  • Page 1 DC-D Series Operation Manual DC-D1011 / DC-D1022W / DC-D1022WR / DC-D1111/ DC-D1122 / DC-D1122R / DC-D1122V / DC-D1122VR / DC-D1122W / DC-D1122WR / DC-D1123 / DC-D1123R / DC-D1123V / DC-D1123VR / DC-D1123W / DC-D1123WR / DC-D1123WHR / DC-D1212R / DC-D1223 / DC-D1223R /...

  • Page 2: Safety Symbols

    Before reading this manual This is a basic operation manual for installation and use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.

  • Page 3: Safety Precautions

    Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.

  • Page 4: Fcc Compliance Statement

    © 2013 IDIS Co., Ltd. IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements.

  • Page 5: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 7 Product Features .
  • Page 6 Part 4 - IDIS Web ........

  • Page 7: Part 1 - Introduction

    • Quick and easy firmware upgrade over the network You can use the IDIS Discovery program to change • Redundant firmware and auto recovery features for network camera settings or the IDIS Solution Suite...

  • Page 8: Accessories

    Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. Network Camera Ferrite Core Open Source Guide Quick Guide Allen Wrench Screws (3 ea.)

  • Page 9: Overview

    / DC-D1223WR / DC-D1223WHR Shield Case DC-D1022W / DC-D1122 / DC-D1122V / DC-D1122W / • DC-D1011 / DC-D1111 / DC-D1122 / DC-D1122R / DC-D1123 / DC-D1123V / DC-D1123W / DC-D1223 / DC- DC-D1123 / DC-D1123R / DC-D1212R / DC-D1223 /...

  • Page 10: Body

    Part 1 – Introduction Body Side Cable Access Safety Wire DC-D1123 / DC-D1223 Dome Cover Screws Shield Case 1 Side Cable Access Hole For routing cables and wires. 2 Safety Wire Prevents the dome cover from falling on to the floor when detached from the camera.
  • Page 11 Part 1 – Introduction DC-D1123VR / DC-D1223VR / DC-D1123WR / DC- DC-D1122 D1223WR DC-D1122R DC-D1123WHR / DC-D1223WHR DC-D1122V / DC-D1022W / DC-D1122W DC-D1011 / DC-D1111...
  • Page 12 D1123WR / DC-D1212R / DC-D1122R / DC-D1223R / DC-D1223VR / DC-D1223WHR / DC- D1223WR only DC-D1212R 2 Lens Features a variable focus auto iris lens or a fixed focus DC-D1011 / DC-D1111 / DC-D1212R lens. models feature a fixed focus lens. 3 Heater &...

  • Page 13: Factory Reset

    Used to connect I/O devices to the camera. on or using the IDIS Discovery program from a remote $ Cable Access Hole location. A factory reset will reboot the system. For more For routing cables and wires.

  • Page 14: Lens

    Once the zoom has been adjusted, turn the screw in clockwise direction to lock it in place. Lever length may vary depending on the model. DC-D1011 / DC-D1111 / DC-D1212R models do not feature a variable focus automatic iris lens. Alarm I/O...
  • Page 15 0.5 seconds. For more information on network connection setup, 2 Audio In/Out refer to the IDIS Discovery operation manual, TYPE 1 • Out: Connect an amplifier to this port (line out). 7 Power LED This device does not feature a built-in audio Indicates the system's operating status.

  • Page 16: Alarm Out

    Part 1 – Introduction Connector Arrangement • Check your local laws and regulations on making video or audio recordings. The user will be held TYPE 1 liable for any violation of the law. (Article 25-5 of the Personal Information Protection Act: Operators of image data processing devices may not operate such devices for purposes other than as originally intended during device installation, place such...

  • Page 17: Installation

    Part 1 – Introduction Installation Installation of this product does not require the use of special tools. For more information on other devices comprising the overall system, refer to their respective installation manuals. Guide Pattern Product color and design may vary depending on the model.
  • Page 18 DC-D1223VR / DC-D1223W / DC-D1223WR / DC- D1223WHR : Use the provided screws to secure the dome cover on to the bottom cover. DC-D1011 / DC-D1111 / DC-D1122 / – DC-D1122R / DC-D1123 / DC-D1123R / DC-D1212R / DC-D1223 / DC-D1223R...

