Summary of Contents for Hisense M3000
- Page 1 Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English Deutsch Español Italiano Português Français ES-A154921-1...
- Page 2 Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English...
- Page 3 Declaration of Conformity (DoC) This TV is CE marked and complies with EU directives. The complete declaration of conformity is included in this manual, and can also be downloaded from the Hisense homepage. Hisense declares that this TV is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EG.
- Page 4 Important Safety Instructions ▌Safety Instructions To ensure safe and correct use of this product, always comply with the following precautions to avoid dangerous situations and damage to your unit: The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of...
- Page 5 Important Safety Instructions „ Moving/Transportation „ Power plug and power cable Before moving this TV, disconnect all - Do not touch the power plug with wet cables and move in the vertical position hands. only. Grasp the device on the upper and - Do not place heavy objects on the lower edges of the frame.
- Page 6 Important Safety Instructions „ Air ventilation and high 20cm temperatures 10cm 10cm 10cm Install your TV only where there is proper ventilation, and ensure that there is at least 10 cm free space on the sides and 20 cm above the unit for air circulation. Excessive heat and obstruction of ventilation could lead to fire or early failure of some electric components.
- Page 7 Important Safety Instructions „ Radio waves „ Supervision - Do not let children play unsupervised - Do not use the TV in any medical close to the TV. It could tip over, be institutions or locations with medical pushed off or pulled down from the equipment.
- Page 8 Important Safety Instructions „ Modification „ Cleaning and care Do not attempt to modify this product CAUTION: in any way. Unauthorized modification Unplug the power cord prior to could void the warranty of this unit, cause cleaning the TV. electric shock and fires. Clean the TV, the screen, and the remote „...
-
Page 9: Table Of Contents
Contents Product image is only for reference, actual product may vary in appearance. Parts of the software function changes with the system upgrade. Contents Accessories List......................1 Installing the Stand ......................2 TV Front..........................3 TV Rear ..........................4 Making Connections .......................5 Remote Control ......................11 Turning the TV on for the First Time ................13 Specifications .......................14 Other Information......................16... -
Page 10: Installing The Stand
Installing the Stand Installing the Stand CAUTION Be sure to disconnect the A/C power cord before installing a stand or Wall-Mount brackets. The LED display is very fragile, and must be protected at all times when installing the base stand. Be sure that no hard or sharp object, or anything that could scratch or damage the LED display, comes into contact with it. -
Page 11: Tv Front
TV Front TV Front CH + MENU VOL + VOL - Source CH - Power Remote sensor / Power Switch I/O Power indicator Item Description Receives remote signals from the remote control. Remote sensor Do not put anything near the sensor, as its function may be affected. -
Page 12: Tv Rear
TV Rear TV Rear COMMON INTERFACE ANT 1 ANT 2 HDMI 3(4K@60Hz) HDMI 4(4K@60Hz) DIGITAL AUDIO OUT AV IN VIDEO SCART COMPONENT IN SERVICE NOTES HEADPHONE ANT2 Jack supports power supply for satellite antenna (13/18V, 0.5A max.) Check the jacks for position and type before making any HDMI connections. -
Page 13: Making Connections
Making Connections Wired setup LAN ( Connect your TV to your network by connecting the LAN port on the back of your TV to an external modem or router using a LAN (Ethernet/Cat 5) cable. See the illustration below. · We recommend to use a modem or router that supports Dynamic Host Configuration Protocol (DHCP). - Page 14 Making Connections Connect an MHL cable (not provided) from your MHL-enabled device, HDMI 1(MHL) such as a cell phone. TV JACK Phone HDMI 1(4K@30Hz) MHL cable (not included) MHL (DC 5V 900mA) Connect an HDMI cable from an external digital audio system. HDMI 2(ARC) ARC enables the TV to directly output the digital sound through an HDMI cable.
- Page 15 Making Connections Connect an outdoor VHF/UHF antenna or cable. Outdoor Antenna TV JACK Cable ANT OUT ANT 1 DVB-T/T2/C Antenna Cable (75Ω) (not included) VHF/UHF Antenna Connecting a satellite antenna. TV JACK ANT 2 DVB-S/S2 (not included) HEADPHONE Connect Headphone for audio out of the TV. TV JACK HEADPHONE Headphone (not included)
- Page 16 Making Connections Connect the USB devices such as hard drives, USB sticks and digital cameras for browsing photos, listening music and watching recorded movies. You can use Timeshift and record (refer to “PVR/Timeshift”). At the same time update is also an easy thing and will be done just by plugging the USB with the updating files into the same interface.
- Page 17 Making Connections COMMON INTERFACE Insert the CI+ module for watching scrambled services like pay-tv channels or some HD channels. TV JACK CAM CARD SMART CARD NOTES Before you insert/remove the CI+ module, ensure that the TV is switched off. Then insert the CI card into the CI+ module in accordance with the Service Provider’s instructions.
- Page 18 Making Connections Connect a component cable and an audio cable from an external COMPONENT IN A/V Device. The component output ports Y, P and P on the VCD or DVD can sometimes be identified as Y, C and C TV JACK VCR/DVD Player/Recorder/ Set-top box/Satellite Receiver/ Video Camera...
-
Page 19: Remote Control
Remote Control POWER: Switch the TV on or into standby mode INPUT: Select input sources C h a n n e l N u m b e r : D i r e c t c h a n n e l selection or numbers input EPG: Display the Electronic Program Guide (DTV mode) - Page 20 Remote Control Installing Batteries in the Remote Control 1. Slide the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment.
-
Page 21: Turning The Tv On For The First Time
Turning the TV on for the First Time Turning the TV on for the First Time 1. Connect the mains cable to the mains socket after you have completed all the connections. 2. The first time you turn the TV on, it will go straight into the Installation Guide. It will assist you to specify the Language, Location, Network. -
Page 22: Specifications
Specifications Features, appearance and specifications are subject to change without notice. Model Name 43" Width: 38.1 inches (969 mm) Without Stand Height: 22.1 inches (563 mm) Depth: 3.4 inches (87 mm) Dimension Width: 38.1 inches (969 mm) With Stand Height: 23.9 inches (607 mm) Depth: 7.6 inches (192 mm) Without Stand 22 lbs (10 kg) - Page 23 Specifications Features, appearance and specifications are subject to change without notice. Model Name 49" Width: 43.5 inches (1106 mm) Without Stand Height: 25.3 inches (642 mm) Depth: 3.3 inches (84 mm) Dimension Width: 43.5 inches (1106 mm) With Stand Height: 27.4 inches (695 mm) Depth: 9.7 inches (246 mm) Without Stand 28 lbs (12.7 kg)
-
Page 24: Other Information
Other Information Recycling/Licenses WEEE (Waste Electronic Electric Equipment) European Directive 2012/19/EU This symbol on the product or on its packaging indicates that this product must not be disposed of with your household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
