50TCA04---A07
Nominal 3 to 6 Tons
With Puron® (R410A) Refrigerant
Service and Maintenance Instructions

TABLE OF CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . . . . . .
. . . . . . . . .
. . . . . . . . . . . . . . . . . .

SAFETY CONSIDERATIONS

1
Installation and servicing of air-conditioning equipment
can be hazardous due to system pressure and electrical
2
components. Only trained and qualified service personnel
3
should
install,
5
equipment. Untrained personnel can perform the basic
maintenance functions of replacing filters. Trained service
7
personnel should perform all other operations.
9
When working on air-conditioning equipment, observe
13
precautions in the literature, tags and labels attached to
13
the unit, and other safety precautions that may apply.
18
Follow all safety codes. Wear safety glasses and work
gloves. Use quenching cloth for unbrazing operations.
19
Have fire extinguishers available for all brazing
20
operations.
20
Follow all safety codes. Wear safety glasses and work
21
gloves. Use quenching cloth for brazing operations. Have
23
fire extinguisher available. Read these instructions
thoroughly and follow all warnings or cautions attached to
32
the unit. Consult local building codes and National
50
Electrical Code (NEC) for special requirements.
50
Recognize safety information. This is the safety- - alert
.
52
symbol
. When you see this symbol on the unit and in
53
instructions or manuals, be alert to the potential for
personal injury.
54
63
Understand the signal words DANGER, WARNING, and
CAUTION. These words are used with the safety- - alert
69
symbol. DANGER identifies the most serious hazards
which will result in severe personal injury or death.
70
WARNING signifies a hazard which could result in
73
personal injury or death. CAUTION is used to identify
unsafe practices which may result in minor personal
injury or product and property damage. NOTE is used to
highlight suggestions which will result in enhanced
installation, reliability, or operation.
!
ELECTRICAL OPERATION HAZARD
Failure to follow this warning could result in personal
injury or death.
Before performing service or maintenance operations
on unit, turn off main power switch to unit. Electrical
shock and rotating equipment could cause injury.
repair,
or
service
air-conditioning
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 50TCA04-A07 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Carrier 50TCA04-A07

Summary of Contents for Carrier 50TCA04-A07

  • Page 1: Table Of Contents

    50TCA04---A07 Nominal 3 to 6 Tons With Puron® (R410A) Refrigerant Service and Maintenance Instructions TABLE OF CONTENTS SAFETY CONSIDERATIONS ....UNIT ARRANGEMENT AND ACCESS SUPPLY FAN (BLOWER) SECTION COOLING .

  • Page 2: Unit Arrangement And Access

    WARNING ELECTRICAL OPERATION HAZARD Failure to follow this warning could result in personal injury or death. Units with convenience outlet circuits may use multiple disconnects. Check convenience outlet for power status before opening unit for service. Locate its disconnect switch, if appropriate, and open it. Tag- - out this switch, if necessary.

  • Page 3: Supply Fan (Blower) Section

    located on the rear side of the unit, above the evaporator/return air access panel. (See Fig. 1.) To remove the filters: 1. Grasp the bottom flange of the upper panel. 2. Lift up and swing the bottom out until the panel dis- engages and pulls out.
  • Page 4 inside surfaces. Check belt tension by using a spring- - force tool (such as Browning’s Part Number “Belt Tension Checker” or equivalent tool); tension should be 6- - lbs at a 5/8- - in. deflection when measured at the centerline of the belt span.

  • Page 5: Cooling

    This cleaner available from Carrier Components Division as part number P902- - 0301 for a one gallon container, and part number P902- - 0305 for a 5 gallon container. It is recommended that all coils,...
  • Page 6 Two- - Row Coils Clean coil as follows: 1. Turn off unit power, tag disconnect. 2. Remove top panel screws on condenser end of unit. 3. Remove condenser coil corner post. See Fig. 8. To hold top panel open, place coil corner post between top panel and center post.

