260 W AC Power Card Specifications
Description
Card Dimensions
LEDs
Input
Cord
Operating
Temperature
Short-term Operat-
ing Temperature
Certifications
AC Supply Fuse
Fan Tray
1900-A2-GN20-00

Figure 1-8: 260 W AC Power Card (Part #: 01-00079-01)

Specification
12" x 2.27" x 11.75"
12V DC, 5 V DC, 3.3V DC,-5 V DC
85 – 265 V AC, 47 – 63 Hz
IEC 320, (6')
5 o C to 40 o C (41 o F to 104 o F)
o o o
-5 C to 50 C (23 F to 122
FCC Part 15, Class A, UL 60950, cUL,
NEBS level 3, CE, ETSI ETS 300 386-2
3 AMP – 250 V AC
An AC fan tray is required
BitStorm 1900 Installation and Maintenance Guide
(3A, 250V AC)
o
F)
1. BitStorm 1900 IP DSLAM
ON/OFF
FUSE
02-17169
1-25
