Page 2: Revision
Products made or sold by Juniper Networks or components thereof might be covered by one or more of the following patents that are owned by or licensed to Juniper Networks: U.S. Patent Nos. 5,473,599, 5,905,725, 5,909,440, 6,192,051, 6,333,650, 6,359,479, 6,406,312, 6,429,706, 6,459,579, 6,493,347, 6,538,518, 6,538,899, 6,552,918, 6,567,902, 6,578,186, and 6,590,785.
Page 3 Juniper, even if such feature, function, service, application, operation, or capability is enabled without a key; (g) distribute any key for the Software provided by Juniper to any third party; (h) use the...
Page 4 Customer did not originally purchase from Juniper or an authorized Juniper reseller; (k) disclose the results of testing or benchmarking of the Software to any third party without the prior written consent of Juniper; or (l) use the Software in any manner other than as expressly provided herein.
Page 5 (or services are accessed by) the Software shall be a third party beneficiary with respect to this Agreement, and such licensor or vendor shall have the right to enforce this Agreement in its own name as if it were Juniper. In addition, certain third party software may be provided with the Software and is subject to the accompanying license(s), if any, of its respective owner(s).
Page 7: Table Of Contents
SRX5600 Services Gateway Chassis ........
Page 8 SRX5600 Services Gateway Routing Engine Boot Sequence ... . 28 SRX5600 Services Gateway Craft Interface ......28 SRX5600 Services Gateway Craft Interface Overview .
Page 9 Connections ........... . 71 Grounding the SRX5600 Services Gateway ......72 Connecting Power to an AC-Powered SRX5600 Services Gateway .
Page 10 SRX5600 Services Gateway Card Terminology ..... . . 99 Holding an SRX5600 Services Gateway Card ......100 Storing an SRX5600 Services Gateway Card .
Page 11 Replacing the SRX5600 Services Gateway Console or Auxiliary Cable ..132 Replacing SRX5600 Services Gateway IOCs ......133 Removing an SRX5600 Services Gateway IOC .
Page 12 DC Power Electrical Safety Guidelines and Warnings ....194 SRX5600 Services Gateway Agency Approvals ......199 SRX5600 Services Gateway Compliance Statements for EMC Requirements .
Page 13 Signal Loss in Multimode and Single-Mode Fiber-Optic Cable for the SRX5600 Services Gateway ........221 Attenuation and Dispersion in Fiber-Optic Cable for the SRX5600 Services Gateway .
Page 14 Gateway Hardware ..........243 Return Procedure for the SRX5600 Services Gateway ....243 Locating SRX5600 Services Gateway Component Serial Numbers .
Page 15 SRX5600 Services Gateway ........
Page 17: About This Guide
Audience This guide is designed for network administrators who are installing and maintaining a Juniper Networks SRX5600 services gateway or preparing a site for services gateway installation. To use this guide, you need a broad understanding of networks in general and the Internet in particular, networking principles, and network configuration.
Page 18 SRX5600 Services Gateway Hardware Guide Table 1: Notice Icons Icon Meaning Description Informational note Indicates important features or instructions. Caution Indicates a situation that might result in loss of data or hardware damage. Warning Alerts you to the risk of personal injury or death.
Page 19: Srx Series Documentation And Release Notes
SRX Series Release Notes differs from the information in the documentation, follow the SRX Series Release Notes. Obtaining Documentation To obtain the most current version of all Juniper Networks technical documentation, see the products documentation page on the Juniper Networks Web site at http://www.juniper.net/...
Page 20: Documentation Feedback
7 days a week, 365 days a year. Self-Help Online Tools and Resources For quick and easy problem resolution, Juniper Networks has designed an online self-service portal called the Customer Support Center (CSC) that provides you with the following features: Find CSC offerings: http://www.juniper.net/customers/support/...
Page 21 About This Guide Join and participate in the Juniper Networks Community Forum: http://www.juniper.net/company/communities/ Open a case online in the CSC Case Manager: http://www.juniper.net/cm/ To verify service entitlement by product serial number, use our Serial Number Entitlement (SNE) Tool located at https://tools.juniper.net/SerialNumberEntitlementSearch/...
Page 23: Srx5600 Services Gateway Overview
PART 1 SRX5600 Services Gateway Overview Introduction to the SRX5600 Services Gateway on page 3 SRX5600 Services Gateway Hardware Components on page 7 Copyright © 2010, Juniper Networks, Inc.
Page 25: Introduction To The Srx5600 Services Gateway
The SRX5600 services gateway is a high-performance, highly-scalable, carrier-class security device with multi-processor architecture. The SRX5600 services gateway is eight rack units (RU) tall. Three of these devices can be stacked in a single floor-to-ceiling rack, for increased port density per unit of floor space.
Page 26: Srx5600 Services Gateway Physical Specifications
SRX5600 Services Gateway Component Redundancy on page 5 Documentation SRX5600 Services Gateway Chassis on page 7 SRX5600 Services Gateway Host Subsystem Description on page 22 SRX5600 Services Gateway Craft Interface Overview on page 28 SRX5600 Services Gateway Power System Overview on page 33 SRX5600 Services Gateway Cooling System Description on page 37 Copyright ©...
Page 27: Srx5600 Services Gateway Component Redundancy
Related SRX5600 Services Gateway Chassis on page 7 Documentation SRX5600 Services Gateway Switch Control Board Description on page 22 SRX5600 Services Gateway Power System Overview on page 33 SRX5600 Services Gateway Cooling System Description on page 37 Copyright © 2010, Juniper Networks, Inc.
Page 29: Srx5600 Services Gateway Hardware Components
(48-U) rack if the rack can handle their combined weight, which can be greater than 818 lb (371.0 kg). See “SRX5600 Services Gateway Physical Specifications” on page 4 for physical specifications for the SRX5600 Services Gateway.
Page 30 SRX5600 Services Gateway Hardware Guide CAUTION: Before removing or installing components of a services gateway, attach an ESD strap to an ESD point and place the other end of the strap around your bare wrist. Failure to use an ESD strap can result in damage to the services gateway.
Page 31 Chassis Figure 3: Rear View of a Fully Configured DC-Powered Services Gateway Chassis Related Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on Documentation page 171 SRX5600 Services Gateway Physical Specifications on page 4 SRX5600 Services Gateway Power System Overview on page 33...
Page 32: Srx5600 Services Gateway Card Cage And Slots
SRX5600 Services Gateway Hardware Guide SRX5600 Services Gateway Card Cage and Slots on page 10 SRX5600 Services Gateway Cooling System Description on page 37 General Electrical Safety Guidelines and Warnings on page 189 SRX5600 Services Gateway Card Cage and Slots The card cage is the set of eight horizontal slots in the front of the chassis where you install cards.
Page 33: Srx5600 Services Gateway I/O Cards
SRX5600 Services Gateway Card Cage and Slots on page 10 SRX5600 Services Gateway I/O Card Description on page 11 SRX5600 Services Gateway Flex IOC and Port Module Description on page 14 SRX5600 Services Gateway Services Processing Card Description on page 19...
Page 34 Installing an SRX5600 Services Gateway IOC on page 135 Documentation Removing an SRX5600 Services Gateway IOC on page 133 SRX5600 Services Gateway Card Cage and Slots on page 10 SRX5600 Services Gateway Field-Replaceable Units on page 115 SRX5600 Services Gateway I/O Card Components on page 12...
Page 35: Srx5600 Services Gateway I/O Card Leds
Processor subsystem, which includes a 1.2-GHz CPU, system controller, and 1 GB of SDRAM Related SRX5600 Services Gateway I/O Card Description on page 11 Documentation Installing an SRX5600 Services Gateway IOC on page 135 Removing an SRX5600 Services Gateway IOC on page 133...
Page 36: Srx5600 Services Gateway Flex I/O Cards And Port Modules
SRX5600 Services Gateway Flex I/O Cards and Port Modules This section includes the following topics: SRX5600 Services Gateway Flex IOC and Port Module Description on page 14 SRX5600 Services Gateway Flex IOC Components on page 16 SRX5600 Services Gateway Port Module Components on page 17...
Page 37 Chapter 2: SRX5600 Services Gateway Hardware Components NOTE: Your services gateway must be running Junos OS Release 9.5R1 or later in order to recognize Flex IOCs and port modules. Each Flex IOC has a processor subsystem, which includes a 1.2-GHz CPU, a system controller, 1 GB SDRAM, and two Packet Forwarding Engines (PFEs) with a maximum throughput of 10 Gbps each.
Page 38 SRX-IOC-4XGE-XFP 4-Port XFP SRX-IOC-16GE-TX 16-Port RJ-45 SRX-IOC-16GE-SFP 16-Port SFP NOTE: Juniper strongly recommends the use of Juniper SFP and SFP transceivers. Juniper cannot guarantee correct operation if non-Juniper transceivers are used. The transceiver type can be different in each port, as long as a supported part number is used.
Page 39 Documentation Removing an SRX5600 Services Gateway Flex IOC on page 137 Maintaining SPCs, IOCs, and Flex IOCs on the SRX5600 Services Gateway on page 94 Troubleshooting SRX5600 Services Gateway IOCs and Flex IOCs on page 109 SRX5600 Services Gateway Field-Replaceable Units on page 115...
Page 40 Installing an SRX5600 Services Gateway Port Module on page 141 Documentation Removing an SRX5600 Services Gateway Port Module on page 140 Maintaining Port Modules on the SRX5600 Services Gateway on page 96 Troubleshooting SRX5600 Services Gateway Port Modules on page 111 Copyright © 2010, Juniper Networks, Inc.
Page 41: Srx5600 Services Gateway Services Processing Cards
SRX5600 Services Gateway Services Processing Cards This section includes the following topics: SRX5600 Services Gateway Services Processing Card Description on page 19 SRX5600 Services Gateway Services Processing Card Components on page 20 SRX5600 Services Gateway Services Processing Card LEDs on page 20...
Page 42: Srx5600 Services Gateway Services Processing Card Components
SRX5600 Services Gateway Card Cage and Slots on page 10 SRX5600 Services Gateway Field-Replaceable Units on page 115 Maintaining SPCs, IOCs, and Flex IOCs on the SRX5600 Services Gateway on page 94 Troubleshooting SRX5600 Services Gateway SPCs on page 111...
Page 43 Two LEDs, located on the craft interface above the SPC, display the status of the SPC and are labeled FAIL Related SRX5600 Services Gateway Craft Interface IOC and SPC LEDs on page 31 Documentation SRX5600 Services Gateway Services Processing Card Description on page 19 SRX5600 Services Gateway Services Processing Card Components on page 20...
Page 44: Srx5600 Services Gateway Host Subsystem Description
The host subsystem has three LEDs that display its status. The host subsystem LEDs are located in the middle of the craft interface. Related SRX5600 Services Gateway Craft Interface Host Subsystem LEDs on page 30 Documentation SRX5600 Services Gateway Switch Control Board Description on page 22...
Page 45 SRX5600 Services Gateway Switch Control Board LEDs on page 24 SRX5600 Services Gateway Card Cage and Slots on page 10 Maintaining the SRX5600 Services Gateway Host Subsystem and SCBs on page 92 Replacing an SRX5600 Services Gateway SCB on page 126 SRX5600 Services Gateway Switch Control Board Slots You must install at least one SCB in the services gateway as part of a host subsystem.
Page 46 SRX5600 Services Gateway Hardware Guide Related SRX5600 Services Gateway Switch Control Board Description on page 22 Documentation Installing an SRX5600 Services Gateway SCB on page 127 SRX5600 Services Gateway Switch Control Board Slots on page 23 SRX5600 Services Gateway Switch Control Board Components Each SCB consists of the following components: Chassis management Ethernet switch.
Page 47: Srx5600 Services Gateway Routing Engine
Related SRX5600 Services Gateway Switch Control Board Description on page 22 Documentation SRX5600 Services Gateway Craft Interface Host Subsystem LEDs on page 30 SRX5600 Services Gateway Routing Engine This section includes the following topics: SRX5600 Services Gateway Routing Engine Description on page 25...
Page 48 Documentation SRX5600 Services Gateway Routing Engine LEDs on page 27 SRX5600 Services Gateway Routing Engine Interface Ports on page 27 SRX5600 Services Gateway Routing Engine Boot Sequence on page 28 Replacing the SRX5600 Services Gateway Routing Engine on page 129...
Page 49 SRX5600 Services Gateway Routing Engine Components on page 26 Documentation SRX5600 Services Gateway Routing Engine Interface Ports on page 27 SRX5600 Services Gateway Routing Engine Interface Ports In the center of the Routing Engine are three ports that connect the Routing Engine to one or more external devices on which system administrators can issue Junos OS command-line interface (CLI) commands to manage the device.