  • Page 19: Angle Adjustment

    Part 1 – Introduction Angle Adjustment Dimensions The lens can be rotated along three axes. DC-D1022W / DC-D1022WR / DC-D1122V / DC-D1122VR / DC-D1122W / DC-D1122WR / DC-D1123V / DC-D1123VR / DC-D1123W / DC-D1123WR / DC-D1123WHR / DC-D1223V / DC- D1223VR / DC-D1223W / DC-D1223WR / DC-D1223WHR Lens Rotation...
  • Page 20 Part 1 – Introduction DC-D1122 / DC-D1122R / DC-D1123 / DC-D1123R / DC-D1223 / DC-D1223R 159mm (6.26”) DC-D1011 / DC-D1111 / DC-D1212R 132mm (5.20”)

  • Page 21: Part 2 - Camera Connection

    Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Audio In Audio Out Power Alarm Out Sensor In Network Camera VGA/HDMI...

  • Page 22: With Non Directip™ Nvr-Based Layout

    TYPE 1 Alarm In/Out, Audio In/Out and SD card recording are supported by models only. The contents after page 21 are only for users using the camera with non DirectIP™ NVR connection or VMS connection such as IDIS Solution Suite Compact.

  • Page 23: Part 3 - Remote Setup

    - The DirectIP™ NVR also allows you to control all camera settings directly from the NVR, without the need for a computer. Launch the IDIS Discovery program and from the list, select a camera whose protocol you wish to change. For more information on configuring camera settings from a DirectIP™...

  • Page 24: Remote Setup

    Part 3 - Remote Setup Remote Setup Quick Setup TYPE 1 Launch the IDIS Discovery program and then from the main screen, select a network camera whose settings you wish to change. Click on the Setup icon. Select Remote Setup from the Setup menu to load the Remote Setup screen.

  • Page 25: System

    Part 3 - Remote Setup System • Miscellaneous - ONVIF Protocol: Select to enable ONVIF protocol use. However, ONVIF Protocol is available only to users belonging to the standard user groups (Administrator, Operator, and User). When you have connected to the camera by using the ONVIF protocol, only the currently enabled streams or events are supported and you cannot change it.

  • Page 26: Date/Time

    Part 3 - Remote Setup Date/Time User/Group • User/Group: Change remote camera control • Date/Time: Change the camera's date/time settings permission settings for users and user groups. and display formats and configure the time zone and daylight saving time settings. Click Apply to apply the - Add Group: Add a new user group.

  • Page 27: Network

    Part 3 - Remote Setup Network • User/Group settings can only be configured by users belonging to the Administrator group. • There is no default password for the Administrator group's admin user. • Standard groups (Administrator, Operator, and User) cannot be edited or deleted. Authorities assigned here apply identically to ONVIF protocol user groups.

  • Page 28: Fen

    IDIS Web program. The FEN Server operated by IDIS is a service to its clients and may go offline without notice for server update purposes or due to an unexpected failure.

  • Page 29: Port/Qos

    Record, and Search ports are enabled by default and cannot be disabled. By enabling IDIS Web and RTSP ports, you will be able to use the IDIS Web program or a media player that supports RTSP (Real-Time Streaming Protocol) service to connect to the camera.

  • Page 30: Bandwidth Control

    It may not be possible to produce the frame rate Port Number/ (If Use HTTPS has been enabled, specified under Video > Streaming if a network enter https instead of http). Camera's IDIS bandwidth limit has been set. Web port number and RTSP port number must be configured correctly in order to establish a connection this way.

  • Page 31: Security

    Part 3 - Remote Setup Security IEEE 802.1X Select the IEEE 802.1X option to enable IEEE 802.1X network connection authentication. • IP Filtering: Select this option to enable IP Filtering. IP Filtering allows camera access from certain IP addresses and blocks access from others. •...

  • Page 32: Video

    Configure Image Sensor settings. images. • B&W Mode: Display the images in greyscale for DC-D1011 / greater clarity in low-lighting conditions. DC-D1111 only - On/Off: Enable/disable B&W Mode. - Auto: Allow the system to enable/disable B&W Mode automatically.
  • Page 33 Part 3 - Remote Setup White Balance Exposure Configure White Balance settings. Configure Exposure settings. • Preset: Use preconfigured white balance settings. • AE Target Gain: Specify exposure compensation's target gain. Exposure is compensated automatically - Auto: Allow the system to adjust the white based on the specified target gain.
  • Page 34 Day & Night Filter automatically. - Schedule: Set up an IR Cut Filter schedule. IR Not applicable to DC-D1011 / DC-D1111 Cut Filter use is disabled during dates and times Configure Day & Night settings. designated as Nighttime and enabled at all other times.

