5109304/03
OWNER GUIDE
Bauhaus
INSET LIVE FUEL EFFECT GAS FIRE
(G.C No. 32-032-60)
WITH
REMOTE CONTROL
(Manufacturer ref. 042)
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20)
WHEN CONVERTED USING CONVERSION KIT NO. 9500376 THIS
APPLIANCE IS FOR USE WITH PROPANE GAS (G31)
THIS APPLIANCE IS FOR USE IN THE UNITED KINGDOM (GB) AND THE
REPUBLIC OF IRELAND (IE) ONLY.
This guide is intended to help you care for your gas fire. Please read thoroughly before
using and keep for future reference.
Manufactured exclusively for British Gas & Scottish Gas by Valor Heating,
Wood Lane, Erdington, Birmingham B24 9QP
For Service Phone 0845 950 0400
This guide to be left with the owner
© Valor Heating

Advertisement

Table of Contents
loading

Related Manuals for Valor Bauhaus 32-032-60

Summary of Contents for Valor Bauhaus 32-032-60

  • Page 1 This guide is intended to help you care for your gas fire. Please read thoroughly before using and keep for future reference. Manufactured exclusively for British Gas & Scottish Gas by Valor Heating, Wood Lane, Erdington, Birmingham B24 9QP For Service Phone 0845 950 0400 This guide to be left with the owner ©...
  • Page 2 CORGI Registered Installer in accordance with our Installer Guide and should not be fitted directly on to a carpet. Valor Heating, Erdington, Birmingham B24 9QP www.valor.co.uk Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication.

  • Page 3: Table Of Contents

    OWNER GUIDE LIST OF CONTENTS Page No SAFETY ........................4 APPLIANCE DIMENSIONS & DATA..............6 OPERATING YOUR FIRE ..................7 The Oxysafe flame sensing & flue blockage safety system........7 Aeration Control......................8 To Light the Fire ......................9 CLEANING ......................11 Metal Parts........................11 Ceramic Coals ......................11 Burner ........................11 FUEL BED REFITTING ..................12 MAINTENANCE ....................15...

  • Page 4: Safety

    OWNER GUIDE S A F E T Y IF YOU SMELL GAS DON’T SMOKE EXTINGUISH ALL NAKED FLAMES DON’T TURN ELECTRICAL SWITCHES ON OR OFF TURN OFF THE GAS SUPPLY AT THE METER OPEN DOORS AND WINDOWS TO GET RID OF THE GAS IMMEDIATELY CALL THE GAS EMERGENCY SERVICE - SEE YOUR LOCAL TELEPHONE DIRECTORY Do have the fire installed by a competent person.
  • Page 5 OWNER GUIDE Do provide a suitable guard which complies with BS 8423 for the protection of young children, the elderly and the infirm. Such a guard is also recommended for the protection of pet animals. (Although this fire conforms to all the applicable standards, it is a heating appliance and certain parts of its surface will become hot.).

  • Page 6: Appliance Dimensions & Data

    OWNER GUIDE A P P L I A N C E D I M E N S I O N S & D A T A Figure 1 Appliance Dimensions The Natural Gas appliance Has a maximum gas input of 6.95kW (Gross) Has a minimum gas input of 4.8kW (Gross) Has a maximum gas output of 3.8kW (Gross) The LPG Gas appliance (Converted using kit no.

  • Page 7: Operating Your Fire

    OWNER GUIDE O P E R A T I N G Y O U R F I R E PLEASE NOTE When operating your fire for the first time, some vapours may be given off which may cause a slight odour and could possibly set off any smoke alarms in the immediate vicinity.

  • Page 8: Aeration Control

    OWNER GUIDE Aeration Control This appliance is fitted with a control which can be set to give a higher or lower supply of air to the burner (See 6 in figure 2). Maximum aeration is set by pushing the lever into the lower position as shown in figure 3.

  • Page 9: To Light The Fire

    OWNER GUIDE To Light the Fire The pilot must be lit using the pilot burner knob on the appliance (see figure 2). The heat and flame settings can be controlled by either using the main burner control knob on the appliance (see figure 2) or by using the remote control handset (See figure 4).
  • Page 10 OWNER GUIDE To turn back to pilot burner only setting Either • Press the “Lower” button on the remote control handset until the main burner goes out. • Turn the main burner control knob fully clockwise. • Turn the pilot burner control knob to the ignition position (2 in figure 2). Note that the remote control handset will not operate with the pilot burner set at this position.

  • Page 11: Cleaning

    OWNER GUIDE C L E A N I N G To maintain the high performance and quality finish of your fire please follow these guidelines: • Before attempting to clean the fire, please remember to turn off the fire and wait for the appliance to cool.

  • Page 12: Fuel Bed Refitting

    OWNER GUIDE F U E L B E D R E F I T T I N G 1. Position the front coal in front of the burner as shown in figure 5. The front coal should fit snugly between the burner and the two raised tabs on the front edge of the tray.
  • Page 13 OWNER GUIDE 3.2. Take four random coals and place along the front coal as shown in figure 8. Ensure that these coals bridge across from the front coal to the matrix. In order to get the best flame effect, it is important that the coals are evenly spaced, and have roughly equal gaps between them.
  • Page 14 OWNER GUIDE 3.5. NATURAL GAS MODELS ONLY: Take five random shaped coals and arrange as shown in figure 11. These coals should overlap the previous row by 5-10mm. In order to get the best flame effect, it is important that the coals are evenly spaced, and have roughly equal gaps between them.

  • Page 15: Maintenance

    OWNER GUIDE M A I N T E N A N C E Battery Replacement – Remote Control Receiver The remote control receiver requires four AA batteries. To ensure maximum battery life and optimum performance we recommend “Long Life” batteries. To replace the batteries: •...

  • Page 16: Regular Maintenance

    OWNER GUIDE Regular maintenance • In order to achieve and maintain high levels of personal safety and performance efficiency, it is essential that the opening at the back of the fire and the flue are kept clear of any form of obstruction. It is possible that deposits of mortar or soot could fall and accumulate causing the flue to be blocked or restricted and so preventing proper clearance of dangerous exhaust fumes.