Page 50: Srx5600 Services Gateway Craft Interface
SRX5600 Services Gateway Craft Interface Host Subsystem LEDs on page 30 SRX5600 Services Gateway Craft Interface Power Supply LEDs on page 30 SRX5600 Services Gateway Craft Interface IOC and SPC LEDs on page 31 SRX5600 Services Gateway Craft Interface Fan LEDs on page 31...
Page 51 SRX5600 Services Gateway Craft Interface Host Subsystem LEDs on page 30 SRX5600 Services Gateway Craft Interface Power Supply LEDs on page 30 SRX5600 Services Gateway Craft Interface IOC and SPC LEDs on page 31 SRX5600 Services Gateway Craft Interface Fan LEDs on page 31...
Page 52 Causes all LEDs on the craft interface to light (for testing) when pressed and held. Related SRX5600 Services Gateway Craft Interface Alarm Relay Contacts on page 32 Documentation SRX5600 Services Gateway Craft Interface Overview on page 28 SRX5600 Services Gateway Craft Interface Host Subsystem LEDs on page 30...
Page 53: Srx5600 Services Gateway Craft Interface Ioc And Spc Leds
Documentation SRX5600 Services Gateway Craft Interface Host Subsystem LEDs on page 30 SRX5600 Services Gateway Craft Interface IOC and SPC LEDs on page 31 SRX5600 Services Gateway Craft Interface IOC and SPC LEDs Each IOC and SPC has LEDs on the craft interface that indicate its status. The IOC and SPC LEDs—labeled...
Page 54: Srx5600 Services Gateway Craft Interface Online Buttons
SRX5600 Services Gateway Craft Interface Online Buttons on page 32 Connecting an SRX5600 Services Gateway to an External Alarm-Reporting Device on page 67 Alarm Relay Contact Wire Specifications for the SRX5600 Services Gateway on page 226 SRX5600 Services Gateway Power System Description This section includes the following topics:...
Page 55: Srx5600 Services Gateway Ac Power Supply Leds
Chapter 2: SRX5600 Services Gateway Hardware Components SRX5600 Services Gateway AC Power Supply LEDs on page 35 SRX5600 Services Gateway DC Power Configurations on page 35 SRX5600 Services Gateway DC Power Supply on page 36 SRX5600 Services Gateway DC Power Supply LEDs on page 37 SRX5600 Services Gateway Power System Overview The services gateway uses either AC or DC power supplies.
Page 56 Documentation SRX5600 Services Gateway AC Power Supply on page 34 SRX5600 Services Gateway AC Power Supply LEDs on page 35 SRX5600 Services Gateway AC Power Supply Each AC power supply weighs approximately 5.0 lb (2.3 kg) and consists of one AC appliance inlet, an AC switch, a fan, and LEDs to monitor the status of the power supply.
Page 57 SRX5600 Services Gateway AC Power Supply LEDs on page 35 Troubleshooting the SRX5600 Services Gateway Power System on page 113 Replacing an SRX5600 Services Gateway AC Power Supply on page 152 SRX5600 Services Gateway AC Power Supply Specifications on page 207...
Page 58 Documentation SRX5600 Services Gateway DC Power Supply on page 36 SRX5600 Services Gateway DC Power Supply LEDs on page 37 SRX5600 Services Gateway DC Power Supply Each DC power supply weighs approximately 3.8 lb (1.7 kg) and consists of one DC input (–48 VDC and return), one 40 A (–48 VDC) circuit breaker, a fan, and LEDs to monitor...
Page 59: Srx5600 Services Gateway Cooling System Description
Chapter 2: SRX5600 Services Gateway Hardware Components Replacing an SRX5600 Services Gateway DC Power Supply on page 154 SRX5600 Services Gateway DC Power Supply Specifications on page 213 SRX5600 Services Gateway DC Power Supply LEDs Each DC power supply faceplate contains three LEDs that indicate the status of the power supply (see Table 21 on page 37).
Page 60 SRX5600 Services Gateway Hardware Guide and Figure 17 on page 39 ). The device has one fan tray and one air filter that install vertically in the rear of the device. The fan tray contains six fans. The air intake to cool the chassis is located on the side of the chassis next to the air filter.
Page 61: Srx5600 Services Gateway Cable Manager Description
Chapter 2: SRX5600 Services Gateway Hardware Components Figure 17: Air Filter Related Maintaining the Fan Tray on the SRX5600 Services Gateway on page 91 Documentation Maintaining the Air Filter on the SRX5600 Services Gateway on page 90 Troubleshooting the SRX5600 Services Gateway Cooling System on page 108...
Page 62 SRX5600 Services Gateway Hardware Guide Figure 18: Cable Manager Figure 19: Cable Management System Installed on the Device Related Replacing the SRX5600 Services Gateway Cable Manager on page 160 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 63: Setting Up The Srx5600 Services Gateway
Gateway SRX5600 Services Gateway Installation on page 43 Preparing the Site for the SRX5600 Services Gateway Installation on page 45 Chapter 5 Unpacking the SRX5600 Services Gateway on page 53 Installing the SRX5600 Services Gateway Mounting Hardware on page 57...
Page 65: Srx5600 Services Gateway Installation
Installing the SRX5600 Services Gateway Using a Mechanical Lift on page 61 Installing the SRX5600 Services Gateway Chassis in the Rack Manually on page 235 Connect cables to the network and external devices.
Page 66 SRX5600 Services Gateway Hardware Guide Connect the AC power cord or DC power cables: Connecting Power to an AC-Powered SRX5600 Services Gateway on page 72 Connecting Power to a DC-Powered SRX5600 Services Gateway on page 75 Power on the services gateway:...
Page 67: Preparing The Site For The Srx5600 Services Gateway Installation
Preparing the Site for the SRX5600 Services Gateway Installation This section includes the following topic: Site Preparation Checklist for the SRX5600 Services Gateway on page 45 SRX5600 Services Gateway Rack Requirements on page 46 SRX5600 Services Gateway Cabinet Requirements on page 50...
Page 68: Srx5600 Services Gateway Rack Requirements
Fiber-Optic Cable for the SRX5600 Services Gateway” on page 223 Related Overview of Installing the SRX5600 Services Gateway on page 43 Documentation Unpacking the SRX5600 Services Gateway on page 53 SRX5600 Services Gateway Rack Requirements The services gateway can be installed in a rack. Many types of racks are acceptable, including four-post (telco) racks and open-frame racks.
Page 69: Srx5600 Services Gateway Rack Size And Strength Requirements
The rack requirements are described in the following topics: SRX5600 Services Gateway Rack Size and Strength Requirements on page 47 Spacing of Rack Mounting Bracket Holes for the SRX5600 Services Gateway on page 48 Connection to Building Structure for the SRX5600 Services Gateway Rack on page 49...
Page 70: Spacing Of Rack Mounting Bracket Holes For The Srx5600 Services
Documentation Site Preparation Checklist for the SRX5600 Services Gateway on page 45 Spacing of Rack Mounting Bracket Holes for the SRX5600 Services Gateway on page 48 Connection to Building Structure for the SRX5600 Services Gateway Rack on page 49 Clearance Requirements for SRX5600 Services Gateway Airflow and Hardware...
Page 71: Rack
Overview of Installing the SRX5600 Services Gateway on page 43 Documentation SRX5600 Services Gateway Rack Size and Strength Requirements on page 47 Spacing of Rack Mounting Bracket Holes for the SRX5600 Services Gateway on page 48 Clearance Requirements for SRX5600 Services Gateway Airflow and Hardware Maintenance on page 49...
Page 72: Srx5600 Services Gateway Cabinet Requirements
SRX5600 Services Gateway Hardware Guide Spacing of Rack Mounting Bracket Holes for the SRX5600 Services Gateway on page 48 Connection to Building Structure for the SRX5600 Services Gateway Rack on page 49 SRX5600 Services Gateway Cabinet Requirements This section includes the following topics:...
Page 73 Overview of Installing the SRX5600 Services Gateway on page 43 Site Preparation Checklist for the SRX5600 Services Gateway on page 45 Spacing of Rack Mounting Bracket Holes for the SRX5600 Services Gateway on page 48 SRX5600 Services Gateway Cabinet Size and Clearance Requirements on page 50...
Page 75: Chapter 5 Unpacking The Srx5600 Services Gateway
Chapter 5 Unpacking the SRX5600 Services Gateway This section includes the following topics: Tools and Parts Required to Unpack the SRX5600 Services Gateway on page 53 Unpacking the SRX5600 Services Gateway on page 53 Verifying the SRX5600 Services Gateway Parts Received on page 55...
Page 76 Figure 22: Contents of the Shipping Crate Related Tools and Parts Required to Unpack the SRX5600 Services Gateway on page 53 Documentation Overview of Installing the SRX5600 Services Gateway on page 43 Site Preparation Checklist for the SRX5600 Services Gateway on page 45 Copyright ©...
Page 77: Verifying The Srx5600 Services Gateway Parts Received
Chapter 5: Chapter 5 Unpacking the SRX5600 Services Gateway Verifying the SRX5600 Services Gateway Parts Received on page 55 Verifying the SRX5600 Services Gateway Parts Received A packing list is included in each shipment. Check the parts in the shipment against the items on the packing list.
Page 78 Overview of Installing the SRX5600 Services Gateway on page 43 Documentation Site Preparation Checklist for the SRX5600 Services Gateway on page 45 Tools and Parts Required to Unpack the SRX5600 Services Gateway on page 53 Unpacking the SRX5600 Services Gateway on page 53 Copyright © 2010, Juniper Networks, Inc.
Page 79: Installing The Srx5600 Services Gateway Mounting Hardware
Moving the Mounting Brackets for Center-Mounting the SRX5600 Services Gateway on page 59 Installing the SRX5600 Services Gateway Mounting Hardware for a Rack or Cabinet The services gateway can be installed in a four-post rack or cabinet or an open-frame rack.
Page 80 SRX5600 Services Gateway Hardware Guide Install the mounting shelf on the back of the rack rails. Rest the bottom slot of each flange on a mounting screw. Partially insert the remaining screws into the open holes in each flange of the mounting shelf.
Page 81 Overview of Installing the SRX5600 Services Gateway on page 43 Documentation Site Preparation Checklist for the SRX5600 Services Gateway on page 45 Tools Required to Install the SRX5600 Services Gateway with a Mechanical Lift on page 61 Unpacking the SRX5600 Services Gateway on page 53...
Page 82 Overview of Installing the SRX5600 Services Gateway on page 43 Documentation Site Preparation Checklist for the SRX5600 Services Gateway on page 45 Tools Required to Install the SRX5600 Services Gateway with a Mechanical Lift on page 61 Unpacking the SRX5600 Services Gateway on page 53 Installing the SRX5600 Services Gateway Using a Mechanical Lift on page 61 Copyright ©...
Page 83: Tools Required To Install The Srx5600 Services Gateway With A Mechanical
Tools Required to Install the SRX5600 Services Gateway with a Mechanical Lift on page 61 Installing the SRX5600 Services Gateway Using a Mechanical Lift on page 61 Installing the SRX5600 Services Gateway Cable Management Brackets on page 63 Tools Required to Install the SRX5600 Services Gateway with a Mechanical Lift...
Page 84 SRX5600 Services Gateway Hardware Guide To install the services gateway using a lift (see Figure 25 on page 63): Ensure that the rack is in its permanent location and is secured to the building. Ensure that the installation site allows adequate clearance for both airflow and maintenance.
Page 85: Installing The Srx5600 Services Gateway Cable Management Brackets
Site Preparation Checklist for the SRX5600 Services Gateway on page 45 Unpacking the SRX5600 Services Gateway on page 53 Tools and Parts Required for SRX5600 Services Gateway Connections on page 65 Overview of Installing the SRX5600 Services Gateway on page 43 Installing the SRX5600 Services Gateway Cable Management Brackets The cable management brackets attach to both sides of the card cage.
Page 86 Insert the tabs into the slots. Tighten the captive screws completely. Figure 26: Installing the Cable Management Brackets Related Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on Documentation page 171 Overview of Installing the SRX5600 Services Gateway on page 43...
Page 87: Connecting The Srx5600 Services Gateway
Connecting the SRX5600 Services Gateway This section includes the following topics: Tools and Parts Required for SRX5600 Services Gateway Connections on page 65 Connecting the SRX5600 Services Gateway to Management and Alarm Devices on page 66 Connecting Network Cables to SRX5600 Services Gateway IOCs and Port...
Page 88: Connecting An Srx5600 Services Gateway To An External Alarm-Reporting
This section includes the following topics: Connecting the SRX5600 Services Gateway to a Network for Out-of-Band Management on page 66 Connecting the SRX5600 Services Gateway to a Management Console or an Auxiliary Device on page 67 Connecting an SRX5600 Services Gateway to an External Alarm-Reporting...
Page 89 Chapter 8: Connecting the SRX5600 Services Gateway Connecting the SRX5600 Services Gateway to a Management Console or an Auxiliary Device To use a system console to configure and manage the Routing Engine, connect it to the appropriate port on the Routing Engine. To use a laptop, modem, or other...
