CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . 1
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-18
Step 1 - Provide Unit Support . . . . . . . . . . . . . . . . . . . 1
• ROOF CURB
Step 2 - Rig and Place Unit . . . . . . . . . . . . . . . . . . . . . 1
• POSITIONING
• ROOF MOUNT
Step 3 - Field Fabricate Ductwork . . . . . . . . . . . . . . . 8
Step 4 - Make Unit Duct Connections . . . . . . . . . . . 8
Step 5 - Trap Condensate Drain . . . . . . . . . . . . . . . . . 8
Step 6 - Make Electrical Connections . . . . . . . . . . . 9
• FIELD POWER SUPPLY
• FIELD CONTROL WIRING
Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Step 8 - Install Outdoor-Air Hood . . . . . . . . . . . . . . 12
Step 9 - Install All Accessories. . . . . . . . . . . . . . . . . 15
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-26
SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-34
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . .35,36
START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . . . . . . CL-1

SAFETY CONSIDERATIONS

Installation and servicing of air-conditioning equipment can
be hazardous due to system pressure and electrical compo-
nents. Only trained and qualified service personnel should in-
stall, repair, or service air-conditioning equipment.
Untrained personnel can perform basic maintenance func-
tions of cleaning coils and filters and replacing filters. All other
operations should be performed by trained service personnel.
When working on air-conditioning equipment, observe precau-
tions in the literature, tags and labels attached to the unit, and
other safety precautions that may apply.
Follow all safety codes. Wear safety glasses and work
gloves. Use quenching cloth for unbrazing operations. Have
fire extinguishers available for all brazing operations.
Before performing service or maintenance operations on
unit, turn off main power switch to unit. Electrical shock
could cause personal injury.
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 015-056
Book 1
Tab
1b
Installation, Start-Up and
Service Instructions
Page
Printed in U.S.A.
Single-Package Rooftop Units
IMPORTANT: Units have high ambient operating limits. If
limits are exceeded, the unit will automatically lock the
compressor out of operation. Manual reset will be required
to restart the compressor.

INSTALLATION

Step 1 - Provide Unit Support

ROOF CURB - Assemble and install accessory roof curb or
horizontal adapter roof curb in accordance with instructions
shipped with the curb or horizontal adapter. Accessory roof curb
and horizontal adapter roof curb and information required to
field fabricate a roof curb or horizontal adapter roof curb are
shown in Fig. 1 and 2. Install insulation, cant strips, roofing felt,
and counter flashing as shown. Ductwork can be secured to roof
curb or horizontal adapter roof curb before unit is set in place.
IMPORTANT: The gasketing of the unit to the roof curb or
horizontal adapter roof curb is critical for a watertight seal.
Install gasket supplied with the roof curb or horizontal
adapter roof curb as shown in Fig. 1 and 2. Im-
properly applied gasket can result in air leaks and poor unit
performance.
Curb or horizontal adapter roof curb should be level. This is
necessary to permit unit drain to function properly. Unit level-
ing tolerance is ± 5 mm per linear m (±
any direction. Refer to Accessory Roof Curb or Horizontal
Adapter Roof Curb Installation Instructions for additional in-
formation as required.
ALTERNATE UNIT SUPPORT - When the curb or hori-
zontal adapter roof curb cannot be used, support unit with
sleepers using unit curb or adapter roof curb support area. If
sleepers cannot be used, support long sides of unit with a mini-
mum of 3 equally spaced 100 mm x 100 mm (4 in. x 4 in.)
pads on each side.
Step 2 - Rig and Place Unit -
transportation damage. File any claim with transportation
agency. Keep unit upright, and do not drop. Use bumper boards
for spreader bars over unit to prevent sling or cable damage.
Rollers may be used to move unit across a roof. Level by using
unit frame as a reference; leveling tolerance is ± 5 mm per lin-
1
ear m (±
/
in. per linear ft) in any direction. See Fig. 3
16
for additional information. Unit rigging weight is shown in
Fig. 3. Refer to Tables 1A and 1B for operating weights.
Four lifting holes are provided in ends of unit base rails as
shown in Fig. 3-5. Refer to rigging instructions on unit.
POSITIONING - Provide clearance around and above unit
for airflow, safety, and service access (Fig. 4 and 5).
Do not install unit in an indoor location. Do not locate air in-
lets near exhaust vents or other sources of contaminated air.
Although unit is weatherproof, guard against water from
higher level runoff and overhangs.
ROOF MOUNT - Check building codes for weight distri-
bution requirements.
Form 50TJ-C17SI
Pg 1
50TJ016-028
50 Hz
1
/
in. per linear ft) in
16
Inspect
unit
for
5-01
Replaces: 50TJ-C16SI
