HySecurity SlideDriver 15 Installation Instructions Manual page 4

t r
OOls equired
• Standard socket set with extension
• Standard hex key set
• Combination wrench set
• Standard pliers and needle-nose pliers
• Set of Phillips head and flat-head screwdrivers
• Wire strippers & wire crimper
s d 200
lide river series
17¾" (45 cm)
2" (5 cm)
1¼" (3 cm)
5" (13 cm)
12½" (32 cm)
14½" (37 cm)
NOTE: Chassis cover
adds ½" (13 mm).
Total depth with
cover = 15" (38 cm).
Mounting bolt
locations
Nine (9) ½ x 4"
anchor bolts.
43" (109 cm)
Required: A
47" (119 cm)
minimum 2 bolts
minimum
fastened per
cross support.
p M H
Ost Ount fOr ydra
For DC / UPS or Modular
options, wall or post-mount the
Unistrut
cabinet.
If planning a post mount,
mounting holes need to be
drilled (U-bolts, fasteners, and
unistrut are not provided).
Cabinet may also be wall-
mounted with anchor bolts.
NOTE: The mounting holes on
the top and bottom flanges are
5/16-inch diameter. Mounting
posts and hardware are not
provided by HySecurity. Flange
For more information, refer to the supplemental manuals that accompany the product.
© 2016 www.hysecurity.com
• Digital Volt-Ohm meter
• Level and measuring tape
• Electric drill and drill bits (Unibit or Stepdrill)
• Metal cutting saw
For the full recommended list of tools and
hardware, see the SlideDriver Programming and
Operations Manual.
Distance between gate face
22¾" (58 cm) and rear chassis:
1½ ± ⅛ inch (38 mm ± 3 mm)
Conduit cutout area for electrical access.
Cut out dimensions: 8 x 6½" (20 x 16.5 cm)
8" (20 cm)
6½"
(16.5 cm)
2" (5 cm)
1¼" (3 cm)
MINIMUM CONCRETE DIMENSIONS
20" Wide x 47" Length x 16" Depth minimum*
10" (25 cm)
(51 x 119 x 41 cm)
*Or, Frost line whichever is greater. Refer to
local code for appropriate depth.
s dC / ups C
upply Or
C/L
C/L
Gate panel face
13½"
(34 cm)
U-bolt
1⅞"
30¾" (78 cm)
(5 cm)
1¼"
(3 cm)
Flange
Door clip
Cabinet option
Cabinet
SlideDriver
SlideDriver: Site Prep
C
SlideDriver:
learanCes
Side Access: Minimum 24 inches (61 cm)
Front Access: Allow 30 inches (76 cm)
Gate panel
Side
ROADWAY
access
Concrete pad extends 2 inch (5 cm)
minimum beyond side and front of gate operator
chassis' footprint. Conduit runs between gate
operator and cabinet.
Gate post
Drive rail
ROADWAY
Right handing
gate operator
O H
peratOr anding
abinet
When you first apply power to the operator, it is locked in
Menu mode and prompts appear on the display. The gate
will not move and the controls will not function until the
prompts have been answered. The prompts include:
Offset 4¾"
(12 cm)
Face of
Gate panel
and cabinet
SlideDriver viewed
from the secure side
SlideDriver Installation and Assembly
Cabinet (DC / UPS):
Door Swing: Minimum 30 inches (76 cm)
Rear Access: Allow 24 inches (61 cm)
Fence
Drive rail
Chassis base cut out for conduit
SlideDriver
Cabinet:
Modular, DC / UPS options
Door swing clearance:
Minimum
36 inches (91 cm)
Front access
Leave enough space between cabinet and chassis to avoid pinch point
and access issues. Conduit runs below ground between the two units.
Allow 12 to 16 inches
FENCE LINE
(30 to 41 cm)
Gate panel
SLIDEDRIVER
• Usage Class setting (UC)
• Gate operator handing (Set Handing: SH)
See page 9 for more information.
OPEN OPEN
Left hand gate Right hand gate
Cabinet (Modular):
Front Access: Minimum 36 inches (92 cm)
Rear Access: Allow 24 inches (61 cm)
Minimum
clearance for
cover removal:
15 inches (38 cm)
Offset 3 inches (7.6 cm) from the
surface of the support posts to
rear of SlideDriver chassis.
Modular and DC / UPS options shown:
Post-mounted.
U-bolts mounted to Unistrut on back of cabinet.
Cabinet may also be wall-mounted with anchor bolts.
Wheel covers required for
cantilevered gates: UL325
Concrete pad
SlideDriver viewed
from the secure side
Drawings NOT to Scale
MX3629-01 Rev. B Page 4
