Wonderfire airflame excel mk.3 ac 18xl User Manual
Hide thumbs
Also See for airflame excel mk.3 ac 18xl:
- Installer and owner manual (56 pages) ,
- Installer and owner manual (60 pages) ,
- Installation & servicing manual (13 pages)
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wonderfire airflame excel mk.3 ac 18xl
Summary of Contents for Wonderfire airflame excel mk.3 ac 18xl
- Page 1 AIRFLAME EXCEL MK.3 AF 18XL 9500360 AC 18XL 9500361 USER MANUAL Patent applied for Please leave these Instructions with the user This appliance is for use in the United Kingdom (GB) and the Republic of Ireland (IE) only. 9860370/03...
- Page 2 PLEASE NOTE 1. The Wonderfire Airflame Excel is to be used only with the type of gas for which it was supplied. Never attempt to use the appliance with other gas types. 2. Always use a fireguard complying with BS6539 or BS6778 for the protection of the young, elderly, or infirm.
- Page 3 Ventilation requirements Note: see convector instructions if being installed within a Wonderfire convector box for ventilation requirements. A permanent ventilation grille Figure 2 of fixed design and having a minimum free area of 100cm must be fitted with direct access to outside air to room.
- Page 4 In order to change from one setting to another depress the control knob slightly and turn the knob to the required position. Alternatively, if a setting between LOW and HIGH is required, then the control knob may be turned to this position. Note: We recommend you use the appliance at a low setting for the first few hours of use to reduce the thermal cracking of the surface of the burner.
- Page 5 CLEANING Note: Before attempting any of the following ensure that the fire has been allowed to cool completely. Note: Some discoloration of the coals is normal. The cast parts of the fire should be carefully cleaned with a lint free damp cloth. On no account should any metal polish or similar be used as this may prove harmful to the surface.
- Page 6 Placing the dress coals The dress coals consist of: • 6 x Finger coals • 18 x Random cut coals Keep the different types of coals separate. Begin the coal build by placing six random shaped coals as shown in figure 6, ensuring that they Figure 6 form a bridge between the front coal and the coal matrix.
- Page 7 ‘c’) also shown in figure 10. Figure 10 SPARE PARTS The ceramic fuel bed items are customer replaceable. When ordering please quote the number shown below. Only use genuine Wonderfire replacement parts in the correct quantity, and follow the instructions carefully. Description Part Number...
- Page 8 If you require your fire to be serviced, or in the unlikely event that it should require repair due to a manufacturing defect then call Wonderfire service department on 0121 386 203, quoting your details listed below. From the Republic of Ireland call 00 44 373 8111 for all enquiries.
