Services Gateway
Flex IOC and Port Module
Installation Instructions
May 2009
Part Number: 530-029503-01
Revision 02
This document describes how to install and remove flex IOCs and port modules
installed in Juniper Networks SRX 5800 and SRX 5600 services gateways. The
illustrations in this document show the SRX 5600 services gateway, but the
instructions apply to both SRX 5800 and SRX 5600 services gateways.
Flex I/O Cards and Port Modules .....................................................................2
Flex IOC Components ...............................................................................3
Port Module Components .........................................................................4
Port Module LEDs .....................................................................................4
Handling and Storing Cards .............................................................................5
Holding a Card ..........................................................................................6
Storing a Card ...........................................................................................8
Replacing Flex IOCs and Port Modules ............................................................9
Removing a Flex IOC ................................................................................9
Installing a Flex IOC ................................................................................11
Removing a Port Module .........................................................................12
Installing a Port Module ..........................................................................14
Preventing Electrostatic Discharge Damage ..................................................16
Electrostatic Discharge Point .........................................................................16
List of Technical Publications ........................................................................19
Requesting Technical Support .......................................................................19
Revision History ............................................................................................20
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRX 5600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Juniper SRX 5600

Summary of Contents for Juniper SRX 5600

  • Page 1: Table Of Contents

    Revision 02 This document describes how to install and remove flex IOCs and port modules installed in Juniper Networks SRX 5800 and SRX 5600 services gateways. The illustrations in this document show the SRX 5600 services gateway, but the instructions apply to both SRX 5800 and SRX 5600 services gateways.

  • Page 2: Contents Flex I/O Cards And Port Modules

    SRX 5600 and SRX 5800 Services Gateway Flex IOC and Port Module Installation Instructions Flex I/O Cards and Port Modules Flex I/O Cards (flex IOCs) are IOCs with two slots, which accept port modules that add Ethernet ports to your services gateway. A flex IOC with installed port modules functions in the same way as a regular IOC, but allows greater flexibility in adding different types of Ethernet ports to your services gateway.

  • Page 3: Flex Ioc Components

    Flex I/O Cards and Port Modules You use port modules and flex IOCs to add different combinations of SFP, XFP, and TX ports to your services gateway to suit the specific needs of your network. The available port modules are shown in Figure 2 on page 3. See Installing a Port Module”...

  • Page 4: Port Module Components

    SRX 5600 and SRX 5800 Services Gateway Flex IOC and Port Module Installation Instructions Midplane connectors and power circuitry Processor subsystem, including a 1.2-GHz CPU, a system controller, and 1 GB of SDRAM Port Module Components Each port module consists of the following components:...

  • Page 5: Handling And Storing Cards

    Handling and Storing Cards Table 4: 16-Port TX Ethernet Port Module LEDs Label Color State Description Green On steadily Port module is functioning normally. OK/FAIL On steadily Port module has failed. Link (top or Green On steadily Link is active. left of each port) No link.

  • Page 6: Holding A Card

    SRX 5600 and SRX 5800 Services Gateway Flex IOC and Port Module Installation Instructions Figure 3: Card Edges Holding a Card When you carry a card, you can hold it either vertically or horizontally. NOTE: A card weighs up to 13.1 lb (5.9 kg). Be prepared to accept the full weight of the card as you lift it.
  • Page 7 Handling and Storing Cards You can rest the faceplate of the card against your body as you carry it. As you carry the card, do not bump it against anything. Card components are fragile. Never hold or grasp the card anywhere except the places that this document indicates. In particular, never grasp the connector edge, especially at the power connector in the corner where the connector and bottom edges meet (see Figure 4 on page 7).

  • Page 8: Storing A Card

    SRX 5600 and SRX 5800 Services Gateway Flex IOC and Port Module Installation Instructions Never carry the card by the faceplate with only one hand. Do not rest any edge of a card directly against a hard surface (see Figure 5 on page Do not stack cards.

