Parrot MULTICAN User Manual page 11

Chrysler
A - CAN :
CoNfigurAtioN
Parrot
• Connect the green wire corresponding to CAN High to pin 5.
• Connect the white wire corresponding to CAN Low to pin 6.
Mercedes
A - CAN :
CoNfigurAtioN
Parrot
• Connect the green wire corresponding to CAN High to pin 11.
• Connect the white wire corresponding to CAN Low to pin 9.
Can High
Can Low
K-bus
Can High
Can Low
K-bus
C
hrysler CoNNeCtor
1
BMW
2
m
erCédes CoNNeCtor
11
6 5
Mer
PSA
