2. BitStorm 1900 Installation and Testing
2-74
Step Procedure
4.) Set the serial COM1 port terminal communication settings.
a.) Initiate a Terminal Session using terminal emulation software
(i.e., Hyperterminal).
b.) Select the appropriate serial
menu (i.e., COM1, COM2, etc).
c.) Verify the port settings are the same as shown in Figure 2-19,
"COM Port Settings." and click
BitStorm 1900 Installation and Maintenance Guide
COM

Figure 2-19: COM Port Settings

(continued)
port from the pull down
O K .
1900-A2-GN20-00