  • Page 9: Replacing Flex Iocs And Port Modules

    Replacing Flex IOCs and Port Modules If you must insert the card into a bag by yourself, first lay the card horizontally on a flat, stable surface, sheet metal side down. Orient the card with the faceplate facing you. Carefully insert the card connector edge into the opening of the bag, and pull the bag toward you to cover the card.
  • Page 10 SRX 5600 and SRX 5800 Services Gateway Flex IOC and Port Module Installation Instructions Simultaneously turn both of the ejector handles counterclockwise to unseat the flex IOC. Grasp the handles and slide the flex IOC straight out of the card cage halfway.

  • Page 11: Installing A Flex Ioc

    Replacing Flex IOCs and Port Modules Installing a Flex IOC NOTE: Your services gateway must be running JUNOS version 9.5R1 or later in order to recognize flex IOCs and port modules. To install a flex IOC (see Figure 7 on page 11): Attach an electrostatic discharge (ESD) grounding strap to your bare wrist and connect the strap to one of the ESD points on the chassis.

  • Page 12: Removing A Port Module

    SRX 5600 and SRX 5800 Services Gateway Flex IOC and Port Module Installation Instructions For more information about the command, see the JUNOS System Basics and Services Command Reference. CAUTION: After the LED turns green, wait at least 30 seconds before removing the IOC again, removing an IOC from a different slot, or inserting an IOC in a different slot.
  • Page 13 Replacing Flex IOCs and Port Modules CAUTION: Do not leave a fiber-optic transceiver uncovered except when inserting or removing cable. The safety cap keeps the port clean and prevents accidental exposure to laser light. CAUTION: Avoid bending fiber-optic cable beyond its minimum bend radius. An arc smaller than a few inches in diameter can damage the cable and cause problems that are difficult to diagnose.

  • Page 14: Installing A Port Module

    SRX 5600 and SRX 5800 Services Gateway Flex IOC and Port Module Installation Instructions Installing a Port Module To install a port module (see Figure 9 on page 14): Attach an electrostatic discharge (ESD) grounding strap to your bare wrist and connect the strap to one of the ESD points on the chassis.
  • Page 15 Replacing Flex IOCs and Port Modules Insert the appropriate cables into the cable connector ports on each port module. Secure the cables so that they are not supporting their own weight. Place excess cable out of the way in a neatly coiled loop, using the cable management system. Placing fasteners on a loop helps to maintain its shape.

  • Page 16: Preventing Electrostatic Discharge Damage

    SRX 5600 and SRX 5800 Services Gateway Flex IOC and Port Module Installation Instructions Preventing Electrostatic Discharge Damage Many services gateway hardware components are sensitive to damage from static electricity. Some components can be impaired by voltages as low as 30 V. You can easily generate potentially damaging static voltages whenever you handle plastic or foam packing material or if you move components across plastic or carpets.
  • Page 17 Electrostatic Discharge Point Figure 11: Front View of a Fully Configured SRX 5600 Services Gateway Chassis Electrostatic Discharge Point...
  • Page 18 SRX 5600 and SRX 5800 Services Gateway Flex IOC and Port Module Installation Instructions Figure 12: Front View of a Fully Configured SRX 5800 Services Gateway Chassis Electrostatic Discharge Point...

  • Page 19: List Of Technical Publications

    List of Technical Publications List of Technical Publications Table 5 on page 19 lists the hardware guides and release notes for Juniper Networks SRX–series services gateways and describes the contents of each document. All documents are available at http://www.juniper.net/techpubs/ Table 5: Technical Documentation for Supported Devices...

  • Page 20: Revision History

    Products made or sold by Juniper Networks or components thereof might be covered by one or more of the following patents that are owned by or licensed to Juniper Networks: U.S. Patent Nos. 5,473,599, 5,905,725, 5,909,440, 6,192,051, 6,333,650, 6,359,479, 6,406,312, 6,429,706, 6,459,579, 6,493,347, 6,538,518, 6,538,899, 6,552,918, 6,567,902, 6,578,186, and 6,590,785.
