Wonderfire AF 16 NV Installer And Owner Manual

Airflame series
Hide thumbs Also See for AF 16 NV:
Table of Contents

Advertisement

Quick Links

INSTALLER AND OWNER GUIDE
MODEL
AF 16 NV
AC 16 NV
AF 18 XL
AC 18 XL
MODEL
AF 16 NV 5" Leg
We trust that this guide gives
sufficient details to enable this
appliance to be installed, operated
and maintained satisfactorily.
However, if further information is
required, our
Wonderfire Technical Helpline will
be pleased to help.
Telephone 0844 8711 565. (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone 0044 844 8711 565.
INSTALLER: Please leave this guide with the owner
©
Baxi Heating U.K. Limited 2008.
AIRFLAME
PRODUCT CODE
9500298 (coal)
0505411 (log)
9500296 (coal)
0505511 (log)
0503611 (pebble)
9500360 (coal)
9500361 (coal)
PRODUCT CODE
9505298 (coal)
MODEL
AF 16 NV RC
AC 16 NV RC
AF 18 XL RC
AC 18 XL RC
MODEL
AC 16 NV TC
5129826/03
PRODUCT CODE
0505601 (coal)
0505611 (log)
0505701 (coal)
0505711 (log)
0505301 (coal)
0505901 (coal)
PRODUCT CODE
05036T1 (coal)
0505811 (log)