Page 90: Modules
Tools and Parts Required for SRX5600 Services Gateway Connections on page 65 Documentation Overview of Installing the SRX5600 Services Gateway on page 43 Alarm Relay Contact Wire Specifications for the SRX5600 Services Gateway on page 226 Connecting the SRX5600 Services Gateway to a Network for Out-of-Band Management on page 66...
Page 91 Figure 32: Attaching a Cable to an IOC Related Overview of Installing the SRX5600 Services Gateway on page 43 Documentation Tools and Parts Required for SRX5600 Services Gateway Connections on page 65 Copyright © 2010, Juniper Networks, Inc.
Page 92 Connecting the SRX5600 Services Gateway to a Network for Out-of-Band Management on page 66 Connecting the SRX5600 Services Gateway to a Management Console or an Auxiliary Device on page 67 Connecting an SRX5600 Services Gateway to an External Alarm-Reporting Device on page 67 Copyright ©...
Page 93: Grounding And Providing Power To The Srx5600 Services Gateway
Grounding and Providing Power to the SRX5600 Services Gateway This section includes the following topics: Tools and Parts Required for SRX5600 Services Gateway Grounding and Power Connections on page 71 Grounding the SRX5600 Services Gateway on page 72 Connecting Power to an AC-Powered SRX5600 Services Gateway on page 72...
Page 94: Grounding The Srx5600 Services Gateway
Documentation page 171 Overview of Installing the SRX5600 Services Gateway on page 43 Tools and Parts Required for SRX5600 Services Gateway Grounding and Power Connections on page 71 Connecting Power to an AC-Powered SRX5600 Services Gateway on page 72 Connecting Power to a DC-Powered SRX5600 Services Gateway on page 75...
Page 95 Repeat Step 1 through Step 6 for the remaining power supplies. Figure 33: Connecting AC Power to the Services Gateway Related AC Power Cord Specifications for the SRX5600 Services Gateway on page 210 Documentation Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on page 171 Copyright ©...
Page 96: Powering On An Ac-Powered Srx5600 Services Gateway
SRX5600 Services Gateway Hardware Guide Overview of Installing the SRX5600 Services Gateway on page 43 Tools and Parts Required for SRX5600 Services Gateway Grounding and Power Connections on page 71 Grounding the SRX5600 Services Gateway on page 72 Powering On an AC-Powered SRX5600 Services Gateway...
Page 97: Connecting Power To A Dc-Powered Srx5600 Services Gateway
Chapter 9: Grounding and Providing Power to the SRX5600 Services Gateway Related Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on Documentation page 171 Overview of Installing the SRX5600 Services Gateway on page 43 Tools and Parts Required for SRX5600 Services Gateway Grounding and Power...
Page 98 SRX5600 Services Gateway Hardware Guide The cable with very low resistance (indicating a closed circuit) to chassis ground is CAUTION: You must ensure that power connections maintain the proper polarity. The power source cables might be labeled to indicate (–) their polarity.
Page 99: Powering On A Dc-Powered Srx5600 Services Gateway
Chapter 9: Grounding and Providing Power to the SRX5600 Services Gateway Figure 34: Connecting DC Power to the Device Related Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on Documentation page 171 Overview of Installing the SRX5600 Services Gateway on page 43...
Page 100 Normally, the services gateway boots from the Junos OS on the CompactFlash card. After powering on a power supply, wait at least 60 seconds before turning it off. Related Powering Off the SRX5600 Services Gateway on page 79 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 101: Powering Off The Srx5600 Services Gateway
Chapter 9: Grounding and Providing Power to the SRX5600 Services Gateway Powering Off the SRX5600 Services Gateway NOTE: After powering off a power supply, wait at least 60 seconds before turning it back on. To power off the services gateway: On the external management device connected to the Routing Engine, issue the operational mode command.
Page 103: Configuring Junos Os For The Srx5600 Services Gateway
Configuring Junos OS for the SRX5600 Services Gateway This section includes the following topics: SRX5600 Services Gateway Software Configuration Overview on page 81 Initially Configuring the SRX5600 Services Gateway on page 82 SRX5600 Services Gateway Software Configuration Overview The services gateway is shipped with the Junos OS preinstalled and ready to be configured when the device is powered on.
Page 104: Initially Configuring The Srx5600 Services Gateway
SRX5600 Services Gateway Hardware Guide Initially Configuring the SRX5600 Services Gateway This procedure connects the device to the network but does not enable it to forward traffic. For complete information about enabling the device to forward traffic, including examples, see the appropriate Junos OS configuration guides.
Page 105 Chapter 10: Configuring Junos OS for the SRX5600 Services Gateway [edit] admin@# set interfaces ge-6/2/0 unit 0 family inet address address/prefix-length admin@# set interfaces ge-6/3/5 unit 0 family inet address address/prefix-length Configure the default route. [edit] admin@# set routing-options static route 0.0.0.0/0 next-hop gateway Configure basic security zones and bind them to traffic interfaces.
Page 106 SRX5600 Services Gateway Hardware Guide syslog { user * { any emergency; file messages { any any; authorization info; file interactive-commands { interactive-commands any; license { autoupdate { url https://ae1.juniper.net/junos/key_retrieval; interfaces { ge-0/0/0 { unit 0; ge-6/2/0 { unit 0 { family inet { address 5.1.1.1/24;...
Page 107 Chapter 10: Configuring Junos OS for the SRX5600 Services Gateway ge-6/2/0.0; policies { from-zone trust to-zone untrust { policy bob { match { source-address any; destination-address any; application any; then { permit; Commit the configuration to activate it on the device.
Page 109 SRX5600 Services Gateway Hardware Maintenance, Replacement, and Troubleshooting Procedures Maintaining the SRX5600 Services Gateway Hardware Components on page 89 Troubleshooting the SRX5600 Services Gateway Hardware Components on page 105 Replacing SRX5600 Services Gateway Hardware Components on page 115 Copyright © 2010, Juniper Networks, Inc.
Page 111: Maintaining The Srx5600 Services Gateway Hardware Components
Gateway Hardware Components This section includes the following topics: Tools and Parts Required to Maintain the SRX5600 Services Gateway on page 89 Routine Maintenance Procedures for the SRX5600 Services Gateway on page 89 Maintaining the SRX5600 Cooling System Components on page 90...
Page 112: Maintaining The Srx5600 Cooling System Components
Maintaining the Fan Tray on the SRX5600 Services Gateway on page 91 Maintaining the SRX5600 Services Gateway Host Subsystem and SCBs on page 92 Maintaining SPCs, IOCs, and Flex IOCs on the SRX5600 Services Gateway on page 94 Maintaining Port Modules on the SRX5600 Services Gateway on page 96...
Page 113 Chapter 11: Maintaining the SRX5600 Services Gateway Hardware Components Maintaining SPCs, IOCs, and Flex IOCs on the SRX5600 Services Gateway on page 94 Maintaining Port Modules on the SRX5600 Services Gateway on page 96 Maintaining SRX5600 Services Gateway Network Cables on page 97...
Page 114: Maintaining The Srx5600 Services Gateway Host Subsystem And Scbs
Maintaining the Air Filter on the SRX5600 Services Gateway on page 90 Maintaining the SRX5600 Services Gateway Host Subsystem and SCBs on page 92 Maintaining SPCs, IOCs, and Flex IOCs on the SRX5600 Services Gateway on page 94 Maintaining Port Modules on the SRX5600 Services Gateway on page 96...
Page 115 Chapter 11: Maintaining the SRX5600 Services Gateway Hardware Components To check the status of the Routing Engine, issue the show chassis routing-engine command. The output is similar to the following: user@host> show chassis routing-engine Routing Engine status: Slot 0: Current state...
Page 116: Maintaining The Srx5600 Packet Forwarding Engine Components
Maintaining the Air Filter on the SRX5600 Services Gateway on page 90 Maintaining the Fan Tray on the SRX5600 Services Gateway on page 91 Maintaining SPCs, IOCs, and Flex IOCs on the SRX5600 Services Gateway on page 94 Maintaining Port Modules on the SRX5600 Services Gateway on page 96...
Page 117 Chapter 11: Maintaining the SRX5600 Services Gateway Hardware Components Action On a regular basis: Check the LEDs on the craft interface corresponding to each IOC and SPC slot. The green LED labeled lights steadily when an IOC or SPC is functioning normally.
Page 118 For further description of the output from the command, see the Junos OS System Basics and Services Command Reference. Related SRX5600 Services Gateway Craft Interface IOC and SPC LEDs on page 31 Documentation Routine Maintenance Procedures for the SRX5600 Services Gateway on page 89...
Page 119 Maintaining the Fan Tray on the SRX5600 Services Gateway on page 91 Maintaining the SRX5600 Services Gateway Host Subsystem and SCBs on page 92 Maintaining SPCs, IOCs, and Flex IOCs on the SRX5600 Services Gateway on page 94 Maintaining SRX5600 Services Gateway Network Cables on page 97...
Page 120 SRX5600 Services Gateway Hardware Guide Action On a regular basis: Use the cable managers to support cables and prevent cables from dislodging or developing stress points. Figure 35: Cable Managers Place excess cable out of the way in the cable manager. Do not allow fastened loops of cable to dangle from the connector or cable manager, because this stresses the cable at the fastening point.
Page 121: Handling And Storing Srx5600 Services Gateway Cards
Maintaining the Fan Tray on the SRX5600 Services Gateway on page 91 Maintaining the SRX5600 Services Gateway Host Subsystem and SCBs on page 92 Maintaining SPCs, IOCs, and Flex IOCs on the SRX5600 Services Gateway on page 94 Maintaining Port Modules on the SRX5600 Services Gateway on page 96...
Page 122 NOTE: This terminology applies to SPCs, IOCs, and SCBs in addition to Routing Engines and port modules Figure 36: Card Edges Related Holding an SRX5600 Services Gateway Card on page 100 Documentation Storing an SRX5600 Services Gateway Card on page 102 Holding an SRX5600 Services Gateway Card When carrying a card, you can hold it either vertically or horizontally.
Page 123 Chapter 11: Maintaining the SRX5600 Services Gateway Hardware Components If the card is horizontal before you grasp it, place your left hand around the faceplate and your right hand along the bottom edge. To hold a card horizontally: Orient the card so that the faceplate faces you.
Page 124 Related SRX5600 Services Gateway Card Terminology on page 99 Documentation Storing an SRX5600 Services Gateway Card on page 102 Storing an SRX5600 Services Gateway Card You must store a card as follows: In the services gateway chassis...
Page 125: Maintaining Srx5600 Services Gateway Power Supplies
Related SRX5600 Services Gateway Craft Interface Power Supply LEDs on page 30 Documentation SRX5600 Services Gateway AC Power Supply LEDs on page 35...
Page 127: Troubleshooting Resources For The Srx5600 Services Gateway
Interface on page 105 Troubleshooting the SRX5600 Services Gateway with Chassis and Interface Alarm Messages on page 106 Troubleshooting the SRX5600 Services Gateway with Alarm Relay Contacts on page 106 Troubleshooting the SRX5600 Services Gateway with the Craft Interface LEDs on page 107...
Page 128 Troubleshooting the SRX5600 Services Gateway with Chassis and Interface Alarm Documentation Messages on page 106 Troubleshooting the SRX5600 Services Gateway with Alarm Relay Contacts on page 106 Troubleshooting the SRX5600 Services Gateway with the Craft Interface LEDs on page 107...
Page 129 Troubleshooting the SRX5600 Services Gateway with Chassis and Interface Alarm Messages on page 106 Troubleshooting the SRX5600 Services Gateway with Alarm Relay Contacts on page 106 Troubleshooting the SRX5600 Services Gateway with the Component LEDs on page 108 Copyright © 2010, Juniper Networks, Inc.
Page 130: Troubleshooting The Srx5600 Services Gateway Cooling System
105 Troubleshooting the SRX5600 Services Gateway with Chassis and Interface Alarm Messages on page 106 Troubleshooting the SRX5600 Services Gateway with Alarm Relay Contacts on page 106 Troubleshooting the SRX5600 Services Gateway with the Craft Interface LEDs on page 107...
Page 131: Troubleshooting Srx5600 Services Gateway Iocs And Flex Iocs
105 Troubleshooting the SRX5600 Services Gateway with the Craft Interface LEDs on page 107 Troubleshooting the SRX5600 Services Gateway with Alarm Relay Contacts on page 106 Troubleshooting SRX5600 Services Gateway IOCs and Flex IOCs Problem The IOCs or Flex IOCs are not functioning normally.
