3002616/05
OWNER'S GUIDE
Eclipse
INSET LIVE FUEL EFFECT GAS FIRE
Model 654
(GC No. 32-032-48)
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20)
WHEN CONVERTED USING CONVERSION KIT NO. 0595201 THIS
APPLIANCE IS FOR USE WITH PROPANE GAS (G31)
THIS APPLIANCE IS FOR USE IN THE UNITED KINGDOM (GB) AND THE
REPUBLIC OF IRELAND (IE) ONLY.
This guide is intended to help you care for your Wonderfire gas fire. Please read
thoroughly before using and keep for future reference
We trust that this guide gives sufficient details to enable your appliance to be operated
and maintained satisfactorily. However, if further information is required, our
Wonderfire Technical Helpline will be pleased to help.
Please telephone 08706 061 065 (National call rates apply in the United Kingdom).
This guide to be left with the owner
© Wonderfire

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eclipse 654 and is the answer not in the manual?

Questions and answers

Related Manuals for Wonderfire Eclipse 654

Summary of Contents for Wonderfire Eclipse 654

  • Page 1 THIS APPLIANCE IS FOR USE IN THE UNITED KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE) ONLY. This guide is intended to help you care for your Wonderfire gas fire. Please read thoroughly before using and keep for future reference We trust that this guide gives sufficient details to enable your appliance to be operated and maintained satisfactorily.
  • Page 2 BS EN ISO 9001 quality system accepted by the British Standards Institute. The Highest Standards Wonderfire is a member of the Society of British Gas Industries which works to ensure high standards of safety, quality and performance. Careful Installation Wonderfire is a CORGI registered company.

  • Page 3: Table Of Contents

    OWNER’S GUIDE LIST OF CONTENTS SAFETY ........................... 4 APPLIANCE DIMENSIONS..................6 GAS CONSUMPTION ....................6 OPERATING YOUR FIRE ................... 7 The Oxysafe flame sensing & flue blockage safety system......... 7 To light the fire......................7 Lighting with a taper ..................... 9 To turn off ........................

  • Page 4: Safety

    OWNER’S GUIDE S A F E T Y IF YOU SMELL GAS DON’T SMOKE EXTINGUISH ALL NAKED FLAMES DON’T TURN ELECTRICAL SWITCHES ON OR OFF TURN OFF THE GAS SUPPLY AT THE METER OPEN DOORS AND WINDOWS TO GET RID OF THE GAS IMMEDIATELY CALL THE GAS EMERGENCY SERVICE - SEE YOUR LOCAL TELEPHONE DIRECTORY Do have the fire installed by a competent person.
  • Page 5 OWNER’S GUIDE Do provide a minimum clearance as shown below above the hearth to any shelf made of wood or other combustible material. Please bear this in mind if you are making any alterations to the room • For a shelf up to 150mm deep Minimum height = 700mm.

  • Page 6: Appliance Dimensions

    OWNER’S GUIDE A P P L I A N C E D I M E N S I O N S Figure 1. Appliance dimensions G A S C O N S U M P T I O N Model 654 Has a maximum natural gas input of 5.1kW (Gross) Has a maximum natural gas output of 2.6kW (Gross) Has a minimum natural gas input of 2.2kW (Gross)

  • Page 7: Operating Your Fire

    OWNER’S GUIDE O P E R A T I N G Y O U R F I R E PLEASE NOTE When operating your fire for the first time, some vapours may be given off which may cause a slight odour and could possibly set off any smoke alarms in the immediate vicinity.
  • Page 8 OWNER’S GUIDE If the pilot does not ignite quickly repeat the procedure. If after 10 seconds pilot ignition has not occurred, turn the control knob back to the “Off” position, wait for 3 minutes and then repeat the ignition procedure. When the pilot is alight and stable, partially depress the knob and turn to “LOW”.

  • Page 9: Lighting With A Taper

    OWNER’S GUIDE Lighting with a taper See figure 4. In the unlikely event of failure of the ignition spark, the pilot can be lit by a taper or long spill. Insert the taper or spill into the gap underneath the pebble at the extreme left hand side of the fuel bed.

  • Page 10: Cleaning

    OWNER’S GUIDE C L E A N I N G To maintain the high performance and quality finish of your fire please follow these guidelines: • Before attempting to clean the fire, please remember to turn off the fire and wait for the appliance to cool completely.

  • Page 11: Ceramic Burner

    OWNER’S GUIDE Ceramic burner Remove any deposits of soot or other foreign matter from the solid areas of the burner with a dry soft brush. Be careful not to brush any particles into the open slots. Remove any particles from the slots with a vacuum cleaner fitted with a soft brush attachment. Do not poke wire, etc.
  • Page 12 OWNER’S GUIDE The position of the pebbles is important. Do not alter the position of the pebbles from that shown in this section of the owner’s guide. There are four pebbles numbered ‘1’ on the underside. Locate these onto the pebble base at the ends of the outer Figure 8 Pebble number ‘1’...
  • Page 13 OWNER’S GUIDE Pebble ‘4’ has a location peg on the underside. The peg has a chamfer on one side. The chamfer must face the burner. Locate pebble ‘4’ onto the right hand side of the pebble base. It should bridge the gap between the front and rear halves of the pebble base.

  • Page 14: Maintenance

    We recommend that all gas appliances and their flues, wherever situated, are checked annually. Servicing • Servicing can be carried out either by a Wonderfire Service engineer or a CORGI registered installer. • If you require your fire to be serviced, please contact Wonderfire Service on...
  • Page 15 OWNER’S GUIDE • If you wish to replace any of the owner replaceable parts listed below, please contact Wonderfire Spares on 08706 000 454 for your nearest stockist of these parts. Description Part No. Base pebble set – Front and Rear...