  • Page 7: Puronr (R- -410A) Refrigerant

    Puron (R- - 410A) from the cylinder as a vapor. Refrigerant Charge Amount of refrigerant charge is listed on the unit’s nameplate. Refer Carrier GTAC2- - 5 Charging, Recovery, Recycling and Reclamation training manual and the following procedures. Unit panels must be in place when unit is operating during the charging procedure.
  • Page 8 To Use Cooling Charging Charts Take the outdoor ambient temperature and read the suction pressure gauge. Refer to chart to determine what suction temperature should be. If suction temperature is high, add refrigerant. If suction temperature is low, carefully recover some of the charge. Recheck the suction pressure as charge is adjusted.

  • Page 9: Cooling Charging Charts

    COOLING CHARGING CHARTS C08203 C08204 Fig. 12 - - Cooling Charging Charts...

  • Page 10: Cooling Charging Charts (Cont)

    COOLING CHARGING CHARTS (cont) C08228 C08229 Fig. 12 - - Cooling Charging Charts (cont.)

  • Page 11: Filter Drier

    Compressor Lubrication The compressor is charged with the correct amount of oil at the factory. CAUTION UNIT DAMAGE HAZARD Failure to follow this caution may result in damage to components. The compressor is in a PuronR refrigerant system and uses a polyolester (POE) oil. This oil is extremely hygroscopic, meaning it absorbs water readily.
  • Page 12 PROBLEM CAUSE Power failure. Fuse blown or circuit breaker tripped. Defective thermostat, contactor, transformer, Compressor and Condenser or control relay. Fan Will Not Start. Insufficient line voltage. Incorrect or faulty wiring. Thermostat setting too high. Faulty wiring or loose connections in compres- sor circuit.

  • Page 13: Convenience Outlets

    CONVENIENCE OUTLETS WARNING ELECTRICAL OPERATION HAZARD Failure to follow this warning could result in personal injury or death. Units with convenience outlet circuits may use multiple disconnects. Check convenience outlet for power status before opening unit for service. Locate its disconnect switch, if appropriate, and open it. Tag- - out this switch, if necessary.
  • Page 14 operation are factory- - provided and mounted. The unit is factory- - configured immediate shutdown operation; additional wiring or modifications to unit terminal board may be necessary to complete the unit and smoke detector configuration to meet project requirements. System The smoke detector system consists of a four- - wire controller and one or two sensors.

  • Page 15: Smoke Detector Locations

    For installations using two sensors, the duct smoke detector does not differentiate which sensor signals an alarm or trouble condition. Smoke Detector Locations Supply Air — The Supply Air smoke detector sensor is located to the left of the unit’s indoor (supply) fan. See Fig.
  • Page 16 6. For units with an economizer, the sampling tube is in- tegrated into the economizer housing but the connec- tion of the flexible tubing to the sampling tube is the same. Fig. 22 - - Return Air Sensor Operating Position FIOP Smoke Detector Wiring and Response All units: FIOP smoke detector is configured to automatically shut down all unit operations when smoke...
  • Page 17 Sensor and Controller Tests Sensor Alarm Test The sensor alarm test checks a sensor’s ability to signal an alarm state. This test requires that you use a field provided SD- - MAG test magnet. CAUTION OPERATIONAL TEST HAZARD Failure to follow this caution may result in personnel and authority concern.

  • Page 18: Detector Cleaning

    Changing the Dirt Sensor Test By default, sensor dirty test results are indicated by: S The sensor’s Dirty LED flashing. S The controller’s Trouble LED flashing. S The controller’s supervision relay contacts toggle. The operation of a sensor’s dirty test can be changed so that the controller’s supervision relay is not used to indicate test results.

  • Page 19: Indicators

    CONTROL OR INDICATOR Magnetic test/reset switch Resets the sensor when it is in the alarm or trouble state. Activates or tests the sensor when it is in the normal state. Alarm LED Indicates the sensor is in the alarm state. Trouble LED Indicates the sensor is in the trouble state.

