DEALER: Keep this manual.
The procedures in this manual MUST be performed by a qualified
technician.
Invacare® TDX® SP2 Series
en Power Wheelchair
Service Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDX SP2 and is the answer not in the manual?

Questions and answers

John
March 25, 2025

power elevating footrests block removal of dead batteries

0
1 comments:
Mr. Anderson
May 14, 2025

To remove the power elevating footrests on an Invacare TDX SP2 to access dead batteries:

1. Remove the side-mounted legrests if fitted.
2. If a centrally-fitted, manually adjustable legrest is present, turn the spindle to move it to the top position.
3. Remove the thumbscrews securing the front shroud/battery retention bracket to the wheelchair.
4. Lift up to unhook and remove the front shroud/battery retention bracket from the wheelchair.

This provides access to the batteries.

This answer is automatically generated

0
