- Page 1 OPERATION MANUAL JENCO MODEL 6230M/6230N/6231M/6231N MICROCOMPUTER BASED pH/mV/TEMP PORTABLE METER JENCO ELECTRONICS, LTD. MANUFACTURER OF PRECISION INSTRUMENTS...
- Page 2 6231M 6231N Storage RS-232C NOTES: 1. RS-232C interface operation is for 6230M and 6230N only. 2.The saving, recalling and erasing data functions are for 6230M and 6231M only. 3. RECALL mode and ERASE mode are for 6230M and 6231M only..
-
Page 3: Initial Inspection
GENERAL INTRODUCTION The model 6230M, 6230N, 6231M or 6231N is a precise instrument for the measurement of pH, mV, and temperature. A built-in microcomputer is used to store, calculate, and compensate for all the relevant parameters relating to pH determinations. -
Page 4: Splash Proof
Other features include, low power consumption, percentage of power supply display, electrode offset recognition, electrode slope recognition, built-in buffer coefficients, automatic or manual temperature compensation, auto-saving pH calibration values, and high 50/60 Hz AC noise rejection. This meter is USER FRIENDLY, for field, industrial and laboratory applications. -
Page 5: Changing The Batteries
CHANGING THE BATTERIES When the LOBAT indicator is flashing, the user should check that whether the external AC adaptor is connected to the meter reliably, and if only internal batteries is used, the user should change the batteries. If the voltage of power supply is too low, the meter will display “Sht”... - Page 6 THE KEYPAD ( See Notes 2 and 3 1. ON/OFF key: The ON/OFF key turns the unit ON or OFF. The pH calibration values will not be erased when the unit is turned off. 2. MODE key: 2.1. During normal operation, the MODE key will change the display mode sequentially to pH-AUTOLOCK, mV-AUTOLOCK, pH, mV, RECALL and ERASE.
- Page 7 MEASURE and ▽ keys: Pressing and holding this combination during ERASE mode for about 5 seconds will erase ALL data saved in the non-volatile memory. All 40 sites will be erased completely. Do not use this function until all recorded data has been reviewed or transcribed or downloaded.
-
Page 8: Modes Of The Meter
MODES OF THE METER ( See Notes 2 and 3 1. pH-AUTOLOCK mode: The meter will display pH and temperature with both pH and AUTOLOCK on. WAIT flashes until the unit detects a stable reading. 2. mV-AUTOLOCK mode: The meter will display mV and temperature with both mV and AUTOLOCK on. -
Page 9: Operational Procedures
OPERATIONAL PROCEDURES Before operation, you should turn on the unit. BUFFER TABLE SELECTION This unit has two buffer sets: 4.01,7.00, 10.01pH and 4.00,6.86, 9.18pH. To change the buffer set, turn off the unit, then press and hold the STAND key while turning on the unit again. - Page 10 1.5 Press the SLOPE key to calibrate. The SLOPE annunciator will stop flashing and stay on. And the WAIT annunciator flashes until the unit detects a stable reading. When a stable reading is reached, the WAIT annunciator will stop flashing and stay off. This means that the second point has been calibrated.
- Page 11 You can press the MODE key to exit for one point pH calibration. The pH annunciator will stop flashing and be on, and the meter is ready for measurements with STAND on but SLOPE off. If dual or three points calibration is needed, go to 2.4.
-
Page 12: Temperature Measurements
immerse them in the sample to be measured. 1.4 Press the MEASURE key. The WAIT annunciator will flash until the unit determines a stable pH reading. When WAIT stops flashing and stays off, the reading is locked. NOTE: If no ATC/Temp probe is connected, the MAN will be on, adjust the ) to that of the sample using the △... - Page 13 measured. 1.4 Press the MEASURE key. The WAIT annunciator will flash until the unit determines a stable mV reading. When WAIT stops flashing and stays off, the reading is locked. 1.5 The ATC/Temp probe can be used to measure the sample temperature as required.
-
Page 14: Connector Cable
Jenco meter and to receive back the specific data sampled at the time intervals you specify in your custom written program. -
Page 15: Error Indications
A demo program and the protocol are included in the accompanying CD. Using the demo, you can easily track or recall data from the Jenco meter. Please read the protocol to understand more about the procedure in detail. You may also choose to ®... - Page 16 Temperature is out of the –10.0 to 120℃ range. OuE/Und Temperature measurement Failed to check or write EEPROM. pH BUFFERS The temperature characteristics of pH calibration buffers 4.00, 4.01, 6.86, 7.00, 9.18 and 10.01 are stored inside the instrument. The buffers used to calibrate the instrument must exhibit the same temperature characteristics as the stored values.
-
Page 17: Specifications
If you purchased the item from our Jenco distributors and it is under warranty, please contact them to notify us of the situation. Jenco Service Department alone will determine if the product problem is due to deviations or customer misuse. -
Page 18: Return Of Items
For your protection, items must be carefully packed to prevent damage in shipment and insured against possible damage or loss. Jenco will not be responsible for damage resulting from careless or insufficient packing. A fee will be charged on all unauthorized returns. - Page 19 英文使用说明书 Manual in English 机型 编制人 豆林奇 编制日期 6230M/6230N/6231M/6231N 2003/12/11 文件编号 修改人 杨启娜 修改日期 K6230M/6230N/6231M/6231N-01 2010-2-25 版本号 核准人 杨健寿 核准日期 2010-2-25 2010-2-25（V02）：修改美国和中国的 EMAIL 地址。...