  • Page 20: Troubleshooting

    S If a wiring fault between a sensor and the controller, the controller’s Trouble LED turns on but not the sensor’s. Alarm Fig. 26 - - Controller Assembly NOTE: All troubles are latched by the duct smoke detector. The trouble condition must be cleared and then the duct smoke detector must be reset in order to restore it to the normal state.

  • Page 21: Relief Device

    The High Static option supply fan motor is equipped with pilot- - circuit Thermix overtemperature/overcurrent protection device resets automatically. Do not bypass this switch to correct trouble. Determine the cause and correct it. Condenser Fan Motor Protection The condenser fan motor is internally protected against overtemperature.

  • Page 22: Control Connections

    Single Point Boxes and Supplementary Fuses — When the unit MOCP device value exceeds 60- - A, unit- - mounted supplementary fuses are required for each heater circuit. These fuses are included in accessory Single Point Boxes, with power distribution and fuse blocks. The single point box will be installed directly under the unit control box, just to the left of the partition separating the indoor section (with electric heaters) from the outdoor section.

  • Page 23: Premierlinkt Control

    PremierLink configuration, operating sequences and troubleshooting information. Have a copy of this manual available at unit start- - up. The PremierLink controller requires the use of a Carrier electronic thermostat or a CCN connection for time broadcast to initiate its internal timeclock. This is necessary for broadcast of time of day functions (occupied/unoccupied).
  • Page 25 Sensors 32,651 factory- - shipped configured for Space Sensor Mode. A 25,395 Carrier T- - 55 or T- - 56 space sensor must be used. T- - 55 19,903 space temperature sensor provides a signal of space 15,714 temperature to the PremierLink control. T- - 56 provides...
  • Page 26 OUTDOOR AIR TEMPERATURE APPLICATION SENSOR Differential Dry Bulb Temperature with Included --- PremierLink (PremierLink CRTEMPSN001A00 requires 4--- 20 mA Actuator) Single Enthalpy with Included --- PremierLink (PremierLink requires 4--- 20mA Not Used Actuator) Differential Enthalpy with PremierLink (PremierLink Included --- requires 4--- 20mA Not Used Actuator)
  • Page 27 IAQ --- COM/OAQ --- COM/RH--- COM OAQ --- SEN/RH--- SEN AUX OUT(Power Exhaust) LEGEND: --- Space Temperature Sensor --- Space Temperature Sensor --- Carrier Comfort Network (communication bus) CMPSAFE --- Compressor Safety FILTER --- Dirty Filter Switch --- Fire Shutdown...
  • Page 28 Connect T- - 56 - - See Fig. 38 for T- - 56 internal connections. Install a jumper between SEN and SET terminals as illustrated. Connect T- - 56 terminals to TB1 terminals 1, 3 and 5 (see Fig. 39). RED(+) WHT(GND) BLK(-)
  • Page 29 The enthalpy control receives the outdoor air enthalpy from the outdoor air enthalpy sensor and provides a dry contact switch input to the PremierLink controller. A closed contact indicates that outside air is preferred to the return air. An open contact indicates that the economizer should remain at minimum position.
  • Page 30 IAQ Sensor 24 VAC Fig. 44 - - Indoor CO2 Sensor (33ZCSENCO2) Connec- tions Refer to Form 33CS- - 58SI, PremierLink Installation, Start- - up, and Configuration Instructions, for detailed configuration information Outdoor Air Quality Sensor (PNO 33ZCSENCO2 plus weatherproof enclosure) — The outdoor air CO2 sensor is designed to monitor carbon dioxide (CO2) levels in the outside ventilation air and interface with the ventilation damper in an HVAC system.
  • Page 31 4000 ft, with no more than 60 total devices on any 1000- - ft section. Optically isolated RS- - 485 repeaters are required every 1000 ft. NOTE: Carrier device default is 9600 band. COMMUNICATION BUS WIRE SPECIFICATIONS — The CCN Communication Bus wiring is field- - supplied and field- - installed.

