E1 Installation Instructions Manual

Micro interface module

Advertisement

Quick Links

MIM-4E1
Installation Instructions
Document Number MIM4-A2-GZ42-00
June 2005
Contents

Software and Firmware License Agreement

The terms and conditions of this License Agreement (the "Agreement") will apply
to the software and/or firmware (individually or collectively the "Software")
incorporated into the Paradyne product (the "Product") purchased by you and any
derivatives obtained from the Software, including any copy of either. If you have
executed a separate written agreement covering the Software supplied to you
under this purchase, such separate written agreement shall govern.
Paradyne Corporation ("Paradyne") grants to you, and you ("Licensee") agree to
accept a personal, non-transferable, non-exclusive, right (without the right to
MIM4-A2-GZ42-00
....................................................................................... 3
.................................................................................... 4
............................................................................................. 5
............................................................................................ 5
................................................................................................... 7
............................................................................................ 7
ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS
TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED
INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU
SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.
IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS
LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS
ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE
LOCATION WHERE YOU OBTAINED THE PARADYNE PRODUCT OR THE
LOCATION FROM WHICH IT WAS SHIPPED TO YOU, AS APPLICABLE, AND YOU
WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT
PURCHASED BY YOU.
June 2005
...................................................... 1
......................................................... 3
.............................................................................. 6
........................................... 8
.......................................................................... 8
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIM-4E1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Paradyne MIM-4E1

  • Page 1: Software And Firmware License Agreement

    MIM-4E1 Installation Instructions Document Number MIM4-A2-GZ42-00 June 2005 Contents Software and Firmware License Agreement Unpacking and Inspecting the Equipment Installing the MIM-4E1 Connecting the E1 Lines E1 RJ48C Pinouts E1 Default Settings E1 Parameter Configuration LED Indicators Regulatory Notices Warranty, Sales, Service, and Training Information...
  • Page 2: June

    sublicense) to use the Software, solely as it is intended and solely as incorporated in the Product purchased from Paradyne or its authorized distributor or reseller under the following terms and conditions: 1. Ownership: The Software is the sole property of Paradyne and/or its licensors. The Licensee acquires no title, right or interest in the Software other than the license granted under this Agreement.
  • Page 3: Unpacking And Inspecting The Equipment

    If you are not sure of the proper static control precautions, contact your nearest sales or service representative. If there is any visible damage, do not attempt to install the MIM-4E1; contact your sales representative. Installing the MIM-4E1 The MIM-4E1 Micro Interface Module provides additional uplink ports for the 4929 DSLAM or BSX8000-5 Broadband Services Switch.
  • Page 4: Connecting The E1 Lines

    RJ48C connectors. — Snap shut the ferrite choke. 2. Plug your E1 cables into the E1 RJ48C ports on the MIM-4E1 faceplate; the order of connection is not important. 3. Verify all connections: the Port 1 and Port 2 Lnk LEDs on the MIM-4E1 faceplate will flash green to indicate the connections are established and operational.
  • Page 5: E1 Rj48C Pinouts

    Position the choke as close as possible to the RJ48C connector. — Snap shut the ferrite choke. 2. Plug your E1 cable into one of the E1 RJ48C ports on the MIM-4E1. Any port may be used. 3. Verify the connection: the E1 link LED on the front of the MIM will flash green to indicate the connection is established and operational.
  • Page 6: E1 Parameter Configuration

    Paradyne products meet the European minimum ones density requirement internally such that loss of synchronization is prevented between the MIM-4E1 and remote E1 equipment with AMI just as it is with HDB3. June 2005 MIM4-A2-GZ42-00...
  • Page 7: Led Indicators

    LED Indicators Table 1. LEDs STATE Lnk/Alm Flashing Green* (Port 1 – Port 4) Solid Green No Illumination Solid Amber Pulsing Amber Flashing Green (Port 1 – Port 4) Flashing Amber A pulsing LED blinks steadily at a rate of once per second. A flashing LED blinks at a more rapid, less constant rate.
  • Page 8: Warranty, Sales, Service, And Training Information

    Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. EUROPEAN REGULATORY COMPLIANCE The following regulatory compliance information applies to the MIM-4E1 as installed in the 4929 DSLAM or BSX8000-5 Broadband Services Switch: This Class A product complies with European Norm EN55022.
