To get optimum performance of your "P-3000C" Drum Pedal,
Traction Plate
Multi Function
Drum Key
Traction Dot
Duo-Deck
Footboard
Hinge
Heel Plate
Short Footboard
PEARL DRUM PEDAL
P-3000C
Instruction Manual
Congratulations on your purchase!
please read this Instruction Manual before playing.
Key Bolt
(for Beater Stroke
Included Items
Oil, Velcro Tape (x3), Allen Wrench (3mm, 2.5mm)
Control Core Beater
Beater Setting Stopper
Adjustment)
Hoop Clamp
Bottom Plate
Beater Holder Link
Key Bolt (for Beater
Position Adjustment)
Key Bolt
(for Footboard Angle
Adjustment)
Uni-Lock Footboard
Angle Cam
Adjustment Knob
Upper Nut
Lower Nut
Click Lock
Wing Bolt
Long Footboard
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pearl P-3000C
Summary of Contents for Pearl P-3000C
- Page 1 PEARL DRUM PEDAL P-3000C Instruction Manual Congratulations on your purchase! To get optimum performance of your "P-3000C" Drum Pedal, please read this Instruction Manual before playing. Control Core Beater Beater Setting Stopper Beater Holder Link Key Bolt (for Beater Position Adjustment)
- Page 2 Beater Stroke Adjustment Insert the Control Core Beater into the Beater Holder Link The P-3000C Demon Chain Pedal features Pearl's patented until it stops against the Beater Setting Stopper, and tighten two-position Beater Holder that can be positioned closer or the Key Bolt with the provided Multi Function Drum Key farther from the drum head for Finesse "A"...
- Page 3 Duo-Deck Footboard Note P-3000C features Pearl's patented Duo-Deck If the Beater is too far from the Bass Footboard, the world's first convertible Short / Long Drum Head, the Footboard can Footboard. touch the Hoop Clamp and cause damage to the Footboard and/or the Hoop Clamp.
- Page 4 Reattach the Hinge to the Footboard in the position shown with two 3-Piece Screws using the provided Multi-Function The P-3000C Demon Chain Pedal features Pearl's patented Drum Key or Allen wrench (3mm) (Fig.11). Click Lock spring tension retention system. To increase the...
- Page 5 Multi-Function Drum Key or Allen wrenches as needed. Velcro Strips for Slip Prevention Velcro Strips are provided with the P-3000C pedal to help prevent slipping when used on carpeted floors. To apply, peel off the backing on the Velcro Strips and apply them in the locations shown.