Page 132 SRX5600 Services Gateway Hardware Guide Issue the CLI command to check the status of installed IOCs. As shown show chassis fpc in the sample output, the value in the column labeled indicates that the Online State IOC is functioning normally: user@host>...
Page 133: Troubleshooting Srx5600 Services Gateway Port Modules
105 Troubleshooting the SRX5600 Services Gateway with the Craft Interface LEDs on page 107 Troubleshooting the SRX5600 Services Gateway with Alarm Relay Contacts on page 106 Troubleshooting SRX5600 Services Gateway Port Modules Problem The port modules are not functioning normally.
Page 134 SRX5600 Services Gateway Hardware Guide Issue the CLI command to check the status of installed SPCs. As show chassis fpc shown in the sample output, the value in the column labeled indicates Online State that the SPC is functioning normally: user@host>...
Page 135: Troubleshooting The Srx5600 Services Gateway Power System
105 Troubleshooting the SRX5600 Services Gateway with the Craft Interface LEDs on page 107 Troubleshooting the SRX5600 Services Gateway with Alarm Relay Contacts on page 106 Troubleshooting the SRX5600 Services Gateway Power System Problem The power system is not functioning normally.
Page 136 Troubleshooting the SRX5600 Services Gateway with the Command-Line Interface Documentation on page 105 Troubleshooting the SRX5600 Services Gateway with the Craft Interface LEDs on page 107 Troubleshooting the SRX5600 Services Gateway with Alarm Relay Contacts on page 106 Copyright © 2010, Juniper Networks, Inc.
Page 137: Replacing Srx5600 Services Gateway Hardware Components
Replacing SRX5600 Services Gateway Flex IOCs on page 137 Replacing SRX5600 Services Gateway Port Modules on page 140 Replacing an SRX5600 Services Gateway IOC or Port Module Cable on page 143 Replacing SRX5600 Services Gateway SPCs on page 146 Replacing SRX5600 Services Gateway XFP and SFP Transceivers on page 149...
Page 138: Tools And Parts Required To Replace Srx5600 Services Gateway Hardware
Services Processing Cards (SPCs) AC and DC power supplies (if redundant) SFP and XFP Transcievers Related Tools and Parts Required to Replace SRX5600 Services Gateway Hardware Documentation Components on page 116 Tools and Parts Required to Replace SRX5600 Services Gateway Hardware Components To replace hardware components, you must have the tools listed in Table 27 on page 116.
Page 139: Replacing The Srx5600 Services Gateway Craft Interface
Replacing the SRX5600 Services Gateway Craft Interface To replace the craft interface, perform the following procedures in sequence: Disconnecting the Alarm Relay Wires from the SRX5600 Services Gateway Craft Interface on page 118 Removing the SRX5600 Services Gateway Craft Interface on page 118...
Page 140: Installing The Srx5600 Services Gateway Craft Interface
Connecting the Alarm Relay Wires to the SRX5600 Services Gateway Craft Interface on page 120 Disconnecting the Alarm Relay Wires from the SRX5600 Services Gateway Craft Interface To disconnect the alarm relay wires from the services gateway and an alarm-reporting device (see Figure 39 on page 118): Disconnect the existing wire at the external device.
Page 141: Installing The Srx5600 Services Gateway Craft Interface
Chapter 13: Replacing SRX5600 Services Gateway Hardware Components Figure 40: Removing the Craft Interface Installing the SRX5600 Services Gateway Craft Interface To install the craft interface (see Figure 41 on page 119): Grasp the craft interface with one hand and hold the bottom edge of the craft interface with the other hand to support its weight.
Page 142: Replacing The Srx5600 Services Gateway Fan Tray
SRX5600 Services Gateway Hardware Guide Connecting the Alarm Relay Wires to the SRX5600 Services Gateway Craft Interface To connect the alarm relay wires between a services gateway and an alarm-reporting device (see Figure 42 on page 120): Prepare the required length of replacement wire with gauge between 28-AWG and 14-AWG (0.08 and 2.08 mm...
Page 143: Installing The Srx5600 Services Gateway Fan Tray
Chapter 13: Replacing SRX5600 Services Gateway Hardware Components Press the latch located on the inside of the fan tray to release it from the chassis. Place one hand under the fan tray to support it and pull the fan tray completely out of the chassis.
Page 144: Replacing The Srx5600 Services Gateway Air Filter
Replacing the SRX5600 Services Gateway Air Filter To replace the air filter, perform the following procedures in sequence: Removing the SRX5600 Services Gateway Air Filter on page 122 Installing the SRX5600 Services Gateway Air Filter on page 123 Removing the SRX5600 Services Gateway Air Filter CAUTION: Do not run the services gateway for more than a few minutes without the air filter in place.
Page 145: Installing The Srx5600 Services Gateway Air Filter
Chapter 13: Replacing SRX5600 Services Gateway Hardware Components Remove the air filter cover. Slide the air filter out of the chassis. Figure 45: Removing the Air Filter Installing the SRX5600 Services Gateway Air Filter To install the air filter (see Figure 46 on page 124): Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to one of the ESD points on the chassis.
Page 146: Replacing Srx5600 Services Gateway Host Subsystem Components
This section includes the following topics: Taking the SRX5600 Services Gateway Host Subsystem Offline on page 124 Operating and Positioning the SRX5600 Services Gateway SCB Ejectors on page 125 Replacing an SRX5600 Services Gateway SCB on page 126 Replacing the SRX5600 Services Gateway Routing Engine on page 129 Taking the SRX5600 Services Gateway Host Subsystem Offline The host subsystem is composed of an SCB with a Routing Engine installed in it.
Page 147: Removing An Srx5600 Services Gateway Scb
Related Operating and Positioning the SRX5600 Services Gateway SCB Ejectors on page 125 Documentation Removing an SRX5600 Services Gateway SCB on page 126 Replacing the SRX5600 Services Gateway Routing Engine on page 129...
Page 148: Installing An Srx5600 Services Gateway Scb
SRX5600 Services Gateway Hardware Guide Replacing an SRX5600 Services Gateway SCB Before replacing an SCB, read the guidelines in “Operating and Positioning the SRX5600 Services Gateway SCB Ejectors” on page 125. To replace an SCB, perform the following procedures: Removing an SRX5600 Services Gateway SCB on page 126...
Page 149: Installing An Srx5600 Services Gateway Scb
Chapter 13: Replacing SRX5600 Services Gateway Hardware Components Figure 47: Removing an SCB Installing an SRX5600 Services Gateway SCB To install an SCB (see Figure 48 on page 129): Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to one of the ESD points on the chassis.
Page 150 SRX5600 Services Gateway Hardware Guide 1.2 V 1202 mV 1.5 V 1511 mV 1.8 V 1798 mV 2.5 V 2481 mV 3.3 V 3306 mV 5.0 V 4956 mV 12.0 V 12084 mV 1.25 V 1250 mV 3.3 V SM3 3287 mV 5.0 V RE...
Page 151: Replacing The Srx5600 Services Gateway Routing Engine
To remove the Routing Engine (see Figure 49 on page 130): Take the host subsystem offline as described in “Taking the SRX5600 Services Gateway Host Subsystem Offline” on page 124. Place an electrostatic bag or antistatic mat on a flat, stable surface.
Page 152 To install a Routing Engine into an SCB (see Figure 50 on page 131): If you have not already done so, take the host subsystem offline. See “Taking the SRX5600 Services Gateway Host Subsystem Offline” on page 124. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to one of the ESD points on the chassis.
Page 153: Replacing Connections To Srx5600 Services Gateway Routing Engine Interface
Replacing the Management Ethernet Cable on the SRX5600 Services Gateway on page 131 Replacing the SRX5600 Services Gateway Console or Auxiliary Cable on page 132 Replacing the Management Ethernet Cable on the SRX5600 Services Gateway One Ethernet cable with RJ-45 connectors is provided with the services gateway. To...
Page 154: Replacing The Srx5600 Services Gateway Console Or Auxiliary Cable
Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on Documentation page 171 Replacing the SRX5600 Services Gateway Console or Auxiliary Cable on page 132 Replacing the SRX5600 Services Gateway Routing Engine on page 129 Replacing the SRX5600 Services Gateway Console or Auxiliary Cable To use a system console to configure and manage the Routing Engine, connect it to the port on the Routing Engine.
Page 155: Replacing Srx5600 Services Gateway Iocs
Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on Documentation page 171 Replacing the SRX5600 Services Gateway Routing Engine on page 129 Replacing the Management Ethernet Cable on the SRX5600 Services Gateway on page 131 Replacing SRX5600 Services Gateway IOCs To replace an IOC, perform the following procedures:...
Page 156 SRX5600 Services Gateway Hardware Guide CAUTION: Do not leave a fiber-optic transceiver uncovered except when inserting or removing cable. The safety cap keeps the port clean and prevents accidental exposure to laser light. CAUTION: Avoid bending fiber-optic cable beyond its minimum bend radius.
Page 157: Installing An Srx5600 Services Gateway Ioc
Chapter 13: Replacing SRX5600 Services Gateway Hardware Components Figure 54: Removing an IOC Installing an SRX5600 Services Gateway IOC An IOC weighs up to 14.5 lb (6.6 kg). Be prepared to accept its full weight. To install an IOC (see Figure 55 on page 136): Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to one of the ESD points on the chassis.
Page 158 SRX5600 Services Gateway Hardware Guide to the floor. Place excess cable out of the way in a neatly coiled loop. Placing fasteners on the loop helps to maintain its shape. CAUTION: Do not let fiber-optic cable hang free from the connector. Do not allow fastened loops of cable to dangle, which stresses the cable at the fastening point.
Page 159: Replacing Srx5600 Services Gateway Flex Iocs
Replacing SRX5600 Services Gateway Flex IOCs To replace a Flex IOC, perform the following procedures: Removing an SRX5600 Services Gateway Flex IOC on page 137 Installing an SRX5600 Services Gateway Flex IOC on page 138 Removing an SRX5600 Services Gateway Flex IOC A Flex IOC weighs up to 13.1 lb (5.9 kg).
Page 160: Installing An Srx5600 Services Gateway Flex Ioc
IOC into a different slot. Figure 57: Removing a Flex IOC Installing an SRX5600 Services Gateway Flex IOC NOTE: Your services gateway must be running Junos OS Release 9.5R1 or later in order to recognize Flex IOCs and port modules.
Page 161 Chapter 13: Replacing SRX5600 Services Gateway Hardware Components Identify the slot on the services gateway where you will install the Flex IOC. If you have not already done so, remove the blank panel from the slot where you are installing the Flex IOC.
Page 162: Replacing Srx5600 Services Gateway Port Modules
Replacing SRX5600 Services Gateway Port Modules To replace a port module, perform the following procedures: Removing an SRX5600 Services Gateway Port Module on page 140 Installing an SRX5600 Services Gateway Port Module on page 141 Removing an SRX5600 Services Gateway Port Module Port modules are installed in Flex IOCs in the services gateway card cage.
Page 163: Installing An Srx5600 Services Gateway Port Module
Chapter 13: Replacing SRX5600 Services Gateway Hardware Components CAUTION: Avoid bending fiber-optic cable beyond its minimum bend radius. An arc smaller than a few inches in diameter can damage the cable and cause problems that are difficult to diagnose. Loosen the captive screws that retain the port module in its slot in the Flex IOC.
Page 164 SRX5600 Services Gateway Hardware Guide If necessary, remove the blank panel covering the slot in the Flex IOC where you are installing the port module. Orient the port module so that the faceplate faces you. Lift the port module into place and carefully align the right and left edges of the port module with the guides inside the Flex IOC.
Page 165: Replacing An Srx5600 Services Gateway Ioc Or Port Module Cable
Replacing an SRX5600 Services Gateway IOC or Port Module Cable To replace an IOC or port module cable, perform the following procedures: Removing an SRX5600 Services Gateway IOC or Port Module Cable on page 143 Installing an SRX5600 Services Gateway IOC or Port Module Cable on page 144...
Page 166: Installing An Srx5600 Services Gateway Ioc Or Port Module Cable
Remove the cable from the cable manager and detach it from the destination port. Installing an SRX5600 Services Gateway IOC or Port Module Cable To install a cable in an IOC or a port module:: Have ready a length of the type of cable used by the component.
Page 167 Chapter 13: Replacing SRX5600 Services Gateway Hardware Components own weight as it hangs to the floor. Place excess cable out of the way in a neatly coiled loop. Placing fasteners on the loop helps to maintain its shape. CAUTION: Avoid bending fiber-optic cable beyond its minimum bend radius.
Page 168: Replacing Srx5600 Services Gateway Spcs
