ICP *9MPT050F12 Installation Instruction page 13

For "Concentric Termination Kit" Venting table, see
"Section 11" in this manual.
Vent Termination Clearances
WARNING
!
CARBON MONOXIDE
HAZARD.
Failure to properly vent this furnace could result in
death, personal injury and/or property damage.
Inlet and outlet pipes may NOT be vented directly
above each other.
440 01 2021 01
POISONING AND FIRE
1. Determine termination locations based on clearances spe-
cified in following steps and as shown in Figure 7, Figure 8,
Figure 20, through Figure 27.
For "Concentric Termination Kit" clearances, see Figure 30,
Figure 31, Figure 32, Figure 33 and Figure 34 in "Section 10"
in this manual.
2. This furnace is Dual Certified and can be installed as a
single pipe appliance (all combustion from inside the struc-
ture) or as a direct vent appliance where all combustion air is
taken from outside the structure.
3. For Single Pipe installation refer to Figure 8 for vent ter-
mination clearances.
4. For Direct Vent installation, refer to Figure 7 for vent ter-
mination.
13