  • Page 35: Streaming

    Tertiary Model DC-D1022WR / DC-D1122VR / DC-D1122WR / Resolution Resolution Resolution DC-D1123R / DC-D1123VR / DC-D1123WR / DC- DC-D1011 / D1123WHR / DC-D1212R / DC-D1122R / DC-D1223R DC-D1022W / 704x480 704x480 DC-D1022WR DC-D1111 / DC-D1223VR / DC-D1223WR / DC-D1223WHR only...
  • Page 36 Part 3 - Remote Setup • Compression: Choose the streaming compression • Multi-View Streaming: Designate a specific area of method. the screen and stream images from that area only. (not applicable to the primary stream) Click Setup to • Resolution: Choose a resolution setting for video designate a streaming area.

  • Page 37: Webcasting

    Part 3 - Remote Setup Webcasting Select the MAT option to use the MAT (Motion Adaptive Use the webcasting service to view live images from the camera on a web site. Transmission) feature during video transmission and recording. • HTML Code: Copy and paste the html code shown on •...

  • Page 38: Privacy Masking

    Part 3 - Remote Setup Audio Privacy Masking TYPE 1 Select Privacy Masking to set up a privacy mask over Configure audio in/out settings. a specific area. The section on which a privacy mask is applied will appear as black when monitoring video. •...

  • Page 39: Event Action

    Part 3 - Remote Setup Event Action Alarm-out TYPE 1 Designate event detection alert actions. Select Alarm Out to enable alarm out. TYPE 1 • Dwell Time: Designate the alarm out duration. When an event occurs, alarm out will be generated for the TYPE 2 specified duration.

  • Page 40: Email

    Select Email to send out emails. Select Remote Callback to send callback messages to a remote system. • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature.

  • Page 41: Audio Alarm Type 1

    Part 3 - Remote Setup Audio Alarm FTP Upload TYPE 1 Select FTP Upload to upload .jpg image of the event Select Audio Alarm to generate audio. detected to an FTP server. • List: Displays a list of audio files to playback. Click •...

  • Page 42: Type 1

    Part 3 - Remote Setup • Settings: Configure image and upload settings. Record - Upload Type: Choose an upload type. Select TYPE 1 Always to upload images using the settings below, Select Record to record video on the SD card. First, irrespective of event detection.
  • Page 43 Part 3 - Remote Setup Schedule Settings Select the Schedule tab and set up a recording Select the Settings tab and configure recording schedule. settings. • Mode: Choose a recording mode. - Always - Event: Records video in event mode. In event recording mode, video is recorded when an event is detected.

  • Page 44: Event

    • Recordings saved on the SD card can be searched TYPE 2 and played back from the IDIS Solution Suite Compact program or remotely from the remote program. For more information, refer to each program's operation manual.

  • Page 45: Alarm In Type.

    • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature.

  • Page 46: Motion Detection

    • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature.

  • Page 47: Trip-Zone

    • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature.

  • Page 48: Audio Detection Type 1

    • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature.

  • Page 49: Tampering

    • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature.

  • Page 50: System Event

    • Email and Remote Callback settings under Event Action must be configured correctly in order to send out emails and messages. • Remote Callback is not supported on IDIS Web. • The camera must be registered to the remote TYPE 2 system in order to use the Remote Callback feature.

  • Page 51: Part 4 - Idis Web

    – Tools → Internet Options → Advanced → Security → Use TLS 1.0 (select) • If connecting by entering an IP address and a port number, you can connect by entering just the IP address if IDIS Web connection port number has been set to 80 (443 when entering https).
  • Page 52 • If running IDIS Web on Internet Explorer 7.0, the bottom section of the screen may get cut off if the address bar or the status bar is shown. In this case, change Internet Options so that the address bar or the status bar is hidden. (Tools →...

