- Page 1 LCD COLOR TV USER MANUAL English LCD1504US Part No IES050610...
-
Page 2: Table Of Contents
Please read all the safety and operating instructions carefully before you begin. CONTENTS Important safety instructions ..................Brief Product Overview . -
Page 3: Important Safety Instructions
CAUTION CAUTION: TO REDUCE THE RISK OF ELEC- TRIC SHOCK, DO NOT REMOVE COVER(OR BACK).NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE WITH THE FCC RULES COULD VOID THE USERS AUTHORITY TO OPERATE THIS EQUIPMENT. - Page 4 Important safety instructions 12. USE ONLY WITH CART, STAND, TRIPOD, BRACKET, OR TABLE SPECIFIED BY THE MANUFACTURER, OR SOLD WITH THE APPARATUS. WHEN A CART IS USED, USE CAUTION WHEN MOVING THE CART/APPARATUS COMBINATION TO AVOID INJURY FROM TIP-OVER. Do not place this TV on an unstable cart, stand, tripod, bracket ,or table. The TV may fall, causing serious injury to someone, and serious damage to the appliance.
-
Page 5: Brief Product Overview
Brief Product Overview 1.Connection Connect the antenna lead or CATV cable or external equipment (such as Antenna, Cable TV, VCD, DVD, VCR, Set top box, etc.) to the corresponding terminals or interface on the TV rear (please refer to the owner s manual of the equipment to be connected as well) and confirm that the signal source is available and works normally. -
Page 6: Signal Source Selection
3.Switching on/off 1)Connect the TV to power outlet. If the power indicator is red, it means the TV is off now. You need topress the POWER button on the TV or the POWER button on the remote control to turn on the TV, and the power indicator will light up in blue. -
Page 7: Learning About Your New Tv
Learning about your new TV Learning about your new TV You can operate your TV by using the buttons on the front panel or the remote control. The terminals on the side and the rear panel provide all the connections you will need to connect other equipment to your TV. Side Controls / Connections Rear Connections Note: The above figures are for reference only, please refer to the actual connection jacks to determine their appearance. -
Page 8: Selecting A Location For The Tv
TV. Wall Mounting your TV The LCD1504US is a VESA compliant LCD TV which means that it can be wall mounted using a standard VESA compliant mounting bracket. VESA compliant mounting brackets are available at your local electronics store. -
Page 9: Connecting The Pc Or Notebook
Connecting your TV NOTE: 1) Headphones are not included. 2) No sound will be heard from the main unit speakers when a headphone mini-plug is connected into the headphone jack. Connecting to a Personal Computer or Notebook You can use your TV as a monitor for Connect the devices as shown below. -
Page 10: Connecting To A Cable Converter Box
Preparation for Using your new TV Connecting to a cable converter box This television has an extended tuning range and can tune into most cable channels without using a cable company supplied converter box. Some cable companies offer premium pay channels in which the signal is scrambled. -
Page 11: Using The Remote Control
Using the remote control Preparing the remote control for use Installing the remote control batteries 1. Open the battery cover on the back of the remote control. 2. Insert two AAA size(1.5V) batteries (included). Match the + and - signs on the batteries to the signs inside the battery compartment. -
Page 12: Shortcut Keys Operation
Shortcut keys operation Connecting POWER Note: Use only a manufacturer approved AC plug. If you are having any issues connecting the AC plug to the TV and / or wall outlet, call our customer service line toll-free at 1800-287-4871 for help. ON/OFF Standby Press POWER on the remote control to turn off the LCD TV, the POWER indicator will turn red. -
Page 13: Switching Between Two Channels
Shortcut keys operation Adjusting volume Press VOL- or VOL+ on the remote control or Muting the sound Press the MUTE on the remote control to temporarily turn off the sound. To restore the sound, press MUTE again. The mute function is automatically turned off when any of the following buttons are pressed: POWER, VOL+. -
Page 14: Selecting The Picture Mode
Shortcut keys operation Selecting the picture mode You can select the picture mode instantly from among three preset modes and one user-set mode. Press the P.MODE button on the remote control repeatedly to select the desired picture mode. Selecting the sound mode You can select a sound effect from among three preset modes and one user-set mode. -
Page 15: Menu Operation
Menu operation Using the Picture Parameters menu Adjust picture settings 1) Press the MENU button to enter the main menu. 2) Press the button to select the item Picture Parameters, and press the button to enter Picture Parameters 3) Press the button to select the item you want to adjust. -
Page 16: Using The The Geometry Menu
Menu operation Using the Geometry menu Geometry 1) Press the MENU button to enter the main menu. 2) Press the button to select the item Geometry, and press the 3)Press the button to select the item you want to adjust. 4)Press the button to change the value. - Page 17 Menu operation OSD Language: Press the CC Mode: Press the button to switch among the different Closed Captioning options CC1~4, T1~4 and Off. MTS : Press the button to switch among Stereo, SAP and Mono audio modes. Reset Menu : Press the button to switch between On and Off.and if the item is switched to On ,The Option menu will appear when you turn on the TV the next time.
- Page 18 Menu operation About TV PG Rating: The TV ratings are divided into two groups: age-based and content-based. Defined as TV-Y All children TV-Y7 Directed to older children TV-G General audience TV-PG Parental Guidance suggested Parents Strongly cautioned TV-14 Mature Audience only TV-MA About Canadian English Rating...
-
Page 19: Using The Search Menu
Menu operation Using the Search menu TV Reception Mode You can set tv source as aerial or cable antenna input. 1) Press the MENU button to enter the main menu. 2) Press the button to select the item Search, and press button to enter Search menu. -
Page 20: Appendix
Appendix Cleaning and care WARNING: TV sets use high voltage. Do not try to remove the back cabinet yourself. There are no user serviceable parts inside. Note that opening the cabinet could void your warranty. Refer servicing to qualified service technicians. To clean the TV screen: 1) Unplug the TV to avoid possible shock hazard. -
Page 21: Troubleshooting
Appendix Troubleshooting Before calling a service technician, please check the following table for a possible cause of the problem and some solutions. Problem TV will not turn on No picture, no sound No sound, picture OK Poor sound, picture OK Poor picture, sound OK Poor reception of broadcast channels Multiple images... -
Page 22: Specifications
12 lbs Supplied accessories Remote control, AC adapter,AC cord, Batteries Design and specifications are subject to change without notice. CUSTOMER NOTICE:Operate carefully to prevent damage to the screen. LCD1504US UHF: 14-69 Cable TV: 2~13,A~W, W+1~W+84,A-5~A-1, 4A Cable/ antenna 75 VHF/UHF input VIDEO 75 1.0Vp-p input... -
Page 23: Limited Warranty
HISENSE HOME ENTERTAINMENT WARRANTY We appreciate your purchase of a HISENSE Home Entertainment product. We take pride in the quality of our products and have manufactured your new Home Entertainment unit to exacting quality standards. We feel confident that in normal use, it will provide you with satisfactory performance.
