OREGON
COAL EFFECT GAS FIRE
INSTALLATION, SERVICING
AND USER INSTRUCTIONS
All instructions must be handed to user for safekeeping
Revision A - 05/03
Country(s) of destination - GB/IE
Focal Point Fires plc, Avon Trading Park, Christchurch, Dorset BH23 2BT
Tel: 01202 499330
Fax: 01202 499326
www.focalpointfires.co.uk
e-mail: sales@focalpointfires.co.uk
