Instruction Manual
Quick Setup
1.
Make sure the Carryout
location with a clear view of the southern sky.
2.
Connect the provided coaxial cable from
the primary receiver to the "MAIN" port on
the base.
3.
Connect one end of the provided power
cable to the power socket and the other end
to a 12V power source.
4.
Follow the receiver setup instructions on
pages 3–4 for your programming provider.
5.
Watch TV!
G2
antenna
is in a
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Carryout G2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Winegard Carryout G2

  • Page 1 Instruction Manual Quick Setup Make sure the Carryout antenna is in a ® location with a clear view of the southern sky. Connect the provided coaxial cable from the primary receiver to the “MAIN” port on the base. Connect one end of the provided power cable to the power socket and the other end to a 12V power source.
  • Page 2: Specifications

    DISH Sat. 110° Receiver models change frequently. DIRECTV Receiver Compatibility The Carryout G2 antenna is not compatible with DIRECTV SWM-only receivers (e.g. H25 or HR34). If you have a SWM- only technology receiver, Winegard Model SWM-840 kit is available. This SWM kit will allow for proper SWM technology operation with Winegard mobile satellite TV antennas.
  • Page 3: Switch Settings

    To set the antenna for any other programming provider, complete the following steps: Select a location that will enable the Carryout G2 antenna to sit within three degrees of level. The antenna may take longer Remove the dome screws with a Phillips screwdriver, and to lock onto signal if the antenna is not level.
  • Page 4: Receiver Setup

    Receiver Setup Select 3-LNB (18”x20”) or 3 Satellites. If given the option of SWM or Multiswitch, select Multiswitch. Connect the receiver to a power source, and complete receiver setup. Receiver setup for the primary receiver follows; if your receiver differs from the options shown, you may need to consult your receiver manual.
  • Page 5 DISH Receiver Setup Select Check Switch. If using two DISH receivers with the Carryout G2 antenna, both receivers must be configured off of the primary port by following the steps below. Disconnect coax cable from the Satellite In port on the back of the receiver.
  • Page 6: Troubleshooting

    MAIN and SEC ports. Rated Current: 4 Amp Rated Power: 50W The Carryout G2 antenna is designed to be maintenance free. Ripple & Noise (max.): 120 mVp-p However, it is a good idea to periodically clean the dome with Voltage Tolerance: ±5%...
