REPAIR AND MAINTENANCE
Front Wheel Replacement
Tools required: Phillips screwdriver and 15 mm wrench
1
Remove the nuts on both sides
of the front axle using a 15 mm
wrench then remove the axle safety
washers (note hardware sequence).

Replacing the Fuse

Tools required: Phillips screwdriver
Turn power switch OFF.
1
Lift up the seat and loosen
the four (4) screws in the storage
compartment and remove the tray.
Need Help? Visit our web site for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer Service
contact information is listed at the back of this manual.
2
Insert the wheel into the front
fork with the lock washers on the
outside of the fork.
2
Locate fuse box on top of
battery. Open the fuse cover to
expose the fuse.
3
Insert the tab on the lock
washer into the hole on the front
fork and tighten the nuts using two
(2) 15 mm wrenches.
30 Amp
3
Remove the fuse and replace
with a new one of equal amperage.
Close the fuse box. Reattach seat/
storage compartment.
10
WARNING:
To prevent shock, please follow the
instructions accordingly and do not
skip or combine any steps.
