Page 1: Service Manual
LCD Television Service Manual Chassis： MT5303C Product Type： LEDN24K15PUK、LEDN32K15UK、 LEDN42K15PUK..Hisense Electric Co.，Ltd. September，2010... -
Page 2: Table Of Contents
5.5 Troubleshooting for TV/VGA/HDMI input..................- 26 - 5.6 Troubleshooting for YPbPr input......................- 27 - 5.7 Troubleshooting for Video/S-Video input.....................- 28 - 6. Explode View and Explode Bom List......................- 29 - 7. Schematic circuit diagram ..........................- 29 - Hisense Confidential - 2 -... -
Page 3: Service Manual
USE OF NON-AUTHORIZED PARTS WILL VOID THE MANUFACTURE'S WARRANTY Proper service and repair is important to the safe, reliable operation of all Hisense Electric Co., Ltd Equipment. The service procedures recommended by Hisense and described in this Service Guide are effective methods of performing service operations. -
Page 4: Warning
LCD TV Service Manual techician trained in the proper Television safety and service methods and procedures Hereafter throughout this manual, Hisense Electric Co., Ltd will be referred to as Hisense. 1.1 Warning 1.1.1 Critical components having special safety characteristics are identified with a by the Ref. - Page 5 > All cables and connectors are properly insulated and do not have any bare wires/lead exposed. 1.1.6 (1) Do not supply a voltage higher than that specified to this product. This may damage the product and may cause a fire. Hisense Confidential - 5 -...
- Page 6 (9) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Hisense Confidential - 6 -...
-
Page 7: Notes
Failure to observe this precaution may result in, the surface of the panel being scratched by foreign Hisense Confidential - 7 -... - Page 8 The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the set. Hisense Confidential - 8 -...
-
Page 9: Product Function Specifications
LCD TV Service Manual 2. Product Function Specifications Product Function Specifications Hisense Confidential - 9 -... -
Page 10: Factory/Service Osd Menu And Adjustment
White Balance White Balance Col Temp standard Set Channel R Grain Auto Color G Grain Factory Option B Grain LOGO Option R Offest Pattern Test G Offest Clean Protected B Offest Clean All Version information Hisense Confidential - 10 -... - Page 11 SOURCE HuangDao TOFAC Hungary France Australia Pattern Test Version Test pattern NULL Version: Panel Type: FLASH : Clean Protected Clean All Clean the user data(keep (Clean the factory data- the factory data ) EEPROM data) Hisense Confidential - 11 -...
- Page 12 Cool 120Hz Warm 500 Hz 1 .5KHz 5KHz 10KHz Picture Mode Brightness Standard Soft Note ： The above “Factory/Service OSD Menu” are reference only, please refer to the ac tual units to determine the appearances. Hisense Confidential - 12 -...
-
Page 13: Software Upgrading
Select the default value, the driver will be installed step by step. 4.1.2 Hardware connecting Connect the unit to your pc with a USB-to-serial port cable. USB port connects to your pc, and serial port to the TV’s RS232 port. Hisense Confidential - 13 -... - Page 14 Serial connector: to the main board of For the first connecting, the pc will recognize and automatically install the USB device. The process is just like the installation of a mini disk, see the following picture. Hisense Confidential - 14 -...
-
Page 15: Upgrading With The Mtktool
The MtkTool using log is restored in the MtkLog folder. It records the running time and date whenever the tool is used. The log will be a txt file named by the date and time. Hisense Confidential - 15 -... - Page 16 3—Press the icon beside the baud rate and make sure it is green as the below picture. 4—Set the flash baud rate to 115200 as the below picture. 5—Click the browse button to select the *.bin file that will be updated. 6—Click the “start” button to update software. Hisense Confidential - 16 -...
- Page 17 Open “Device Manager” and find which port is connected with the TV. In above picture, COM4 is connected to the TV; so, select “COM4” in the MtkTool main interface. Select the right baud rate according to chip model. For this unit( chip model is MT536X), select 115200.*8。“Auto Set Flash Hisense Confidential - 17 -...