SRX5600 Services Gateway Hardware Guide Replacing SRX5600 Services Gateway SPCs To replace an SPC, perform the following procedures: Removing an SRX5600 Services Gateway SPC on page 146 Installing an SRX5600 Services Gateway SPC on page 147 Removing an SRX5600 Services Gateway SPC An SPC weighs up to 13.1 lb (5.9 kg).
Page 169: Installing An Srx5600 Services Gateway Spc
Chapter 13: Replacing SRX5600 Services Gateway Hardware Components Simultaneously turn both of the ejector handles counterclockwise to unseat the SPC. Grasp the handles and slide the SPC straight out of the card cage halfway. Place one hand around the front of the SPC and the other hand under it to support it.
Page 170 SRX5600 Services Gateway Hardware Guide Verify that each fiber-optic transceiver is covered with a rubber safety cap. If it does not, cover the transceiver with a safety cap. Orient the SPC so that the faceplate faces you, the text on the card is right-side up, and the EMI strip is on the right-hand side.
Page 171: Replacing Srx5600 Services Gateway Xfp And Sfp Transceivers
Replacing SRX5600 Services Gateway XFP and SFP Transceivers To replace an XFP or SFP transciever, perform the following procedures: Removing an SRX5600 Services Gateway SFP or XFP Transceiver on page 149 Installing an SRX5600 Services Gateway SFP or XFP Transceiver on page 151...
Page 172 SRX5600 Services Gateway Hardware Guide To remove an SFP or XFP transceiver (see Figure 64 on page 151): Have ready a replacement transceiver or a transceiver slot plug, an antistatic mat, and a rubber safety cap for the transceiver. Attach an ESD grounding strap to your bare wrist, and connect the strap to one of the ESD points on the chassis.
Page 173: Installing An Srx5600 Services Gateway Sfp Or Xfp Transceiver
CAUTION: After removing a transceiver from the card, wait at least 30 seconds before reinserting it or inserting a transceiver into a different socket. Installing an SRX5600 Services Gateway SFP or XFP Transceiver Small form-factor pluggable (SFPs) and XFPs are optical transceivers that are installed in an IOC, SPC, or port module.
Page 174: Replacing An Srx5600 Services Gateway Ac Power Supply
Replacing an SRX5600 Services Gateway AC Power Supply To replace an AC power supply, perform the following procedures: Removing an SRX5600 Services Gateway AC Power Supply on page 152 Installing an SRX5600 Services Gateway AC Power Supply on page 153 Removing an SRX5600 Services Gateway AC Power Supply The power supplies are located at the rear of the chassis.
Page 175: Installing An Srx5600 Services Gateway Ac Power Supply
Chapter 13: Replacing SRX5600 Services Gateway Hardware Components Figure 65: Removing an AC Power Supply Installing an SRX5600 Services Gateway AC Power Supply To install an AC power supply (see Figure 66 on page 154): Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to one of the ESD points on the chassis.
Page 176: Replacing An Srx5600 Services Gateway Dc Power Supply
Replacing an SRX5600 Services Gateway DC Power Supply To replace a DC power supply, perform the following procedures: Removing an SRX5600 Services Gateway DC Power Supply on page 154 Installing an SRX5600 Services Gateway DC Power Supply on page 155 Removing an SRX5600 Services Gateway DC Power Supply The power supplies are located at the rear of the chassis.
Page 177: Installing An Srx5600 Services Gateway Dc Power Supply
Chapter 13: Replacing SRX5600 Services Gateway Hardware Components Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to one of the ESD points on the chassis. Switch the circuit breaker on the power supply faceplate to the position Remove the clear plastic cover protecting the terminal studs on the faceplate.
Page 178 NOTE: For the SRX5600 services gateway, the DC power supplies in PEM0 must be powered by dedicated power feeds derived from feed...
Page 179: Replacing An Srx5600 Services Gateway Ac Power Supply Cord
Figure 69: Connecting DC Power Replacing an SRX5600 Services Gateway AC Power Supply Cord To replace an SRX5600 Services Gateway AC power supply cord, perform the following procedures: Disconnecting an SRX5600 Services Gateway AC Power Supply Cord on page 158 Connecting an SRX5600 Services Gateway AC Power Supply Cord on page 158 Copyright ©...
Page 180: Disconnecting An Srx5600 Services Gateway Ac Power Supply Cord
PS FAIL LED is not lit. Replacing an SRX5600 Services Gateway DC Power Supply Cable To replace an SRX5600 Services Gateway DC power supply cable, perform the following procedures: Disconnecting an SRX5600 Services Gateway DC Power Supply Cable on page 159 Connecting an SRX5600 Services Gateway DC Power Supply Cable on page 159 Copyright ©...
Page 181: Disconnecting An Srx5600 Services Gateway Dc Power Supply Cable
To install a replacement power cable for a DC power supply (see Figure 70 on page 160): Locate a replacement power cable that meets the specifications defined in “DC Power Cable Specifications for the SRX5600 Services Gateway” on page 217. Verify that a licensed electrician has attached a cable lug to the replacement power cable.
Page 182: Replacing The Srx5600 Services Gateway Cable Manager
Replacing the SRX5600 Services Gateway Cable Manager To replace the cable manager, perform the following procedures: Removing the SRX5600 Services Gateway Cable Manager on page 160 Installing the SRX5600 Services Gateway Cable Manager on page 161 Removing the SRX5600 Services Gateway Cable Manager The cable management system is located on both sides of the card cage.
Page 183: Installing The Srx5600 Services Gateway Cable Manager
Chapter 13: Replacing SRX5600 Services Gateway Hardware Components Remove the cable manager. Figure 71: Removing or Installing the Cable Management System Installing the SRX5600 Services Gateway Cable Manager To install the cable management system: Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to one of the ESD points on the chassis.
Page 185: Appendixes
Cable and Wire Guidelines and Specifications for the SRX5600 Services Gateway on page 221 Cable Connector Pinouts on page 227 Installing the SRX5600 Services Gateway Without a Mechanical Lift on page 229 Contacting Customer Support and Returning the SRX5600 Services Gateway Hardware on page 243...
Page 187 Equipment on page 173 SRX5600 Services Gateway Installation Safety Guidelines and Warnings on page 174 SRX5600 Services Gateway Laser and LED Safety Guidelines and Warnings on page 179 SRX5600 Services Gateway Maintenance and Operational Safety Guidelines and Warnings on page 183...
Page 188 SRX5600 Services Gateway Hardware Guide WARNING: This symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents.
Page 189: Appendix A Safety And Regulatory Compliance Information
Related SRX5600 Services Gateway General Safety Guidelines and Warnings on page 167 Documentation Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on...
Page 190: Additional Srx5600 Services Gateway Warnings
Avoid touching uninsulated electrical wires or terminals that have not been disconnected from their power source. Such an action could cause electrical shock. Related SRX5600 Services Gateway Definition of Safety Warning Levels on page 165 Documentation Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on...
Page 191: Restricted Access Area Warning
Related Restricted Access Area Warning on page 169 Documentation SRX5600 Services Gateway Definition of Safety Warning Levels on page 165 Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on page 171 SRX5600 Services Gateway Fire Safety Requirements and Fire Suppression Equipment...
Page 192: Preventing Electrostatic Discharge Damage To The Srx5600 Services
Related Qualified Personnel Warning on page 168 Documentation SRX5600 Services Gateway General Safety Guidelines and Warnings on page 167 SRX5600 Services Gateway Definition of Safety Warning Levels on page 165 Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on...
Page 193 Appendix A: Safety and Regulatory Compliance Information Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway Many services gateway hardware components are sensitive to damage from static electricity. Some components can be impaired by voltages as low as 30 V. You can easily generate potentially damaging static voltages whenever you handle plastic or foam packing material or if you move components across plastic or carpets.
Page 194 Qualified Personnel Warning on page 168 Documentation Restricted Access Area Warning on page 169 SRX5600 Services Gateway General Safety Guidelines and Warnings on page 167 SRX5600 Services Gateway Definition of Safety Warning Levels on page 165 Copyright © 2010, Juniper Networks, Inc.
Page 195: Equipment
NOTE: To keep warranties effective, do not use a dry chemical fire extinguisher to control a fire at or near a Juniper Networks services gateway. If a dry chemical fire extinguisher is used, the unit is no longer eligible for coverage under a service agreement.
Page 196: Srx5600 Services Gateway Installation Safety Guidelines And Warnings
SRX5600 Services Gateway Hardware Guide SRX5600 Services Gateway Definition of Safety Warning Levels on page 165 SRX5600 Services Gateway Installation Safety Guidelines and Warnings This section includes the following topics: Chassis Lifting Guidelines on page 174 Installation Instructions Warning on page 174...
Page 197 Related Chassis Lifting Guidelines on page 174 Documentation SRX5600 Services Gateway General Safety Guidelines and Warnings on page 167 Rack-Mounting Requirements and Warnings on page 175 Ramp Warning on page 179 Rack-Mounting Requirements and Warnings Ensure that the equipment rack into which the services gateway is installed is evenly and securely supported to avoid the hazardous condition that could result from uneven mechanical loading.
Page 198 Les directives ci-dessous sont destinées à assurer la protection du personnel: Le rack sur lequel est monté le Juniper Networks services gateway doit être fixé à la structure du bâtiment. Si cette unité constitue la seule unité montée en casier, elle doit être placée dans le bas.
Page 199 Le seguenti direttive vengono fornite per garantire la sicurezza personale: Il Juniper Networks services gateway deve essere installato in un telaio, il quale deve essere fissato alla struttura dell'edificio. Questa unità deve venire montata sul fondo del supporto, se si tratta dell'unica unità...
Page 200 Para garantizar su seguridad, proceda según las siguientes instrucciones: El Juniper Networks services gateway debe instalarse en un bastidor fijado a la estructura del edificio. Colocar el equipo en la parte inferior del bastidor, cuando sea la única unidad en el mismo.
Page 201: Ramp Warning
Appendix A: Safety and Regulatory Compliance Information Related Chassis Lifting Guidelines on page 174 Documentation SRX5600 Services Gateway General Safety Guidelines and Warnings on page 167 Installation Instructions Warning on page 174 Ramp Warning on page 179 Ramp Warning WARNING: When installing the services gateway, do not use a ramp inclined at more than 10 degrees.
Page 202: Class 1 Laser Warning
SRX5600 Services Gateway Hardware Guide General Laser Safety Guidelines When working around the services gateway, observe the following safety guidelines to prevent eye injury: Do not look into unterminated ports or at fibers that connect to unknown sources. Do not examine unterminated optical ports with optical instruments.
Page 203: Class 1 Led Product Warning
Attention Ne pas fixer le faisceau des yeux, ni l'observer directement à l'aide d'instruments optiques. Warnung Nicht direkt in den Strahl blicken und ihn nicht direkt mit optischen Geräten prüfen. Avvertenza Non fissare il raggio con gli occhi né usare strumenti ottici per osservarlo direttamente. Copyright © 2010, Juniper Networks, Inc.
Page 204: Radiation From Open Port Apertures Warning
SRX5600 Services Gateway Hardware Guide Advarsel Stirr eller se ikke direkte p strlen med optiske instrumenter. Aviso Não olhe fixamente para o raio, nem olhe para ele directamente com instrumentos ópticos. ¡Atención! No mirar fijamente el haz ni observarlo directamente con instrumentos ópticos.
Page 205: Battery Handling Warning
Class 1 Laser Warning on page 180 Class 1 LED Product Warning on page 181 Laser Beam Warning on page 181 SRX5600 Services Gateway Maintenance and Operational Safety Guidelines and Warnings This section includes the following topics: Battery Handling Warning on page 183...
Page 206 SRX5600 Services Gateway Hardware Guide Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant. Jeter les piles usagées conformément aux instructions du fabricant.
Page 207 Varning! Tag av alla smycken (inklusive ringar, halsband och armbandsur) innan du arbetar på utrustning som är kopplad till kraftledningar. Metallobjekt hettas upp när de kopplas ihop med ström och jord och kan förorsaka allvarliga brännskador; metallobjekt kan också sammansvetsas med kontakterna. Copyright © 2010, Juniper Networks, Inc.
