Wonderfire Sonnet Powerflue BR00290 Installer's Manual

Rear fan flued inset gas fire
Hide thumbs Also See for Sonnet Powerflue BR00290:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
I
N
S
Please keep in a safe place for future reference
T
A
L
L
MODEL BR00290
S O N N E T
S O N N E T
S O N N E T
S O N N E T
P o w e r f l u e
P o w e r f l u e
P o w e r f l u e
P o w e r f l u e
R e a r F a n F l u e d I n s e t
G a s F i r e
E
R
G
For
U
I
D
E
600B 376/02

Advertisement

Table of Contents
loading

Related Manuals for Wonderfire Sonnet Powerflue BR00290

Summary of Contents for Wonderfire Sonnet Powerflue BR00290

  • Page 1 MODEL BR00290 S O N N E T S O N N E T S O N N E T S O N N E T P o w e r f l u e P o w e r f l u e P o w e r f l u e P o w e r f l u e R e a r F a n F l u e d I n s e t...
  • Page 2 (GB) and the Republic of Ireland (IE) only. This Installer Guide gives sufficient details to enable the appliance to be installed and maintained. If further information is required our Wonderfire service department will be pleased to help. Please phone us on 0121 386 6203...

  • Page 3: Table Of Contents

    PART 1: APPLIANCE DATA ................................4 PART2: GENERAL INSTALLATION REQUIREMENTS...................... 5 PART 3: UNPACKING..................................9 PART 4: PREPARING FOR INSTALLATION......................... 10 PART 5: WALL PREPARATION..............................10 General ......................................10 Brick, Stone Etc. Building. Main Case In Front Of Wall ......................10 Brick, Stone Etc.

  • Page 4: Part 1: Appliance Data

    PART 1: APPLIANCE DATA This product uses fuel effect pieces, burner back wall and gaskets containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres. Excessive exposure to these materials may cause temporary irritation to eyes, skin and respiratory tract. Consequently, it makes sense to take care when handling these articles to ensure that the release of dust is kept to a minimum.

  • Page 5: Part2: General Installation Requirements

    PART2: GENERAL INSTALLATION REQUIREMENTS The installation must be in accordance with these instructions. For the user’s protection, in the United Kingdom it is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Gas Safety (Installation and Use) Regulations.
  • Page 6 materials must be removed from the area covered by the metal outer surround of the appliance. We suggest that the actual surround is used as a template to mark the area for combustible cladding removal. The appliance can be fitted to a purpose made proprietary class “O” 150°C surround. The opening in the surround or wall recess for the fire box must be within the limits shown in figure 1.
  • Page 7 The flue terminal should be located so that the wind can blow freely across it at all times and where any blockage due to leaves, snow, etc. is unlikely. The minimum allowable distances from the terminal are shown in figure 2 and the table. Note: The distances are from the edge of the vertical exit slots in the terminal not from the edges of the rectangular box (See figure 2).
  • Page 8 470mm 600mm 325mm 525mm 350mm 235mm 125mm 475mm 53mm 550mm 600mm max. (Flue tube uncut) 150mm min. N (Fan box projection) 205mm when sited outside wall 55mm when recessed in outer wall 285mm R (Flue tube diameter) 125mm S (Terminal guard projection) 305mm 355mm V (Recess width)

  • Page 9: Part 3: Unpacking

    PART 3: UNPACKING Figure 4 Pack contents The pack contains: Nut & olive for 8mm inlet pipe Burner & firebox unit with attached Retention kit ( 4 wall plugs, 4 eye bolts, 2 tension Rockwool jacket adjusters and two cable assemblies). Fan box assembly Wall plugs Flue duct...

  • Page 10: Part 4: Preparing For Installation

    PART 4: PREPARING FOR INSTALLATION Check ignition spark Before attempting to install, it is worth checking that the piezo electric spark ignition system operates satisfactorily. To initiate the spark, depress the control knob and while keeping it depressed, turn anticlockwise through approximately 60° to the “PILOT/IGN” position. A spark should track from the electrode pin to the thermocouple tip.

  • Page 11: Brick, Stone Etc. Building. Main Case Recessed Into Wall

    Brick, Stone Etc. Building. Main Case Recessed Into Wall (Figure 8) This installation has the fire box recessed into the inner wall of the building. The front flanges of the fire box and the appliance metal decorative surround will abut the front surface of the wall. The non-combustible hearth must project at least 345mm in front of the convection box front flanges and be at least 625mm wide (Figure 1).

  • Page 12: Wall Preparation For Flue Tube

    Wall preparation for flue tube. The flue must be installed so that it is at right angles to the back panel of the fire all round the flue circumference. The fire itself should be fitted vertically against a flat wall. Where this is difficult to achieve due to building inaccuracies care should be taken to ensure that the back of the fire is not stressed in any way due to distortion of the assembly when tightening the fixing screws.

