Technaxx HD TX-24 User Manual

Hide thumbs Also See for HD TX-24:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
indoor and outdoor usage HD TX-24
www.technaxx.de/ (in bottom bar "Konformitätserklärung")
Important Hint regarding the User Manuals:
All languages of the user manual (english, german, french, spanish,
italian, netherlands, polish) you find on the CD-ROM enclosed.
The english and german version of the user manual you also find as
Contents
Before using the device the first time, read the user manual carefully.
1.
2.
Software Installation and Commissioning; Hardware Requirements
3.
3.1.
3.2.
3.3.
4.
(Learn basic function to view and video in LAN and WLAN)
4.1.
4.2.
4.3.
4.4.
4.5.
5.
6.
6.1.
Technaxx
IP-Security Camera for

User Manual

The Declaration of Conformity for this device is under:
printed version enclosed.
®

Advertisement

Table of Contents
loading

Related Manuals for Technaxx HD TX-24

Summary of Contents for Technaxx HD TX-24

  • Page 1: Table Of Contents

    ® Technaxx IP–Security Camera for indoor and outdoor usage HD TX-24 User Manual The Declaration of Conformity for this device is under: www.technaxx.de/ (in bottom bar “Konformitätserklärung”) Important Hint regarding the User Manuals: All languages of the user manual (english, german, french, spanish, italian, netherlands, polish) you find on the CD-ROM enclosed.
  • Page 2 6.1.8. Change the device alias 6.1.9. Dial connection (PPPOE) 6.1.10. Set time zone 6.1.11. Restore the default settings 6.2. Camera settings in WAN Mode 6.2.1. Groups 6.2.2. Change Access password 6.2.3. Change the camera alias 6.2.4. MicroSD card query 6.2.5. Relationship between SYSM MONITOR, p2pCamViewer (MAC), p2pCamViewer Settings on the Main Menu 7.1.

  • Page 3: Features & Product Description & Additonal Clamp Connections

    Supports MicroSD memory card up to 32GB Video compress format: H.264 720p Multi Stream Supports 802.11.b/g/n wireless protocol Additional clamp connections to connect external alarm devices IP-Security Camera for indoor and outdoor usage HD TX-24 IR–LED Power line Lens Audio out IR–Sensor...
  • Page 4 ALARM IP CAMERA SENSOR NC (Normally Closed) NO (Normally Open) 2. Software Installation and Commissioning Windows Requirements: WIN 7, WIN 8, Windows XP, Windows Vista Hardware Requirements 1GB RAM and 2 Core CPU for 1 camera at 1 time 2GB RAM and i3 or updated processor for 4 cameras at 1 time REMARKS: No matter how many cameras you’d like to connect, this software has no requirement for GPU (Graphic Processing Unit) CAUTION: This manual is for SYSM Monitor V8.D.12.08, the software is improving,...
  • Page 5 Insert the software CD into the PC drive (or download the software on www.scc21.net): Opening the CD and start program "SYSM Monitor.exe" Continue click “Next“ until following steps were finished. After installation finished, click below icon “SYSM Monitor” to run the software as shown.

  • Page 6: Hardware

    3. Hardware 3.1. Package Contents: IP-Security Camera for indoor and outdoor usage HD TX-24, Power Supply, Network cable, Antenna and red cap for the antenna, Bracket and screws, Installation-CD with user manuals in 7 languages, User Manual (english and german version) 3.2.

  • Page 7: Getting Started

    4. Getting Started (learn basic function to view and video in LAN and WLAN) 4.1. Video from a camera in the local network (LAN) Make sure the camera was plugged in adaptor and connected with router via LAN cable first. Run SYSM monitor and click “LAN” on the right list area, then right-click the blank area, a menu pops out similar to Figure, select "Refresh"...

  • Page 8: Set Wifi Connection

    4.2. Set WIFI connection (a) Right mouse click then see the device Then select “Set WIFI connection” menu popped out. (b) Set SSID (Wireless router name) / Password (1) Enable “Start WiFi setting”. (2) Click “Scan” to choose the WIFI connection “Network name [SSID]” (it is your Wireless router name).