Page 208 SRX5600 Services Gateway Hardware Guide Related Battery Handling Warning on page 183 Documentation Lightning Activity Warning on page 186 Operating Temperature Warning on page 187 Product Disposal Warning on page 188 Lightning Activity Warning WARNING: Do not work on the system or connect or disconnect cables during periods of lightning activity.
Page 209 104°F (40°C). To prevent airflow restriction, allow at least 6 in. (15.2 cm) of clearance around the ventilation openings. Waarschuwing Om te voorkomen dat welke services gateway van de Juniper Networks services gateway dan ook oververhit raakt, dient u deze niet te bedienen op een plaats waar de maximale aanbevolen omgevingstemperatuur van 40°C wordt overschreden.
Page 210 15,2 cm alrededor de las aperturas para ventilación. Varning! Förhindra att en Juniper Networks services gateway överhettas genom att inte använda den i ett område där den maximalt rekommenderade omgivningstemperaturen på...
Page 211: Srx5600 Services Gateway Electrical Safety Guidelines And Warnings
Jewelry Removal Warning on page 184 Lightning Activity Warning on page 186 Operating Temperature Warning on page 187 SRX5600 Services Gateway Electrical Safety Guidelines and Warnings This section includes the following topics: In Case of Electrical Accident on page 189...
Page 212 SRX5600 Services Gateway Hardware Guide Never assume that power is disconnected from a circuit. Always check the circuit before starting to work. Carefully look for possible hazards in your work area, such as moist floors, ungrounded power extension cords, and missing safety grounds.
Page 213 Power Disconnection Warning WARNING: Before working on the services gateway or near power supplies, unplug the power cord from an AC-powered services gateway; switch off the power at the circuit breaker on a DC-powered services gateway. Copyright © 2010, Juniper Networks, Inc.
Page 214 SRX5600 Services Gateway Hardware Guide Waarschuwing Voordat u aan een frame of in de nabijheid van voedingen werkt, dient u bij wisselstroom toestellen de stekker van het netsnoer uit het stopcontact te halen; voor gelijkstroom toestellen dient u de stroom uit te schakelen bij de stroomverbreker.
Page 215 Varning! Använd endast ledare av koppar. Related In Case of Electrical Accident on page 189 Documentation DC Power Electrical Safety Guidelines and Warnings on page 194 SRX5600 Services Gateway Agency Approvals on page 199 Copyright © 2010, Juniper Networks, Inc.
Page 216 SRX5600 Services Gateway Hardware Guide DC Power Electrical Safety Guidelines and Warnings When working with DC-powered equipment, observe the following guidelines and warnings: DC Power Electrical Safety Guidelines DC Power Disconnection Warning DC Power Grounding Requirements and Warning DC Power Wiring Sequence Warning...
Page 217 CC, mettere l'interruttore in posizione OFF e fissarlo con nastro adesivo in tale posizione. Advarsel Før noen av disse prosedyrene utføres, kontroller at strømmen er frakoblet likestrømkretsen. Sørg for at all strøm er slått AV. Dette gjøres ved Copyright © 2010, Juniper Networks, Inc.
Page 218 SRX5600 Services Gateway Hardware Guide å lokalisere strømbryteren på brytertavlen som betjener likestrømkretsen, slå strømbryteren AV og teipe bryterhåndtaket på strømbryteren i AV-stilling. Aviso Antes de executar um dos seguintes procedimentos, certifique-se que desligou a fonte de alimentação de energia do circuito de corrente contínua.
Page 219 è da massa a massa, da positivo a positivo (da linea ad L) e da negativo a negativo (da neutro a N). Tenere presente che il filo di massa deve sempre venire collegato per primo e scollegato per ultimo. Copyright © 2010, Juniper Networks, Inc.
Page 220 SRX5600 Services Gateway Hardware Guide Advarsel Riktig tilkoples tilkoplingssekvens er jord til jord, +RTN til +RTN, –48 V til – 48 V. Riktig frakoples tilkoplingssekvens er –48 V til – 48 V, +RTN til +RTN, jord til jord. Aviso Ate con alambre la fuente de potencia cc Usando los terminales apropiados en el extremo del cableado.
Page 221: Srx5600 Services Gateway Agency Approvals
General Electrical Safety Guidelines and Warnings on page 189 SRX5600 Services Gateway Agency Approvals on page 199 SRX5600 Services Gateway DC Power Supply Specifications on page 213 SRX5600 Services Gateway Chassis Grounding Specifications on page 205 SRX5600 Services Gateway Agency Approvals...
Page 222: Srx5600 Services Gateway Compliance Statements For Emc Requirements
Documentation General Electrical Safety Guidelines and Warnings on page 189 DC Power Electrical Safety Guidelines and Warnings on page 194 SRX5600 Services Gateway Compliance Statements for EMC Requirements Canada on page 201 European Community on page 201 Copyright © 2010, Juniper Networks, Inc.
Page 223: Canada
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Related SRX5600 Services Gateway Agency Approvals on page 199 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 225: Srx5600 Services Gateway Environmental Specifications
Articles 110-16, 110-17, and 110-18 of the National Electrical Code, ANSI/NFPA 70. Related SRX5600 Services Gateway Agency Approvals on page 199 Documentation SRX5600 Services Gateway General Safety Guidelines and Warnings on page 167 Copyright © 2010, Juniper Networks, Inc.
Page 226 SRX5600 Services Gateway Hardware Guide SRX5600 Services Gateway Fire Safety Requirements and Fire Suppression Equipment on page 173 SRX5600 Services Gateway Definition of Safety Warning Levels on page 165 General Electrical Safety Guidelines and Warnings on page 189 Copyright © 2010, Juniper Networks, Inc.
Page 227: Srx5600 Services Gateway Power Guidelines, Requirements, And
SRX5600 Services Gateway Chassis Grounding Specifications on page 205 SRX5600 Services Gateway Grounding-Cable Lug Specification on page 206 SRX5600 Services Gateway AC Power Specifications and Requirements on page 207 SRX5600 Services Gateway DC Power Specifications and Requirements on page 213...
Page 228: Srx5600 Services Gateway Grounding-Cable Lug Specification
Figure 75: Grounding Point (AC-Powered Services Gateway Shown, DC-Powered Similar) Related SRX5600 Services Gateway Grounding-Cable Lug Specification on page 206 Documentation SRX5600 Services Gateway Grounding-Cable Lug Specification The accessory box shipped with the services gateway includes the cable lug that attaches to the grounding cable (see Figure 76 on page 206).
Page 229: Srx5600 Services Gateway Ac Power Specifications And Requirements
SRX5600 Services Gateway AC Power Supply Specifications on page 207 Power Consumption for an AC-Powered SRX5600 Services Gateway on page 208 AC Power Circuit Breaker Requirements for the SRX5600 Services Gateway on page 210 AC Power Cord Specifications for the SRX5600 Services Gateway on page 210 SRX5600 Services Gateway AC Power System Specifications Table 29 on page 207 lists the AC power system electrical specifications.
Page 230 Documentation Power Consumption for an AC-Powered SRX5600 Services Gateway on page 208 AC Power Circuit Breaker Requirements for the SRX5600 Services Gateway on page 210 AC Power Cord Specifications for the SRX5600 Services Gateway on page 210 Power Consumption for an AC-Powered SRX5600 Services Gateway We recommend that you provision 11.0 A @ 200 VAC (2200 W) or 14.5 A @ 110 VAC (1595...
Page 231 Appendix C: SRX5600 Services Gateway Power Guidelines, Requirements, and Specifications Table 32 on page 209 lists the power requirements for various hardware components when the services gateway is operating under typical voltage conditions. Table 32: Component Power Requirements Power Requireme...
Page 232 Documentation SRX5600 Services Gateway AC Power Supply Specifications on page 207 AC Power Circuit Breaker Requirements for the SRX5600 Services Gateway on page 210 AC Power Cord Specifications for the SRX5600 Services Gateway on page 210 AC Power Circuit Breaker Requirements for the SRX5600 Services Gateway Each AC power supply has a single AC appliance inlet located on the power supply that requires a dedicated AC power feed.
Page 233 Appendix C: SRX5600 Services Gateway Power Guidelines, Requirements, and Specifications Table 33: AC Power Cord Specifications Electrical Country Model Number Specification Plug Type Australia CBL-M-PWR-RA-AU 240 VAC, 50 Hz AC SAA/3/15 China CBL-M-PWR-RA-CH 220 VAC, 50 Hz AC CH2-16P Europe (except Denmark, Italy, Switzerland,...
Page 234 CAUTION: Power cords and cables must not block access to device components or drape where people could trip on them. Related SRX5600 Services Gateway AC Power System Specifications on page 207 Documentation Copyright © 2010, Juniper Networks, Inc.
Page 235: Srx5600 Services Gateway Dc Power Specifications And Requirements
SRX5600 Services Gateway AC Power Supply Specifications on page 207 Power Consumption for an AC-Powered SRX5600 Services Gateway on page 208 AC Power Circuit Breaker Requirements for the SRX5600 Services Gateway on page 210 SRX5600 Services Gateway DC Power Specifications and Requirements...
Page 236 Documentation Power Consumption for a DC-Powered SRX5600 Services Gateway on page 214 DC Power Circuit Breaker Requirements for the SRX5600 Services Gateway on page 216 DC Power Source Cabling for the SRX5600 Services Gateway on page 216 DC Power Cable Specifications for the SRX5600 Services Gateway on page 217...
Page 237 Appendix C: SRX5600 Services Gateway Power Guidelines, Requirements, and Specifications Table 36: DC-Powered Base System Requirements (continued) Current Power Requirement Requirement (Amps @ DC Power Supply Configuration (Watts) –48 VDC) Redundant configuration includes four DC power supplies, 180 W 3.8 A...
Page 238 Documentation SRX5600 Services Gateway DC Power Supply Specifications on page 213 DC Power Circuit Breaker Requirements for the SRX5600 Services Gateway on page 216 DC Power Source Cabling for the SRX5600 Services Gateway on page 216 DC Power Cable Specifications for the SRX5600 Services Gateway on page 217...
Page 239 SRX5600 Services Gateway DC Power Supply Specifications on page 213 Power Consumption for a DC-Powered SRX5600 Services Gateway on page 214 DC Power Circuit Breaker Requirements for the SRX5600 Services Gateway on page 216 DC Power Cable Specifications for the SRX5600 Services Gateway on page 217...
Page 240 SRX5600 Services Gateway DC Power Supply Specifications on page 213 Power Consumption for a DC-Powered SRX5600 Services Gateway on page 214 DC Power Circuit Breaker Requirements for the SRX5600 Services Gateway on page 216 DC Power Source Cabling for the SRX5600 Services Gateway on page 216...
Page 241: Srx5600 Services Gateway Electrical Wiring Guidelines
SRX5600 Services Gateway DC Power Supply Specifications on page 213 Power Consumption for a DC-Powered SRX5600 Services Gateway on page 214 DC Power Circuit Breaker Requirements for the SRX5600 Services Gateway on page 216 DC Power Source Cabling for the SRX5600 Services Gateway on page 216...
Page 242 SRX5600 Services Gateway Hardware Guide Related General Electrical Safety Guidelines and Warnings on page 189 Documentation Installation Instructions Warning on page 174 Copyright © 2010, Juniper Networks, Inc.
Page 243: Gateway
Network Cable Specifications and Guidelines for the SRX5600 Services Gateway on page 221 Alarm Relay Contact Wire Specifications for the SRX5600 Services Gateway on page 226 Console Port Cable and Wire Specifications for the SRX5600 Services Gateway on page 226...
Page 244 Compared with multimode fiber, single-mode fiber has higher bandwidth and can carry signals for longer distances. It is consequently more expensive. Related Attenuation and Dispersion in Fiber-Optic Cable for the SRX5600 Services Gateway Documentation on page 222 Calculating Power Budget for Fiber-Optic Cable for the SRX5600 Services Gateway...
Page 245 Appendix D: Cable and Wire Guidelines and Specifications for the SRX5600 Services Gateway of component attenuation, power penalties (including those from dispersion), and a safety margin for unexpected losses. Related Signal Loss in Multimode and Single-Mode Fiber-Optic Cable for the SRX5600 Services...
Page 246 SRX5600 Services Gateway Hardware Guide – LL greater than zero indicates that the power budget is sufficient to operate the receiver. Factors that can cause link loss include higher-order mode losses, modal and chromatic dispersion, connectors, splices, and fiber attenuation. Table 39 on page 224 lists an estimated amount of loss for the factors used in the following sample calculations.
Page 247: Services Gateway
Appendix D: Cable and Wire Guidelines and Specifications for the SRX5600 Services Gateway The following sample calculation for an 8 km-long single-mode link with a power budget ) of 13 dB uses the estimated values from Table 39 on page 224 to calculate link loss ) as the sum of fiber attenuation (8 km @ 0.5 dB/km, or 4 dB) and loss for seven...
