Chapter 1
Embedded USB 2.0 Host Controller
- One EHCI USB 2.0 and four UHCI USB 1.1 Controllers support total 8 USB 2.0/1.1
Ports
- Support USB 2.0 High-Speed Device @480 Mb/s Transfer Rates
- Optional USB adapters for additional USB 2.0/1.1 ports
Fast Ethernet/Home Networking Controller
- On-board LAN chip RTL8101L supports 10/100 Mb Fast Ethernet
On board Super I/O Controller
- ITE 8712 LPC I/O with system monitors hardware
- Two UARTs support serial ports and IR function (up to 115.2Kbps) for HPSIR and
ASKIR
- One SPP/ECP/EPP parallel port
- One floppy disk drive connector supports up to 2.88MB
Boot-Block Flash ROM
- Award system BIOS support PnP, APM, DMI, ACPI, & Multi-device booting
features
Embedded system monitoring
- 8 external voltage inputs
- 2 temperatures sensing for CPU and system
- 3 Fan speed (CPU, system and Case) monitoring