  • Page 53: Web Live Mode

    2013-05-29 16:25:22 Press to terminate IDIS Web. Place the mouse pointer on the logo to check IDIS Web's version. TYPE 1 Displays the current time. Click to view the video in full screen. Press the ESC key on the keyboard to return to the previous screen.
  • Page 54 Part 4 - IDIS Web Used to control a PTZ camera at a remote location. May not be supported depending on the model. Used to adjust live video quality. Click to control the alarm out device connected to the camera.

  • Page 55: Web Search Mode

    & Press to terminate IDIS Web. Place the mouse pointer on the logo to check IDIS Web's version. TYPE 1 Displays time information of the video recording from the remote locale. Click to view the video in full screen. Press the ESC key on the keyboard to return to the previous screen.
  • Page 56 Part 4 - IDIS Web Indicates the camera's number. Zoom in or out on the video. Adjust image brightness. Apply image filters (Sharpen, Blur, Equalizer, Interpolation, and Revert) to the images. Image calibration is applied only during the paused state.

  • Page 57: Part 5 - Appendix

    Part 5 - Appendix Setup Menu Tree (Remote Setup) TYPE 1 TYPE 2 Remote Setup Remote Setup Quick Setup Quick Setup System System Network Network Video Video System Audio System General Date/Time General User/Group Date/Time Network User/Group Network IP Address IP Address Port/QoS Bandwidth Control...

  • Page 58: Troubleshooting

    ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 6.0 or below.

  • Page 59: Specifications

    DC-D1223 / DC-D1223R / DC-D1223V / DC-D1223VR / DC-D1223W / DC-D1223WR / Variable Focus Automatic Iris Lens: F1.2 DC-D1223WHR DC-D1011 / DC-D1111 / DC-D1212R Fixed Focus Lens: F2.0 DC-D1022W / DC-D1022WR / DC-D1122 / Focal Length DC-D1122R / DC-D1122V / DC-D1122VR / DC-D1122W / DC-D1122WR / DC-D1123 / 3.3mm - 12mm...
  • Page 60 0.5 Lux @ F1.6 (30 IRE) DC-D1123W DC-D1223 / DC-D1223V / DC-D1223W 0.5 Lux @ F1.2 (30 IRE) DC-D1011 / DC-D1111 0.5 Lux @ F 2.0 (30 IRE) DC-D1022WR / DC-D1122R / DC-D1122VR / IR LED OFF : 0.5 Lux @ F1.6 (30 IRE) DC-D1122WR / DC-D1123R / DC-D1123VR / IR LED ON : 0 Lux @ F1.6 (30 IRE)
  • Page 61 Signal Format NTSC or PAL (selectable) H.264, M-JPEG (supports 4-stage image Compression Algorithm compression rate) Compression DC-D1011 / DC-D1022W / DC-D1022WR CIF (352x240), 4CIF (704x480) Resolution DC-D1111 / DC-D1122 / DC-D1122V / DC-D1122VR / DC-D1122W / DC-D1122WR CIF (352x240), 4CIF (704x480),...
  • Page 62 Part 5 - Appendix Multi-Stream Primary, Secondary, Tertiary Audio TYPE 1 Compression Algorithm G.726 (16KHz), G.711 μ – Law (8KHz) Video Out** 1 composite, 1 Vp-p Audio In TYPE 1 1 Line In Audio Out TYPE 1 1 Line Out Alarm In TYPE 1 1 TTL, NC/NO programmable, 4.3V (NC) or 0.3V (NO)
  • Page 63 DC-D1123WHR / DC-D1223WHR -20˚C ~ 50˚C (-4˚F ~ 122˚F) Operating Humidity 0% ~ 90% Power Input / DC-D1011 / DC-D1022W / DC-D1022WR / 12V DC, TYPE 1 DC-D1111 / DC-D1122 / DC-D1122R / DC-D1122V PoE(IEEE 802.3af, Class2) / DC-D1122VR / DC-D1122W / DC-D1122WR DC-D1212R PoE(IEEE 802.3af, Class 2)

  • Page 64: Index

    Index ONVIF Protocol Admin/Watch/Recording/Search Ports Quality Bitrate Control Resolution RTSP Port Camera Name Compression Date/Time Time Sync DSCP Use FEN FEN Name Use HTTPS FEN Server User/Group Frame Rate Use UPnP IDIS Web Port IPFiltering Network Bandwidth Limit Ver 1.2...