  • Page 32: Economizer Systems

    (typically WHT) to the unit’s TB1- - 14 terminal. Connect the CCN (- - ) lead (typically BLK) to the unit’s TB1- - 16 terminal. See Fig. 51. CCN Bus + (RED) GND (WHT) – (BLK) Fig. 51 - - PremierLink CCN Bus Connections ECONOMIZER SYSTEMS The 50TC units may be equipped with a factory- - installed or accessory (field- - installed) economizer system.
  • Page 33 500 OHM RESISTOR NOTE 1 NOTE 3 50HJ540573 ACTUATOR ASSEMBLY DIRECT DRIVE ACTUATOR NOTES: 1. Switch on actuator must be in run position for economizer to operate. 2. PremierLink™ control requires that the standard 50HJ540569 outside-air sensor be replaced by either the CROASENR001A00 dry bulb sen sor or HH57A077 enthalpy sensor.
  • Page 34 A functional view of the EconoMi$er is shown in 56. Typical settings, sensor ranges, and jumper positions are also shown. An EconoMi$er IV simulator program is available from Carrier to help with EconoMi$er IV training and troubleshooting. EconoMi$er IV Standard Sensors...
  • Page 35 and D. See Fig. 59 for the corresponding temperature changeover values. Fig. 58 - - EconoMi$er IV Controller Potentiometer and LED Locations LED ON LED ON LED OFF LED ON LED OFF LED OFF DEGREES FAHRENHEIT Fig. 59 - - Outside Air Temperature Changeover Setpoints 0.13 0.20 0.22...
  • Page 36 CONTROL CONTROL POINT CURVE APPROX. deg. F (deg. C) AT 50% RH 73 (23) 70 (21) 67 (19) 63 (17) Open Free Cool Fig. 63 - - EonoMi$er IV Control Differential Enthalpy Control For differential enthalpy control, the EconoMi$er IV controller uses two enthalpy sensors (HH57AC078 and CRENTDIF004A00), one in the outside air and one in the return air duct.
  • Page 37 CO SENSOR MAX RANGE SETTING 6000 5000 4000 3000 2000 1000 DAMPER VOLTAGE FOR MAX VENTILATION RATE Fig. 64 - - CO2 Sensor Maximum Range Settings If a separate field-supplied transformer is used to power the IAQ sensor, the sensor must not be grounded or the EconoMi$er IV control board will be damaged.
  • Page 38 (See Table 12.) Use setting 1 or 2 for Carrier equipment. (See Table 12.) 1. Press Clear and Mode buttons. Hold at least 5 seconds until the sensor enters the Edit mode.
  • Page 39 5. Press Mode to move through the variables. 6. Press Enter to lock in the selection, then press Mode to continue to the next variable. Dehumidification of Fresh Air with DCV (Demand Controlled Ventilation) Control If normal rooftop heating and cooling operation is not adequate for the outdoor humidity level, an energy recovery unit and/or a dehumidification option should be considered.

  • Page 40: Wiring Diagrams

    2. Set the Enthalpy potentiometer to A. The Free Cool LED turns on. The actuator should drive to between 20 and 80% open. 3. Remove the 5.6 kilo- - ohm resistor and jumper T to T1. The actuator should drive fully open. 4.

