AIRFLAME EXCEL MK.3
remote control
This Appliance is for use in the United Kingdom (GB) and the
9860378/03
AF 16NV RC
AC 16NV RC
AF 16XL RC
AC 16XL RC
USER MANUAL
Patent applied for
Republic of Ireland (IE) only.
Please leave these Instructions with the user
9500370
9500371
9500372
9500373
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wonderfire airflame excel mk.3 AC 16XL RC
Summary of Contents for Wonderfire airflame excel mk.3 AC 16XL RC
- Page 1 AIRFLAME EXCEL MK.3 remote control AF 16NV RC 9500370 AC 16NV RC 9500371 AF 16XL RC 9500372 AC 16XL RC 9500373 USER MANUAL Patent applied for This Appliance is for use in the United Kingdom (GB) and the Republic of Ireland (IE) only. Please leave these Instructions with the user 9860378/03...
- Page 2 PLEASE NOTE 1. The Wonderfire Airflame Excel is to be used only with the type of gas for which it was supplied. Never attempt to use the appliance with other gas types. 2. Always use a fireguard complying with BS6539 or BS6778 for the protection of the young, elderly, or infirm.
- Page 3 Ventilation requirements Note: see convector instructions if being installed within a Wonderfire convector box for ventilation requirements. A permanent ventilation grille of fixed design and having a minimum free area of 100cm must be fitted with direct access to outside air to room.
- Page 4 Operation of the fire – continued this position (keeping it depressed) for ten seconds to allow the flame supervision device to establish. Observe if it is alight by looking through the slots to the left hand end of the front coals.
- Page 5 Please note: We do not recommend pointing the remote control handset at any domestic animal or operating the device within one meter of the animal’s ear. Research has shown that a domestic cat or dog will not suffer any pain or hearing damage but the ultrasonic transmission signal may disrupt its normal behaviour.
- Page 6 For fires fitted with Aeration Control To operate the aeration control system, the following procedure should be followed: • Allow the appliance to warm up, (for at least fifteen minutes) in the fully aerated position, with the control lever pushed in to the locked position –...
- Page 7 Placing the fuel matrix Position fuel matrix on top of the burner as shown in figure 9. The rear face of the burner should locate into two cut-outs on the top face of the rear legs. Ensure that the matrix sits flatly on the top of the burner.
- Page 8 Placing the dress coals – continued Next, take both finger coals and place one at each end of the front row of coals as shown in figure 12, again making sure that they bridge across from the front coal to the matrix. Figure 12 Now take six random shaped coals and position as shown in figure 13.
-
Page 9: Spare Parts
Figure 14a SPARE PARTS The ceramic fuel bed items are customer replaceable. When ordering please quote the number shown below. Only use genuine Wonderfire replacement parts in the correct quantity, and follow the instructions carefully. Description Part Number... -
Page 10: Legal Requirement
If you require your fire to be serviced, or in the unlikely event that it should require repair due to a manufacturing defect then call Wonderfire service department on 0121 386 6203, quoting your details listed below. From the Republic of Ireland call 00 44 373 8111 for all enquiries.