Page 248 SRX5600 Services Gateway Hardware Guide Related Connecting the SRX5600 Services Gateway to a Management Console or an Auxiliary Documentation Device on page 67 Connecting the SRX5600 Services Gateway to a Network for Out-of-Band Management on page 66 Alarm Relay Contact Wire Specifications for the SRX5600 Services Gateway Table 41 on page 226 lists the specifications for the wires that connect to the alarm relay contacts.
Page 249: Appendix E Cable Connector Pinouts
APPENDIX E Cable Connector Pinouts RJ-45 Connector Pinouts for the SRX5600 Services Gateway Routing Engine Ethernet Port on page 227 RJ-45 Connector Pinouts for the SRX5600 Services Gateway Routing Engine Auxiliary and Console Ports on page 228 RJ-45 Connector Pinouts for the SRX5600 Services Gateway Routing Engine Ethernet...
Page 250: Connector Pinouts For The Srx5600 Services Gateway Routing Engine Auxiliary And Console Ports
Receive Data DSR/DCD Data Set Ready Clear to Send Related Console Port Cable and Wire Specifications for the SRX5600 Services Gateway on Documentation page 226 Connecting the SRX5600 Services Gateway to a Management Console or an Auxiliary Device on page 67...
Page 251: Appendix F Installing The Srx5600 Services Gateway Without A Mechanical Lift
Removing Components from the SRX5600 Chassis Before Installing It Without a Lift on page 230 Installing the SRX5600 Services Gateway Chassis in the Rack Manually on page 235 Reinstalling Components in the SRX5600 Services Gateway Chassis After Installing It Without a Lift on page 237...
Page 252 Removing Components from the SRX5600 Chassis Before Installing It Without a Lift on page 230 Installing the SRX5600 Services Gateway Chassis in the Rack Manually on page 235 Reinstalling Components in the SRX5600 Services Gateway Chassis After Installing It Without a Lift on page 237...
Page 253: Appendix F Installing The Srx5600 Services Gateway Without A Mechanical Lift
Appendix F: Installing the SRX5600 Services Gateway Without a Mechanical Lift Removing the Power Supplies Before Installing the SRX5600 Services Gateway Without a Lift Remove the leftmost power supply first and then work your way to the right. To remove...
Page 254 SRX5600 Services Gateway Hardware Guide Figure 81: Removing the Fan Tray Removing SCBs Before Installing an SRX5600 Services Gateway Without a Lift To remove the SCBs (see Figure 82 on page 233): Place an electrostatic bag or antistatic mat on a flat, stable surface.
Page 255: Gateway Without A Lift
Appendix F: Installing the SRX5600 Services Gateway Without a Mechanical Lift Figure 82: Removing an SCB Removing IOCs, Flex IOCs, and SPCs Before Installing an SRX5600 Services Gateway Without a Lift The services gateway holds up to six IOCs, Flex IOCs, and SPCs, which are installed horizontally in the front of the device.
Page 256 Tools Required to Install the SRX5600 Services Gateway Without a Mechanical Lift on page 230 Preventing Electrostatic Discharge Damage to the SRX5600 Services Gateway on page 171 Installing the SRX5600 Services Gateway Chassis in the Rack Manually on page 235 Copyright © 2010, Juniper Networks, Inc.
Page 257: Installing The Srx5600 Services Gateway Chassis In The Rack Manually
Reinstalling Components in the SRX5600 Services Gateway Chassis After Installing It Without a Lift on page 237 Installing the SRX5600 Services Gateway Mounting Hardware for a Rack or Cabinet on page 57 Moving the Mounting Brackets for Center-Mounting the SRX5600 Services Gateway...
Page 258 NOTE: This illustration depicts the services gateway being installed in an open-frame rack. Related Overview of Installing the SRX5600 Services Gateway Without a Mechanical Lift on Documentation page 229 Tools Required to Install the SRX5600 Services Gateway Without a Mechanical Lift...
Page 259: Reinstalling Components In The Srx5600 Services Gateway Chassis After Installing It Without A Lift
Appendix F: Installing the SRX5600 Services Gateway Without a Mechanical Lift Installing the SRX5600 Services Gateway Mounting Hardware for a Rack or Cabinet on page 57 Moving the Mounting Brackets for Center-Mounting the SRX5600 Services Gateway on page 59 Reinstalling Components in the SRX5600 Services Gateway Chassis After Installing...
Page 260 SRX5600 Services Gateway Hardware Guide Figure 85: Reinstalling a Power Supply Reinstalling the Fan Tray After Installing the SRX5600 Services Gateway Without a Lift To reinstall the fan tray (see Figure 86 on page 239): Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to one of the ESD points on the chassis.
Page 261 Appendix F: Installing the SRX5600 Services Gateway Without a Mechanical Lift Figure 86: Reinstalling the Fan Tray Reinstalling SCBs After Installing the SRX5600 Services Gateway Without a Lift To reinstall an SCB (see Figure 87 on page 240): CAUTION: Before removing or replacing an SCB, ensure that the ejector handles are stored horizontally and pressed toward the center of the SCB.
Page 262 SRX5600 Services Gateway Hardware Guide Figure 87: Reinstalling an SCB Reinstalling IOCs, Flex IOCs, and SPCs After Installing the SRX5600 Services Gateway Without a Lift To reinstall IOCs, Flex IOCs, and SPCs, follow this procedure for each card (see Figure 88 on page 241): Place the card on an antistatic mat or remove it from its electrostatic bag.
Page 265: Contacting Customer Support And Returning The Srx5600 Services
Contacting Customer Support to Obtain Return Materials Authorization for the SRX5600 Services Gateway on page 253 Packing the SRX5600 Services Gateway or a Component for Shipment on page 254 Return Procedure for the SRX5600 Services Gateway If a problem cannot be resolved by the JTAC technician, a Return Materials Authorization (RMA) is issued.
Page 266: Locating Srx5600 Services Gateway Component Serial Numbers
Locating the SRX5600 Services Gateway Chassis Serial Number Label on page 246 Locating the SRX5600 Services Gateway SCB Serial Number Label on page 247 Locating the SRX5600 Services Gateway IOC, Flex IOC, and SPC Serial Number Label on page 248...
Page 267: Locating The Srx5600 Services Gateway Power Supply Serial Number
Appendix G: Contacting Customer Support and Returning the SRX5600 Services Gateway Hardware Locating the SRX5600 Services Gateway Power Supply Serial Number Labels on page 250 Locating the SRX5600 Services Gateway Routing Engine Serial Number Label on page 251 Locating the SRX5600 Services Gateway Craft Interface Serial Number...
Page 268 Locating the SRX5600 Services Gateway Chassis Serial Number Label on page 246 Locating the SRX5600 Services Gateway SCB Serial Number Label on page 247 Locating the SRX5600 Services Gateway IOC, Flex IOC, and SPC Serial Number Label on page 248...
Page 269 245 Locating the SRX5600 Services Gateway SCB Serial Number Label on page 247 Locating the SRX5600 Services Gateway IOC, Flex IOC, and SPC Serial Number Label on page 248 Locating the SRX5600 Services Gateway Port Module Serial Number Label on page 249...
Page 270 245 Locating the SRX5600 Services Gateway Chassis Serial Number Label on page 246 Locating the SRX5600 Services Gateway IOC, Flex IOC, and SPC Serial Number Label on page 248 Locating the SRX5600 Services Gateway Port Module Serial Number Label on page 249...
Page 271 Locating the SRX5600 Services Gateway Chassis Serial Number Label on page 246 Locating the SRX5600 Services Gateway SCB Serial Number Label on page 247 Locating the SRX5600 Services Gateway Port Module Serial Number Label on page 249 Locating the SRX5600 Services Gateway Power Supply Serial Number Labels on...
Page 272 SRX5600 Services Gateway Hardware Guide Locating the SRX5600 Services Gateway Routing Engine Serial Number Label on page 251 Locating the SRX5600 Services Gateway Craft Interface Serial Number Label on page 252 Information You Might Need to Supply to JTAC on page 253...
Page 273 Locating the SRX5600 Services Gateway Chassis Serial Number Label on page 246 Locating the SRX5600 Services Gateway SCB Serial Number Label on page 247 Locating the SRX5600 Services Gateway IOC, Flex IOC, and SPC Serial Number Label on page 248...
Page 274 Locating the SRX5600 Services Gateway Chassis Serial Number Label on page 246 Locating the SRX5600 Services Gateway SCB Serial Number Label on page 247 Locating the SRX5600 Services Gateway IOC, Flex IOC, and SPC Serial Number Label on page 248...
Page 275: Contacting Customer Support To Obtain Return Materials Authorization For The Srx5600 Services Gateway
Locating the SRX5600 Services Gateway Chassis Serial Number Label on page 246 Locating the SRX5600 Services Gateway SCB Serial Number Label on page 247 Locating the SRX5600 Services Gateway IOC, Flex IOC, and SPC Serial Number Label on page 248...
Page 276: Packing The Srx5600 Services Gateway Or A Component For Shipment
Packing the SRX5600 Services Gateway or a Component for Shipment This section includes the following topics: Required Tools and Parts for Packing the SRX5600 Services Gateway on page 254 Packing the SRX5600 Services Gateway for Shipment on page 255 Packing SRX5600 Services Gateway Components for Shipment on page 256...
Page 277: Packing The Srx5600 Services Gateway For Shipment
Appendix G: Contacting Customer Support and Returning the SRX5600 Services Gateway Hardware Flat-blade (–) screwdriver Mechanical lift, if available Phillips (+) screwdrivers, numbers 1 and 2 Rubber safety cap for fiber-optic interfaces or cable Wire cutters Related Return Procedure for the SRX5600 Services Gateway on page 243...
Page 278 Disconnecting an SRX5600 Services Gateway DC Power Supply Cable on page 159 Return Procedure for the SRX5600 Services Gateway on page 243 Required Tools and Parts for Packing the SRX5600 Services Gateway on page 254 Packing SRX5600 Services Gateway Components for Shipment on page 256...
Page 279 Appendix G: Contacting Customer Support and Returning the SRX5600 Services Gateway Hardware Packing the SRX5600 Services Gateway for Shipment on page 255 Copyright © 2010, Juniper Networks, Inc.
Page 283 LEDs (red and yellow) on craft interface....29 replacing..............131 messages, list of............106 fiber-optic relay contacts..............32 attenuation............222 connecting wire............120 cleaning instructions for transceivers....97 disconnecting wire..........118 dispersion...............222 wire specifications..........226 multimode and single-mode......221 temperature, displaying..........109 transmission distance, maximum....221 altitude, acceptable range..........203 wavelength ranges..........221 Copyright © 2010, Juniper Networks, Inc.
Page 284 SRX5600 Services Gateway Hardware Guide components disconnecting............143 cable management system........39 maintaining..............97 chassis...................7 port module cooling system..............37 disconnecting............143 craft interface..............28 power See AC power cord field replacement............115 cable management system Flex IOC................14 description................39 host subsystem...............22 fiber-optic cable, use with..........97 IOC..................11 installation................63 midplane................10...
Page 285 (for Routing specifications............225 Engine management) Ethernet port on Routing Engine for maintenance or replacement....132 description................27 tools required............65 cable, DPC for maintenance or replacement....144 fan tray description................37 maintaining...............91 Copyright © 2010, Juniper Networks, Inc.
Page 286 SRX5600 Services Gateway Hardware Guide cable, Ethernet port (for Routing Engine status, checking..........94, 97, 109 management) storing................102 for maintenance or replacement....131 IOCs tools required............65 components..............12 cable, PIC troubleshooting............109 for maintenance or replacement....144 DC power and grounding cables jewelry removal warning............184 tools required............65...
Page 287 Port module after chassis installation........237 cable removal instructions...........143 after chassis installation........239 troubleshooting...............111 relative humidity, acceptable..........203 power budget calculation............223 cables and cords See AC power cord; DC power cables margin calculation............223 Copyright © 2010, Juniper Networks, Inc.
Page 288 SRX5600 Services Gateway Hardware Guide removal instructions cable reinstalling auxiliary or console port (for Routing after chassis installation........239 Engine management)........132 removing Ethernet port (for Routing Engine before chassis installation.......232 management)...........131 SCBs IOC................143 components..............24 port module............143 description................22 removing LEDs..................24 alarm relay contact wires...........118 seismic (earthquake)............203...