  • Page 9: View The Camera On The Internet (Wlan)

    4.3. View the camera on the Internet (WLAN) Click "Login" in the area of the main list on the right, input "User Name" and "password" and click "Login" button. The user name and password is on the label of the camera. The User name is: Cam ID/User, and the Password is: Login password 4.4.
  • Page 10 (2) Login in via the new account. (3) Right click on the blank area, select “Add device” on the pop up window and input camera alias / Camera ID /Access password (it is on the label of the camera).
  • Page 11 (4) Double click the camera name to view video...

  • Page 12: Main Menu

    4.5. Main Menu Settings Play back Fullscreen Device Management Change password Help Full screen: View video in full screen. Settings: Set System, Video, Local alarm, Alerts, Net. (a) System: Programme Language, option, Notifications, Update...
  • Page 13 (b) Video: Set the folder of video recording and take picture / alarm view time (c) Local alarm alerts: Set local alarm record time / capture time / alarm music.
  • Page 14 (d) Net: Usually this is for development to test. Don’t change anything. Device management: Add device / change password /set permission...
  • Page 15 Add other camera to this account. This account will get the management authority. Change the device management Password. Change the device access code (watch password). Change device name.
  • Page 16 Select network server, usually use “Auto”. Restart the device remotely. Set permission. Playback: Playback video on computer.
  • Page 17 Change password: Change login password. Log: Check system log. Help: Software question and answer.

  • Page 18: Video Surveillance (Control Panel)

    5. Video Surveillance (Control Panel) CAUTION: some function is only for special camera! Cruise (ON/OFF): Set cruise on, the camera will auto move rotate. Optical zoom: control camera optical zoom +/-, only for the camera has optical zoom lens. Digital Zoom: software support 4x digital zoom Aperture switch: set camera aperture big or small Capture: snap picture Record: Record video on computer...
  • Page 19 Set alarm sensitivity and set area (press left button and move to set area) Horizontal pan (ON/OFF): set camera auto rotate horizontally (10) Vertical tilt (ON/OFF0: set camera auto rotate vertically (11) Go to pre-set position: call the camera preset (1-8) (12) Set preset position: set camera preset.(1-8) (13)

  • Page 20: General System Settings

    (17) Alarm log: The camera alarm log (18) Setting: Set device properties General System Settings Run the SYSM monitor, all the cameras will display in the LAN 6.1. Camera Settings in LAN Mode device list, double click camera name to view the camera video.

  • Page 21: Set The Ip Address

    6.1.1. Set the IP address The default setting is camera use DHCP. Camera auto gets IP address from network router. It is a easy way for normal customer who do not know how to set IP address manually. 6.1.2. Set WIFI connection (refer to 4.2. WIFI connection) 6.1.3.

  • Page 22: Microsd Card Configuration

    6.1.4. MicroSD card configuration Turn off the camera, then insert the MicroSD card and turn on the camera, after boot up. First format the MicroSD card. It also does not support hot swapping.

  • Page 23: Microsd File Download

    The camera auto records video to the MicroSD card when there is motion alarm. The camera auto records video to the MicroSD card when the camera external sensor gets alarm. The camera auto continue records after the camera boots up. The camera auto coverage the old video file when the MicroSD card is full.

  • Page 25: Alarm Alerts (Email)

    6.1.6. Alarm alerts (Email) First enable the camera motion alarm function before setting the alarm alerts by Email. Fill in the blanks of the pop-up window, click “OK”. The device will automatically take photos and sent them to the email you set. (For example: the SMTP port for Gmail is 587;...

  • Page 26: Groups

    6.1.7. Groups (1) Create a Group: Right click the camera ID and select “Create a group”. Enter a name for the group in the pop-up interface. (2) Delete a Group: Right click the group name and click "Delete group" to display the pop-up box.

