Maintenance & Care
Replace drive belt
1. Follow steps 1-4 of previous section, "Clean
Drive Belt Motor Shaft
and replace rotating floor brush".
3.
4.
2. Check drive belt carefully for wear, cuts and
stressed areas. If the drive belt appears worn,
you will need to replace it.
3. Remove brush, then grasp old drive belt and
remove from motor shaft. Discard old drive belt.
4. Loop new drive belt over motor shaft and
stretch other end over floor brush in the space
provided between the bristles.
5. Place ends of floor brush down into
slots on sides as shown.
6. Turn floor brush by hand several times in the
direction of the motor shaft. If properly installed,
drive belt will align itself on floor brush.
5. 7.
7. Replace brush cover and five screws.
