HySecurity SlideDriver 15 Installation Instructions Manual
Hide thumbs
Also See for SlideDriver 15:
- Programming and operations manual (156 pages) ,
- Programming & operation manual (104 pages) ,
- Manual (8 pages)
Advertisement
Table of Contents
Models
SlideDriver 15
222 SS ST
1,500 lb (680 kg)
SlideDriver 30F
222 EX 1.7 ST
3,000 lb (1,361 kg)
SlideDriver 40
222 E ST
4,000 lb (1,814 kg)
SlideDriver 50VF2/3
222 X3 ST
5,000 lb (2.268 kg)
SlideDriver 80
222 X1 ST
8,000 lb (3,629 kg)
SlideDriver 200
444 XS ST
20,000 lb (9,072 kg)
800-321-9947 www.hysecurity.com
Installation Instructions
1 ft/s (30 cm/s)
1.7 ft/s (50 cm/s)
1 ft/s (30 cm/s)
2.2 ft/s (70 cm/s) or
3 ft/s (91 cm/s)
1 ft/s (30 cm/s)
1 ft/s (30 cm/s)
The World's Most Rugged and Reliable High Security Slide Gate Operator
SlideDriver 30F
MX3629-01 Rev. B
Advertisement
Table of Contents
Related Manuals for HySecurity SlideDriver 15
Summary of Contents for HySecurity SlideDriver 15
- Page 1 Installation Instructions Models SlideDriver 15 222 SS ST 1,500 lb (680 kg) 1 ft/s (30 cm/s) SlideDriver 30F 222 EX 1.7 ST 3,000 lb (1,361 kg) 1.7 ft/s (50 cm/s) SlideDriver 40 222 E ST 4,000 lb (1,814 kg) 1 ft/s (30 cm/s)
- Page 3 Low voltage/ 13" (33 cm) Drawings are NOT TO SCALE. NOTE: XtremeDrive™ mount drive rail ¼ to ½” (6 to 13 mm) higher. communication wires 26" (66 cm) © 2016 www.hysecurity.com SlideDriver Installation and Assembly MX3629-01 Rev. B Page 3...
- Page 4 OPEN the top and bottom flanges are 5/16-inch diameter. Mounting posts and hardware are not Left hand gate Right hand gate Cabinet option provided by HySecurity. Flange SlideDriver viewed SlideDriver viewed from the secure side from the secure side Cabinet For more information, refer to the supplemental manuals that accompany the product.
-
Page 5: Setup And Assembly
14½-inches (37 cm) 1½-inch Mounting Template Drawings NOT to Scale (38 mm) Do NOT fully tighten the anchor bolts until after the drive rail is installed. See page 4. © 2016 www.hysecurity.com SlideDriver Installation and Assembly MX3629-01 Rev. B Page 5... -
Page 6: Concrete Pad
Drill holes through the drive rail flange and insert U bolts from the far side. Secure the toggle handle. Install U bolts along the upright support structure, as needed. HySecurity recommends that you attach to a minimum of 3 supports per Disengage the drive wheels by pulling on the toggle handle. - Page 7 Limit ramp stopped position Toggle Handle Assembly NOTE: Only the limit ramp should trigger the limit switch. Drawings NOT to Scale © 2016 www.hysecurity.com SlideDriver Installation and Assembly MX3629-01 Rev. B Page 7...
-
Page 8: Wiring Ac Power
DANGER Turn OFF AC power at the source (circuit breaker panel) before accessing the HySecurity gate operators are intended for permanent installation. Make sure to wires in the gate operator. Follow facility Lock Out/Tag Out procedures. Make Blue - 480 VAC review all the information in this manual and prepare the site with the following sure all power switches are in the OFF position. -
Page 9: Complete The Installation
The gate will not move and the controls will not function until the prompts have been answered. The prompts include: For in-field conversions, the NEC requires that the voltage label on the motor be changed to match the new configuration. Contact HySecurity for a replacement label. UC 2 •... - Page 10 SlideDriver 50VF2/3 800-321-9947 www.hysecurity.com MX3629-01 Rev. B...
