- Page 1 Inset Live fuel Effect Engine for use with The Gallery Fire Collection Model BR218C1 INSTALLATION AND SERVICING INSTRUCTIONS Please keep in a safe place for future reference 600B654/01...
- Page 2 P l e a s e l e a v e t h i s I n s t a l l e r G u i d e w i t h t h e u s e r As supplied, this appliance is for use with natural gas (G20) When converted using conversion kit no.
-
Page 3: Table Of Contents
CONTENTS Installation Notes ............................ 4 Technical specification ........................... 5 Pack Contents ............................5 General Installation Requirements ......................6 • Fire Surround............................. 7 • Hearth Requirememnts ........................7 Installation and Commissioning Instructions ..................7 • Fireplace, flue and Ventilation Details ..................... 7 •... -
Page 4: Installation Notes
INSTALLATION NOTES In your own interest and for safety, in the United Kingdom, it is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Gas Safety (Installation & Use) Regulations and Amendments. Failure to install the appliance correctly could lead to prosecution. -
Page 5: Technical Specification
should the A.S.D be altered or bypassed in any way. Only a genuine manufacturers replacement part should be fitted. The individual A.S.D components are not replaceable. Note that soft wall coverings (e.g. embossed vinyl, etc.) are easily affected by heat. They may scorch or become discoloured when close to a heating appliance. -
Page 6: General Installation Requirements
GENERAL INSTALLATION REQUIREMENTS This appliance is not suitable for installation in a room or internal space containing a bath or shower or where steam is regularly present or in a private garage. This appliance is suitable for the following: - A masonry chimney with a minimum diameter of 175mm (7”) free from any obstruction, and with any damper or restrictor plate in the chimney removed or secured, and having a minimum effective flue height of 3m (10ft). -
Page 7: Fire Surround
Fire Surround: This appliance may be installed with a surround with a minimum approved temperature rating of 150 degrees. The fire surround must be sealed to the wall. Hearth Requirements: The appliance must be mounted on a non- combustible hearth in accordance with Figure 4. The hearth material must have a minimum thickness of 12.5mm (1/2”). -
Page 8: Cable Retention
CABLE RETENTION Cables and eyebolts are supplied for the retention of the appliance. Ensure that the internal fireplace components are sufficiently sound to take the eyebolts and wall plugs. These should be fitted in accordance with Figure 6, using the wall plugs and a No.10 drill. Use only the fibre wall plugs supplied (or similar). -
Page 9: Check Reference Pressure
When the above checks have been completed partially depress the control knob and turn to “OFF”. If the above checks are satisfactory, continue with the installation. If not, check the control and ignition circuitry and components as described in the servicing section of this manual. CHECK REFERENCE PRESSURE The appliance is pre-set to give the correct heat input at the inlet pressure shown in the Technical Specification section of this manual. - Page 10 Place the rear base coal in the burner compartment behind the front coal. It should rest on the ledge at the back of the burner compartment and its rear face should touch the rear ceramic wall (See Figure 12 & 13).
-
Page 11: Full Operating Checks
FULL OPERATING CHECKS RECHECK CONTROL SETTINGS Now that all the ceramic fuel effects are in position, the control operation must be fully rechecked. Make sure that the isolating valve at the inlet elbow is open. Depress the control knob and turn anti-clockwise partially towards the “PILOT/IGN” position. A spark should be generated at the pilot while turning. -
Page 12: Final Review
FINAL REVIEW Place the front casting in position between the sides of the front surround. Place the bottom front cover casting below the front casting. Visually inspect the appliance. Clean off any marks incurred during installation. Hand these instructions and the user’s instructions to the customer. Advise the customer that the appliance will operate to its maximum potential if the flue is primed during the first 20 –... -
Page 13: Servicing
SERVICING & PARTS REPLACEMEMT Always turn off the gas supply before commencing any servicing. (The inlet elbow for this appliance incorporates an isolating valve). This product uses fuel effect pieces, burner compartment walls and gaskets containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres. -
Page 14: Gas Tap Removal
TO REMOVE THE GAS TAP/F.S.D • Remove the burner unit. • Disconnect the electrode lead from tab underneath the electrode. • Undo the thermocouple nut at the gas tap • Disconnect the inlet pipe at the tap end • Disconnect the pilot pipe at the tap end. •... -
Page 15: Short List Of Spares
SHORT LIST OF SPARES DESCRIPTION NO. OFF PART NO. Injector Bray cat 18 size 360 For Natural Gas Appliances 541069 Injector Bray cat 18 size 170 For Propane Appliances 571709 Gas tap & spark generator 569429 Spark generator 521069 Control knob 545979 Pilot unit For Natural Gas Appliances 540979... - Page 16 All Wonderfire appliances are CE Approved and designed to meet the appropriate British Standards. All Wonderfire appliances are manufactured to the highest standards of quality and excellence and are manufactured under a BS EN ISO 9001 quality system accepted by the British Standards Institute.
