Bissell POWERFORCE COMPACT 1520 SERIES User Manual page 11

Maintenance & Care
Clean and replace rotating floor brush
You should check your cleaner's rotating floor
brush and drive belt regularly for wear or
damage. You should also clean the brush and
brush ends by removing string, hair and carpet
fibers. These can wrap around the brush and
hamper its ability to effectively clean your
carpet. Also, remove any debris that has
accumulated under the brush cover.
1. Turn off vacuum and unplug from electrical
outlet.
2. Place vacuum upside down with brush roll
facing upwards.
3. Remove five screws as shown with a small
Phillips screwdriver.
4. Lift off brush cover.
5. Grasp floor brush at both ends and lift out.
6. Clean strings, hair and other debris from floor
brush, motor pulley, and drive belt.
7. Check floor brush for worn areas and replace
if needed.
8. Check air passageway for obstructions.
Recline the handle to the floor, separate the hose
from the hose wand base to look through the
hose for clogs. Remove debris from this area.
9. When finished cleaning, reposition floor brush
and drive belt. Turn floor brush by hand several
times in the direction of the motor to align the
belt on the floor brush. Then replace the brush
cover and screws.
3.
Five Screws
5.
9.
www.BISSELL.com
4.
Motor Shaft
8.
Air Passageway
11
