Lightweight Fairway Mower
67978 – LF 550
67979 – LF 550
67981 – LF 570
67982 – LF 570
67980 – LF 550
67983 – LF 570
WARNING: If incorrectly used this machine can cause severe
injury. Those who use and maintain this machine should be
trained in its proper use, warned of its dangers and should
read the entire manual before attempting to set up, operate,
adjust or service the machine.
GB
United
Kingdom
™
, 2WD
™
, 4WD
™
, 2WD
™
, 4WD
™
Turbo, 4WD
™
Turbo, 4WD
WARNING
4229042-GB-Rev B
Dealer
This manual is designed to assist dealer
personnel with the proper set up and
preparation of the equipment prior to
delivery to the customer. You may wish to
keep a copy in your customer file.
Do Not Remove the Safety & Operation
Manual or Parts & Maintenance Manual
from the mower.
For additional information not included in
this manual, refer to your office copy of:
• The Safety & Operation Manual
• The Parts & Maintenance Manual
Use the pre-delivery checklist provided on
the inside back cover of this manual. You
may wish to provide a copy to the
customer upon delivery of the unit.