  • Page 41: To Shut Off Unit

    4. Verify the following conditions: a. Make sure that condenser- - fan blade are correctly positioned in fan orifice. See Condenser- - Fan Adjustment section on page 11 for more details. b. Make sure that air filter(s) is in place. c.
  • Page 42 - up and setpoints from a zone sensor or terminal control module. During start- - up, the Carrier software can also be used to verify communication with Premier- - Link controller.
  • Page 43 outdoor- - air dampers closed to maintain the proper supply- - air temperature. HEATING, UNITS WITH ECONOMI$ER IV — When the room temperature calls for heat, the heating controls are energized as described in the Heating, Units Without Economizer section. ECONOMIZER OCCUPIED economizer logic will be energized when the unit IFC is...
  • Page 44 Heating may also be energized when an IAQ sensor installed and has overridden the minimum economizer damper position. If the OAT < 55_F and an IAQ sensor is installed and the IAQ minimum position > minimum damper position causing the SAT to decrease below the SPT - - 10_F, then the heat stages will be cycled to temper the SAT to maintain a temperature between the SPT and the SPT + 10_F.
  • Page 45 S Whenever the Supply Fan Relay point is forced On in the STATUS01 points display table The fan will also continue to run as long as compressors are on when transitioning from occupied to unoccupied with the exception of Fire Shutdown mode. If the Fire Shutdown input point is closed or forced in the STATUS01 points display table, the fan will be shutdown immediately regardless of the occupancy state or demand.
  • Page 46 return to normal when the indoor relative humidity drops 3% below the active humidity setpoint. Economizer — The economizer dampers are used to provide free cooling and indoor air quality if optional CO2 sensor is installed and when the outside conditions are suitable.
  • Page 47 The maximum number of stages available is dependent on the type of heat and the number of stages programmed in the CONFIG and SERVICE configuration tables. Staging will occur as follows for gas electric units, Carrier heat pumps with a defrost board, or cooling units with electric heat: For Heating PID STAGES = 2 HEAT STAGES = 1 (50% capacity) - - energize HS1.
  • Page 48 equal to OCSP and Enthalpy = Low then PURGEMP = 100%. S If the OAT < NTLO then PURGEMP = LTMP (Low Temperature Minimum Position - - defaults to 10%) S If the OAT > 65_F or (OAT ≥ NTLO and OAT > OCSP) or Enthalpy = High then PURGEMP = HTMP (High Temperature Minimum Position defaults to 35%).

  • Page 49: Fastener Torque Values

    For more information on how the PremierLink controller is used in conjunction with the Carrier 3V control system, contact your CCN controls representative. IMPORTANT: The PremierLink controller should not be used as a linked air source in a ComfortIDt VAV system.

  • Page 50: Wiring Diagrams

    Supply fan motor mounting Supply fan motor adjustment plate Motor pulley setscrew Fan pulley setscrew Blower wheel hub setscrew Bearing locking collar setscrew Compressor mounting bolts Condenser fan motor mounting bolts Condenser fan hub setscrew Fig. 65 - - 50TC Typical Unit Wiring diagram - - Power (A06) Table 16 –...

  • Page 52: Model Number Nomenclature

    APPENDIX I. MODEL NUMBER SIGNIFICANCE Model Number Nomenclature 5 0 T C -- A 0 6 A 0 A 5 A 0 A 0 A 0 ____ ____ Unit Heat Type 50 = Elec heat pkg rooftop Tier / Model TC = Entry tier (with Puron) Heat Size --- = No heat...

  • Page 53: Appendix Ii. Physical Data

    Physical Data (Cooling) Refrigeration System # Circuits / # Comp. / Type Puron (R--- 410a) charge A/B (lbs) Oil A/B (oz) Metering Device High--- press. Trip / Reset (psig) Low--- press. Trip / Reset (psig) Evap. Coil Material Coil type Rows / FPI Total Face Area (ft Condensate Drain Conn.

