■ Required Connections
[DC POWER INPUT TERMINAL]
TX - RX ANT
V HF or UHF TX•RX
antenna required.
9
INSTALLATION AND CONNECTIONS 2
Make sure the back up battery is correctly
connected. Use a cable with following
current capacity. Solder or clamp the cable
plug when connecting the power cable to
the backup battery to prevent voltage drops.
Power cable current capacity: 25 A or more
VHF RX - RX ANT
VHF or UHF TX•RX
antenna required.
GROUND
