Download this manual See also: Parts & Maintenance Manual, Operating Manual
Parts & Maintenance Manual
Underhållshandbok och reservdelslista
Lightweight Fairway Mower with ROPS
Lättviktsklipparen Fairway med ROPS
67978 – LF 550
67979 – LF 550
67981 – LF 570
67982 – LF 570
67980 – LF 550
67983 – LF 570
WARNING: If incorrectly used this machine can cause severe injury.
Those who use and maintain this machine should be trained in its
proper use, warned of its dangers and should read the entire manual
before attempting to set up, operate, adjust or service the machine.
VARNING:
Om maskinen inte används på korrekt sätt kan den orsaka
allvarliga skador. De som använder och sköter den här maskinen
måste få utbildning om korrekt användning och varnas om farorna.
Vidare måste de läsa hela förarhandboken innan de försöker ställa in,
använda, justera eller underhålla maskinen.
SE
GB
Sweden
United
Kingdom
™
, Kubota V1505-E3B, 5 Gang 2WD
™
, Kubota V1505-E3B, 5 Gang 4WD
, Kubota V1505-E3B, 5 Gang 2WD
™
, Kubota V1505-E3B, 5 Gang 4WD
™
Turbo, Kubota V1505-T-E3B, 5 Gang 4WD
™
™
Turbo, Kubota V1505-T-E3B, 5 Gang 4WD
WARNING
VARNING
4229041-SE-Rev A
When Performance Matters.
™