  • Page 54: Appendix Iii. Fan Performance

    Carrier recommended the lower horsepower option. 5. For information on the electrical properties of Carrier’s motors, please see the Electrical information section of this book. 6. For more information on the performance limits of Carrier’s motors, see the application data section of this book.
  • Page 55 APPENDIX III. FAN PERFORMANCE (cont.) 50TC**04 1 Phase 3 Ton Horizontal Supply Field Supplied Drive 0.14 0.16 1050 0.18 1125 0.21 1200 0.23 1275 0.27 1350 0.30 1425 0.34 1500 0.38 Medium Static Option 1017 0.64 1082 1035 0.68 1100 1050 1053 0.73...
  • Page 56 APPENDIX III. FAN PERFORMANCE (cont.) 50TC**04 3 Phase 3 Ton Horizontal Supply Field Supplied Drive 0.14 0.16 1050 0.18 1125 0.21 1200 0.23 1275 0.27 1350 0.30 1425 0.34 1500 0.38 Medium Static Option 1017 0.64 1082 1035 0.68 1100 1050 1053 0.73...
  • Page 57 APPENDIX III. FAN PERFORMANCE (cont.) 50TC**05 1 Phase 4 Ton Horizontal Supply Standard Static Option 1200 0.23 1300 0.28 1400 0.33 1500 0.38 1600 0.44 1700 0.51 1800 0.59 1900 0.67 2000 0.76 1004 Medium Static Option 1200 1089 0.84 1153 1177 1300...
  • Page 58 APPENDIX III. FAN PERFORMANCE (cont.) 50TC**05 3 Phase 4 Ton Horizontal Supply Standard Static Option 1200 0.23 1300 0.28 1400 0.33 1500 0.38 1600 0.44 1700 0.51 1800 0.59 1900 0.67 2000 0.76 1004 Medium Static Option 1200 1089 0.84 1153 1300 1114...
  • Page 59 APPENDIX III. FAN PERFORMANCE (cont.) 50TC**06 1 Phase 5 Ton Horizontal Supply Field Supplied Drive 1500 0.33 0.40 1625 1750 0.48 1875 0.57 2000 0.67 2125 0.79 1025 2250 0.92 1066 2375 1024 1.06 1107 2500 1069 1.22 1149 Medium Static Option 1500 1188 1.09...
  • Page 60 APPENDIX III. FAN PERFORMANCE (cont.) 50TC**06 3 Phase 5 Ton Horizontal Supply Field Supplied Drive 1500 0.33 0.40 1625 1750 0.48 1875 0.57 2000 0.67 2125 0.79 1025 2250 0.92 1066 2375 1024 1.06 1107 2500 1069 1.22 1149 1500 1188 1.09 1261...
  • Page 61 APPENDIX III. FAN PERFORMANCE (cont.) 50TC**07 3 Phase 6 Ton Horizontal Supply Field Supplied Drive 1800 0.51 0.62 1950 2100 0.75 1019 2250 0.90 1067 1026 1.06 2400 1115 2550 1079 1.25 1164 2700 1132 1.46 1214 2850 1186 1.69 1264 3000 1240...

  • Page 62: Pulley Adjustment

    APPENDIX III. FAN PERFORMANCE (cont.) Pulley Adjustment MOTOR/DRIVE UNIT COMBO Standard Static Medium Static 1175 High Static Standard Static Medium Static 1175 High Static 1466 Standard Static Medium Static 1175 High Static Standard Static Medium Static 1175 High Static 1466 Standard Static 1175 Medium Static...

