DETERMINE INSTALLATION HEIGHT
Recommended
*9-ft. to 10-ft. ceilings may be 25-1/2" to 30" clearance.
of the hood must be at least 25-1/2". The 30" recommended
sional Range or Rangetop, installation clearance must be
at least 30".
sure standard is applicable.
DUCT COVER DIMENSIONS
A
ZV1050
11-1/2"
ZX1059
19"
ZX10510
25"
Design Information
*30"
36" Min.
B
12"
20"
26"
DUCT COVER ACCESSORIES
Order the accessory at the same time as the vent hood
Cover Accessory.
Actual
7'11"
8'0"
8'1"
8'2"
8'3"
8'4"
8'5"
8'6"
8'7"
8'8"
8'9"
8'10"
8'11"
-
9'0"
9'1"
-
9'2"
9'3"
9'4"
9'5"
9'6"
9'7"
9'8"
9'9"
9'10"
9'11"
10'0"
4
Installation Heights
*Possible Hood
29"
Supplied
30"
Supplied
30"
Supplied
25-1/2" to 30"
ZX1059SFSS
25-1/2" to 30"
ZX1059SFSS
25-1/2" to 30"
ZX1059SFSS
25-1/2" to 30"
ZX1059SFSS
25-1/2" to 30"
ZX1059SFSS
25-1/2" to 30"
ZX1059SFSS
25-1/2" to 30"
ZX1059SFSS
25-1/2" to 30"
ZX1059SFSS
25-1/2" to 30"
ZX1059SFSS
25-1/2" to 30"
ZX1059SFSS
25-1/2" to 30"
ZX1059SFSS
25-1/2" to 30"
ZX10510SFSS
25-1/2" to 30"
ZX10510SFSS
25-1/2" to 30"
ZX10510SFSS
25-1/2" to 30"
ZX10510SFSS
25-1/2" to 30"
ZX10510SFSS
25-1/2" to 30"
ZX10510SFSS
25-1/2" to 30"
ZX10510SFSS
25-1/2" to 30"
ZX10510SFSS
25-1/2" to 30"
ZX10510SFSS
25-1/2" to 30"
ZX10510SFSS
25-1/2" to 30"
ZX10510SFSS
25-1/2" to 30"
ZX10510SFSS