  • Page 13: Fixing The Appliance In Position

    The area immediately behind the firebox must be separated from the combustible elements of the inner wall by 25mm thickness of non combustible material. This can consist of the usual 13mm plasterboard wall lining plus 12mm of “Superlux” or similar non-combustible material - see figure 12. Fixing the appliance in position There are two methods of fixing that may be used: 1.

  • Page 14: Part 6: Installation Of Electrics, Firebox And Fan Box

    PART 6: INSTALLATION OF ELECTRICS, FIREBOX AND FAN BOX Important : Under no circumstances should the electrical loom be fed between the inner and outer sections of the flue tube. Obtain the wiring loom and lay the loom through hole in the wall ensuring that the end with two connectors and earthing tags is outside the building.

  • Page 15: Securing Firebox To Wall - Cable Retention

    Securing firebox to wall - cable retention Assemble retention cables into firebox. Insert cables into cable anchor points in upper rear of firebox and then tape together adjoining edges of the jacket as shown in figure 16. Offer the firebox up to the wall and feed the retention cable through the installed eyebolts.

  • Page 16: Fan Box Installation

    Fan box installation Before installation can proceed it will be necessary to remove the fan unit from the fan box. Remove the 2 cover retaining screws and withdraw the fan unit. See figure 19 Checking inside for any loose unwanted packaging For transit purposes the weather shield is supplied as a loose part.

  • Page 17: Electrical Installation

    Electrical installation Install a power supply at a switched fuse having a minimum separation of 3mm at all poles. The spur should be readily accessible to the user, easily identifiable and preferably sited adjacent to the appliance. It should only connect this appliance.

  • Page 18: Electrical Test

    Electrical test Fig. 29 Switch on power supply to the appliance. The red indicator light at the left side of the burner should be on. Press and hold in the “on” switch at the front of the burner. Within a few seconds, the Fan motor should start and the indicator light should go out.

  • Page 19: Part 7: Gas Supply Installation

    PART 7: GAS SUPPLY INSTALLATION Connect the supply line to the appliance. Unless the supply pipe connection is from the left front side, the supply pipe will have to be formed to avoid various components below the burner. If a visible connection is to be made, it will be necessary to cut a small notch in the side of the fret to allow the gas pipe to pass.

  • Page 20: Check Reference Pressure

    Check Reference Pressure . The appliance is pre-set to give the correct setting pressure as shown in part 1 of this manual. No adjustment is necessary. Check the burner pressure by fitting a pressure gauge at the test point. The test point is on the pipe situated below the bottom right corner of the burner unit (See figure 32).

  • Page 21: Part 8: Fitting The Ceramics

    PART 8: FITTING THE CERAMICS With its feather Install the 9 loose edge at the top, place the coals as follows. The smooth surfaces of the ceramic rear wall into the coals should be at the channel at the back of the firebox.

  • Page 22: Part 9: Checks

    PART 9: CHECKS Recheck Control Settings Now that all the ceramic fuel effects are in position, the control operation must be fully rechecked. • Make sure that the isolating valve at the inlet elbow is open and that the electrical power supply is on (the indicator light should glow).

  • Page 23: Flame Supervision & Spillage Monitoring System

    This monitoring system must not be adjusted, bypassed or put out of operation. This monitoring system, or any of its parts, must only be exchanged using Wonderfire Authorised parts.

  • Page 24: Part 11: Servicing Parts And Replacement

    PART 11: SERVICING PARTS AND REPLACEMENT • Always turn off the gas and isolate the electric supply before commencing any servicing and make sure that the appliance is cold. (The inlet elbow for this appliance incorporates an isolating valve). • This product uses fuel effect pieces, burner compartment rear wall and gaskets containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres.

  • Page 25: To Remove The Pilot Unit

    To Remove The Pilot Unit • Remove the 9 loose coals, front base coal, rear base coal and ceramic back wall. • Remove the front cover castings. • Support the inlet isolating elbow to avoid straining the pipework and disconnect the appliance from the elbow. •...

  • Page 26: To Remove The Main Burner Injector

    To Remove The Main Burner Injector • Detach the burner unit from the fire box as described above. • Disconnect the main burner pipe from the elbow injector. If necessary, loosen the pipe at the gas tap end to swing the pipe clear of the injector. •...

  • Page 27: To Remove The Pressure Switch

    To remove the pressure switch • Access to the pressure switch is gained by first removing the fan. (See preceding text - fan removal procedure). • Disconnect the wiring loom to pressure switch connector. • Remove the two pressure switch fixing screws, and carefully prise free the two rubber sensing tubes whilst withdrawing the pressure switch from the fan box.

  • Page 28: Short List Of Spares

    Short List Of Spares Key No. Description No. off Part No. Air pressure switch 567359 Electrical control unit 567369 Injector Bray cat 18 size 360 - For Natural Gas Appliances 541609 Injector Bray cat 18 size 170 - For Propane Appliances 571709 Gas tap &...
  • Page 29 All Wonderfire appliances are CE Approved and designed to meet the appropriate British Standards. All Wonderfire appliances are manufactured to the highest standards of quality and excellence under the BS EN ISO 9001 quality system accepted by the British Standards Institute.
