4.2.3 Backrest frames

Modulite is available with different backrest frames.
Standard backrest tube*
Backrest height
48 cm
Tube diameter
22 mm
* used with one-piece seat plate only.
Installation follows the same defined order of steps for all backrests.

4.2.4 Armrest styles

Modulite seat is available with different armrest styles.
T-Armrest
Function
T-armrest
Flip-up Armrest
Following Armrest
Padded Armrest
Inrigged armrest
Armpad styles
All Modulite armrests are available with the following armpads, except for padded armrest.
8
Flex 3 backrest plates
Push bar for backrest posts
with push handles
22 mm
Flip-up Following
Available armrest bracket length
Regular or higher (+5 cm) for use with a thick seating cushion
one size
one size
one size
one size
Flex 3 Tension Adjustable
Backrest post with push
handles
48 cm / 54 cm
25 mm
Padded
Matrx
Backrest post without push
handles
48 cm / 54 cm
25 mm
Inrigged