- Page 18 If the flash chip does not support high speed transport, do not select this option; otherwise, reserve the selected mood. MT536X Click “Browse” button, find the upgrading program file, and select it. Press “Upgrade” button and start upgrading. The following interface appears on the screen, indicating upgrading successfully. Hisense Confidential - 18 -...
- Page 19 LCD TV Service Manual MT536X Hisense Confidential - 19 -...
-
Page 20: Upgrading With The Usb
LCD TV Service Manual 4.3 Upgrading with the USB MT5303C Series can update with USB directly, the Main software should named his_upgrade.pkg。Turn on the TV then Insert the USB . The following appear: Choose “YES”on the screen and press the ‘OK’button on the remote control, Starting upgrade About 40 seconds. - Page 21 If software upgrading defeated, First turn off the TV.insert the USB and restart the TV. It can automatic upgrade. nothing on the screen ,The indicator led is red. When upgrading is successful ,the indicator led turns blue. The system auto start up. Hisense Confidential - 21 -...
-
Page 22: Troubleshooting
Try new batteries Replace battery Replace RC Replace remote control Check IR receiver Change Led & IR board Replace Led & IR BD Change Led & IR cable Replace Led & IR cable Replace main board Hisense Confidential - 22 -... -
Page 23: Troubleshooting For Function Key
5.2 Troubleshooting for Function Key Buttons does not work Check solder connections and Check switches see if any switches are stuck. Replace Key BD Check key board Check Key BD cable Change Key BD Replace main board Hisense Confidential - 23 -... -
Page 24: Tv Won't Power On
Try Power on by Check signal RC and Button Panel Bright Source Neither Both works Work Replace Main Replace Main BD Power on Replace Panel (to contact Hisense tech support.) Replace Power BD Hisense Confidential - 24 -... -
Page 25: Troubleshooting For Audio
LCD TV Service Manual 5.4 Troubleshooting for Audio No sound Reconnect Check connecter Replace speaker wire Check speaker wire Replace speaker set Check speaker set Replace main board Power Supply Board Hisense Confidential - 25 -... -
Page 26: Troubleshooting For Tv/Vga/Hdmi Input
LCD TV Service Manual 5.5 Troubleshooting for TV/VGA/HDMI input No picture on the screen Check Signal Source Make sure signal source is available Reconnect Check connect Check cable Replace cable Replace main board Hisense Confidential - 26 -... -
Page 27: Troubleshooting For Ypbpr Input
LCD TV Service Manual 5.6 Troubleshooting for YPbPr input No picture on the screen Check Source work or not Check Source Device Reconnect Check connect Check Wires (Green Blue, Red) Replace wires Replace main board Hisense Confidential - 27 -... -
Page 28: Troubleshooting For Video/S-Video Input
LCD TV Service Manual 5.7 Troubleshooting for Video/S-Video input No picture on the screen Check Source work or not Check Signal Source Reconnect Check connect Replace Cable/Wires Check Cable/ Wires Replace main board Hisense Confidential - 28 -... -
Page 29: Explode View And Explode Bom List
LCD TV Service Manual 6. Explode View and Explode Bom List 7. Schematic circuit diagram Hisense Confidential - 29 -... - Page 30 AVDD33_AADC AVDD33_ADAC0 Output Path 1 3,4,5,6,7,8,9,11,12,13,14 AVDD33_AADC AVDD33_ADAC0 VIMD_AADC AVDD33_ADAC1 VMID_AADC AVDD33_ADAC1 ADCOUTL AL2O Near IC Near IC AIN_L_AADC AL2_ADAC +3V3SB AV33 ADCOUTR AR2O 3,5,6,7,8,14 +3V3SB AV33 AIN_R_AADC AR2_ADAC REFP_AADC AL1O Head Phone 3,7,8,9,11,13 AV33 AVDD33_REFP AL1_ADAC AVDD33_ADAC0 AR1O VIMD_AADC AVDD33_AADC AR1_ADAC ADAC_VCM...