  • Page 63: Appendix Iv. Electrical Data

    APPENDIX IV. ELECTRICAL DATA 50TC**04 3 TONS VOLTAGE COMP (ea) RANGE V ---Ph---Hz 208--- 1--- 60 16.6 230--- 1--- 60 16.6 208--- 3--- 60 10.4 230--- 3--- 60 10.4 460--- 3--- 60 575--- 3--- 60 50TC**05 4 TONS VOLTAGE COMP (ea) RANGE V ---Ph---Hz 208--- 1--- 60...
  • Page 64 APPENDIX IV. ELECTRICAL DATA (cont.) 50TC**06 5 TONS VOLTAGE COMP (ea) RANGE V ---Ph---Hz 208--- 1--- 60 26.2 230--- 1--- 60 26.2 208--- 3--- 60 15.6 230--- 3--- 60 15.6 460--- 3--- 60 575--- 3--- 60 50TC**07 6 TONS VOLTAGE COMP (ea) RANGE V ---Ph---Hz...
  • Page 65 APPENDIX IV. ELECTRICAL DATA (cont.) MCA/MOCP DETERMINATION NO C.O. OR UNPWRD C.O. ELECTRIC HEATER TYPE Nom (kW) None None 3.3/4.4 15.9/18.3 4.9/6.5 23.5/27.1 6.5/8.7 31.4/36.3 7.9/10.5 37.9/43.8 9.8/13.0 46.9/54.2 None None 3.3/4.4 15.9/18.3 4.9/6.5 23.5/27.1 6.5/8.7 31.4/36.3 7.9/10.5 37.9/43.8 9.8/13.0 46.9/54.2 None None...
  • Page 66 APPENDIX IV. ELECTRICAL DATA (cont) MCA/MOCP DETERMINATION NO C.O. OR UNPWRD C.O. (cont) ELECTRIC HEATER TYPE Nom (kW) None None 3.3/4.4 15.9/18.3 6.5/8.7 31.4/36.3 9.8/13.0 46.9/54.2 13.1/17.4 62.8/72.5 15.8/21.0 75.8/87.5 None None 3.3/4.4 15.9/18.3 6.5/8.7 31.4/36.3 9.8/13.0 46.9/54.2 13.1/17.4 62.8/72.5 15.8/21.0 75.8/87.5 None...
  • Page 67 APPENDIX IV. ELECTRICAL DATA (cont) MCA/MOCP DETERMINATION NO C.O. OR UNPWRD C.O. (cont) ELECTRIC HEATER TYPE Nom (kW) None None 4.9/6.5 23.5/27.1 6.5/8.7 31.4/36.3 9.8/13.0 46.9/54.2 13.1/17.4 62.8/72.5 15.8/21.0 75.8/87.5 None None 4.9/6.5 23.5/27.1 6.5/8.7 31.4/36.3 9.8/13.0 46.9/54.2 13.1/17.4 62.8/72.5 15.8/21.0 75.8/87.5 None...
  • Page 68 APPENDIX IV. ELECTRICAL DATA (cont) MCA/MOCP DETERMINATION NO C.O. OR UNPWRD C.O. (cont) ELECTRIC HEATER TYPE Nom (kW) None None 4.9/6.5 13.6/15.6 7.9/10.5 21.9/25.3 12.0/16.0 33.4/38.5 15.8/21.0 43.8/50.5 19.9/26.5 55.2/63.8 None None 4.9/6.5 13.6/15.6 7.9/10.5 21.9/25.3 12.0/16.0 33.4/38.5 15.8/21.0 43.8/50.5 19.9/26.5 55.2/63.8 None...

  • Page 69: Appendix V. Wiring Diagram List

    APPENDIX V. WIRING DIAGRAM LIST Wiring Diagrams 50TC Size Voltage 208/230---1---60 48TM500212.04 208/230---3---60 48TM500212.04 460---3---60 48TM500212.04 575---3---60 48TM500212.04 208/230---1---60 48TM500212.04 208/230---3---60 48TM500212.04 460---3---60 48TM500212.04 575---3---60 48TM500212.04 208/230---1---60 48TM500212.04 208/230---3---60 48TM500212.04 460---3---60 48TM500212.04 575---3---60 48TM500212.04 208/230---3---60 48TM500212.04 460---3---60 48TM500212.04 575---3---60 48TM500212.04 PremierLink* 48TM500983.02 NOTE: Component arrangement on Control;...

  • Page 70: Appendix Vi. Motormaster Sensor Locations

    APPENDIX VI. MOTORMASTER SENSOR LOCATIONS Fig. 67 - - 50TC*A04 Outdoor Circuiting Fig. 68 - - 50TC*A05/06 Outdoor Circuiting C08259 Fig. 69 - - 50TC*A07 Outdoor Circuiting C08260 Fig. 70 - - 50TC*A08 Outdoor Circuiting C08261 C08262...
  • Page 71 APPENDIX VI. (cont) MOTORMASTER SENSOR LOCATIONS C08263 Fig. 71 - - 50TC*A09/12 Outdoor Circuiting...
  • Page 72 Catalog No: 50TC ---1SM Copyright 2008 Carrier Corp. S 7310 W. Morris St. S Indianapolis, IN 46231 Printed in U.S.A. Edition Date: 05/08 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.

  • Page 73: Preliminary Information

    SET ECONOMIZER MINIMUM VENT AND CHANGEOVER SETTINGS TO MATCH JOB REQUIREMENTS (IF EQUIPPED) Copyright 2008 Carrier Corp. S 7310 W. Morris St. S Indianapolis, IN 46231 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