Juniper SRX5600 Hardware Manual

Chapter 1 Introduction to the SRX5600 Services Gateway

Chapter 2 SRX5600 Services Gateway Hardware Components

Chapter 3 SRX5600 Services Gateway Installation

Chapter 4 Preparing the Site for the SRX5600 Services Gateway Installation

Chapter 5 Unpacking the SRX5600 Services Gateway

Chapter 6 Installing the SRX5600 Services Gateway Mounting Hardware

Chapter 7 Installing the SRX5600 Services Gateway

Chapter 8 Connecting the SRX5600 Services Gateway

Chapter 9 Grounding and Providing Power to the SRX5600 Services Gateway

Chapter 10 Configuring Junos os for the SRX5600 Services Gateway

Chapter 11 Maintaining the SRX5600 Services Gateway Hardware Components

Chapter 12 Troubleshootingthesrx5600Servicesgatewayhardware

Chapter 13 Components

Appendix A Safety and Regulatory Compliance Information

Appendix E Cable Connector Pinouts

Appendix F Installing the SRX5600 Services Gateway Without a Mechanical Lift

Appendix F Installing the SRX5600 Services Gateway Without a Mechanical Lift

Quick Links

Hardware Guide

Troubleshooting

Need help?

Questions and answers

Related Manuals for Juniper SRX5600

Summary of Contents for Juniper SRX5600
