Summary of Contents for Idis DC-D4512WERA
- Page 1 Network Camera Installation Manual DC-D4512WERA Powered by...
-
Page 2: Before Reading This Manual
Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product. -
Page 3: Safety Precautions
Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1. -
Page 4: Fcc Compliance Statement
IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements. -
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
• Wide dynamic range compensation (True WDR) for compresses and transmits video over Ethernet. improved video quality in high-contrast situations You can use the IDIS Discovery program to change • Slow shutter support for improved low-lighting video network camera settings or the IDIS Solution Suite... -
Page 7: Accessories
Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. RJ45 moduler jack, RJ45 waterproof rubber ring, RJ45 Network Camera connector protect cover, cable waterproof rubber ring, RJ45 connector back cover Guide Pattern Allen Wrench Quick Guide... -
Page 8: Overview
Part 1 – Introduction Overview • Wall/Ceiling Installation Hole Used to screw the camera in place on a wall or a ceiling. • Top Cover Assembly Guide The top cover rotates on the bottom cover and is tightened. • SD Memory Card Slot Used to insert a micro SD memory card into the camera. -
Page 9: Cable
For more information on network connection setup, Alarm in range is 0V to 5V. In order to detect alarm refer to the IDIS Discovery operation manual. input from an electrical switch, the signal must be higher than 4.3V from an NC switch or less than The table below shows the network cable 0.3V from an NO switch and must last for longer... -
Page 10: Factory Reset
It's also possible to do a factory reset by pressing and releasing the reset button while the camera is turned on or using the IDIS Discovery program from a remote location. A factory reset will reboot the system. For more... -
Page 11: Waterproof Cable Installation
Part 1 – Introduction Waterproof Cable Installation RJ45 waterproof rubber ring RJ45 modular jack RJ45 waterproof rubber ring RJ45 modular jack RJ45 waterproof rubber ring RJ45 connector protect cover RJ45 modular jack cable waterproof rubber ring (The waterproof rubber ring is fastened to the connector protect cover.) Connect the plug terminal to the RJ45 jack. - Page 12 Part 1 – Introduction Installation After the angle adjustment is finished, tighten the front screw to completely attach the main body. • Check the wall or ceiling to see if it needs to be reinforced. The camera may fall off if the wall or ceiling is not strong enough to support its weight.
-
Page 13: Angle Adjustment
Part 1 – Introduction Angle Adjustment Dimension The lens can be rotated along three axes. Ø 121mm Lens Rotation Horizontal Rotation Vertical Rotation • Lens Rotation Used to adjust the lens' rotation angle. Turn the lens rotator clockwise or counterclockwise direction. •... -
Page 14: Part 2 - Camera Connection
Part 2 - Camera Connection Use the camera by connecting to DirectIP® NVR or non DirectIP® NVR, VMS such as IDIS Solution Suite Compact. With DirectIP® NVR-based Layout Audio In Audio Out Alarm Out Power Alarm In Network Camera Monitor Out... -
Page 15: With Non Directip® Nvr-Based Layout
Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP® NVR connection or VMS connection such as IDIS Solution Suite Compact. -
Page 16: Part 3 - Appendix
ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 10 or below. -
Page 17: Specifications
Part 3 - Appendix Specifications These product specifications may change without prior notice. Video Image Sensor 1/2.8" CMOS Max. Resolution 2592 x 1944 (4:3) 2592 x 1456 (16:9) Scanning Mode Progressive Scan Lens type Fixed-focal Focal Length f=2.8mm, F2.0 f=4.3mm, F1.6 Angular Field of View 80°(H), 56.7°(V), 106.9°(D) (4.3mm) 104.8°(H), 76.9°(V), 130°(D) (2.8mm) - Page 18 Part 3 - Appendix * An SD memory card is a consumable product with a finite service life. Prolonged use will damage the card's memory sectors and result in data loss or memory card failure. Test the SD memory card regularly and replace it whenever necessary. * microSD Logo is a trademark of SD-3C, LLC.
- Page 19 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