  • Page 27: Camera Settings In Wan Mode

    6.1.11. Restore default setting Right click the camera ID and select “Restore the default setting”, as shown: REMARKS: Login password, watch password, and the parameters of the device like camera system, language, video parameter, will be restored to the factory setting. All those settings previously saved will be lost.

  • Page 28: Change Access Password

    (2) Delete a Group: Right click the group name and click "Delete group" to display the pop-up box. (3) Add the camera to the appropriate group: Select the camera ID, hold down the left button to drag the camera to the group, and then release the left mouse button. 6.2.2.

  • Page 29: Relationship Between Sysm Monitor, P2Pcamviewer (Mac), P2Pcamviewer

    6.2.5. Relationship between SYSM MONITOR, p2pCamViewer (MAC), p2pCam Viewer There are different kind of software can be used in our IP camera: (1) SYSM MONITOR: for Windows PC users (2) p2pCamViewer (MAC): for MAC computer users (3) p2pCamViewer: for smart phone users like Android, iPhone. Users can use different software above to see video from one IP camera.

  • Page 30: Settings On The Main Menu

    (4) QR-Code: Except for logging in with the ID number and password on the sticker, users can also login automatically by scanning the QR-Code on the sticker. After clicking the "Scan QR Code" on the Smart Phone the scanning of the ID number and password starts automatically.

  • Page 31: System

    7.2.1. System User can do the setting for “When closing main window”, “Exit software”, “Notification”, “3D option”, “System Upgrade” and “Set program languages” by this page. Remind to use “3D option” and “Set program languages to” will only be activated after restart the software.

  • Page 32: Local Alarm Alerts

    7.2.3. Local Alarm Alerts Before setting the Local Alarm Alerts, complete the setting on motion detection area. To learn about the setting of motion detection area, refer to No. 5. “Video Surveillance“ (8) Motion detection area”. Click “Settings”, and choose “Local Alarm Alerts”...

  • Page 33: Change Management Password

    REMARK: Default management password and watch password equal to the device login password and Access code on the QR code label. IMPORTANT: Default Manager (User) for the camera is Cam ID / User on the camera label. Manager position will be changed to other user if other user clicking in the "Device management"...

  • Page 34: Change Watch Password

    7.3.3. Change watch password Input the new watch password (Equal to the Access code in QR code label) and set the watch permission, watch password will replace Access code on QR code label. 7.3.4. Change camera alias Set a friendly name easy to Remember for the camera.

  • Page 35: Permissions Setting

    7.3.7. Permissions Setting This camera is private and protected, to limit the activity for registered user. Management assign different permission level different user. To set permission for different user, follow the steps below. Add permission: Input the user name and search, then select the user name and set permission levels.
  • Page 36 Change permission: Select the user name and click “Change Permission”, then select the level by “No right”, “Allow watch”, “Allow watch and record” and “Allow watch, record and operate”. No right: Users are not allowed to watch the live video unless they know the watch password.

  • Page 37: Search

    7.4. Search According to recording time of the query video recordings on the local computer, double-click the video file to playback. NOTE: Video playback support for pause, slow down, fast forward, drag the progress bar and other operations. 7.5. Change password (User login password) When login successfully, you can click "Change Password"...

  • Page 38: Video Delay

    FAQ (Frequently Asked Questions) 8.1. Video delay There are three factors which will cause video delay: upload speed, PC download speed, and image resolution. If the issue happens on the PC client, generally, you can click “Settings” as below to adjust the resolution to QVGA (320 x 240). If it also does not work, please check the other two factors.

  • Page 39: Can Visit The Ip Camera In Lan, But Cannot View It On Wlan

    8.4. Can visit the IP camera in LAN, but cannot view it on WLAN When camera can be viewed on LAN, but cannot be viewed via WLAN, usually because the device gets wrong IP address. Try to set DHCP for the device 8.5.

  • Page 40: Restore To Default Settings

    725g ( with cable) / (L) 26 x (W) 7 x (H) 16cm Distributor (Inverkehrbringer): Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany Hints for Environment Protection: Packages materials are raw materials and can be recycled. Do not disposal old devices into the domestic waste.
