Quick Install Guide
5-Port Mini Fast Ethernet Switch
Use the XVS-F5 to:
Use the XVS-F5 to:
Extend Your Home or Offi ce Network
„
Deliver Fast Ethernet Connectivity at the Network Edge
„
Set-up a Dedicated Network for Optimizing VoIP, Video,
„
Security, or Gaming Applications (when used with a
managed switch)
Simply Connected
XVS-F5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XVS-F5 and is the answer not in the manual?

Questions and answers

Related Manuals for Luxul XVS-F5

Summary of Contents for Luxul XVS-F5

  • Page 1 Simply Connected Quick Install Guide XVS-F5 5-Port Mini Fast Ethernet Switch Use the XVS-F5 to: Use the XVS-F5 to: Extend Your Home or Offi ce Network „ Deliver Fast Ethernet Connectivity at the Network Edge „ Set-up a Dedicated Network for Optimizing VoIP, Video, „...

  • Page 2: Document Conventions

    No part of this publication may be modified or adapted in any way, for any purposes without permission in writing from Luxul. The mate- rial in this manual is subject to change without notice. Luxul reserves the right to make changes to any product to improve reliability, func- tion, or design.

  • Page 3: Fcc Compliance

    HARDWARE DESCRIPTION Front Panel The front panel of the XVS-F5 includes 5 Link/Activity LEDs, one power LED, four PoE Status LEDs and one PoE Max LED. Please refer to the detailed description of these indicators in Section 2.2 below.

  • Page 4: Led Indicators

    LED, four PoE Status LEDs and one PoE Max LED. These LED indicators show the operating status of the XVS-F5 and each switch connection. The following chart shows the LED indicators of the XVS-F5 along with an explanation of the indicator’ s properties: Color...

  • Page 5: Rear Panel Layout

    Green 100Mbp device connected — 10Mbp device connected Rear Panel Layout The Rear Panel of the XVS-F5 includes eight 10/100Mbps RJ-45 Ethernet ports. XVS-F5 Rear Panel View CAUTION: Please use the included power supply. If a different power supply is used, it could damage the XVS-F5 ©...

  • Page 6: Preparing For Installation

    „ devices Power should be AC 100-240V~ 1.4A(Max) 50/60Hz. „ Installation Requirements Install the XVS-F5 in a stable/safe place to avoid any possible „ damage Inspect the AC power cord to ensure that it is correctly connected „ and undamaged To avoid electric shock, DO NOT open the XVS-F5 housing (no „...

  • Page 7: Connecting Devices

    Simply Connected Power socket should be within 4 feet of the XVS-F5 . „ Check power adapter to confirm safe and secure connection. „ XVS-F5 INSTALLATION Connecting Devices Use standard Ethernet CAT5, CAT5e or CAT6 cable to connect the XVS-F5 to a device as described below. The XVS-F5 will automati- cally adjust to the characteristics (speed/duplex) of the device to which it is connected.

  • Page 8: Fcc Statement

    „ Consult the dealer or an experienced radio/TV technician for help. Hereby, Luxul, 14203 Minuteman Drive, Suite 201, Draper, Utah, 84020, declares that this Luxul XVS-F5 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
