- Page 1 RKD-KVM-17-HDDVI 1U LCD Console Drawer Options : - SDI - Audio - DC power User Manual 17” Ultra High Resolution LCD 1920 x 1200 UM-RKD-KVM-17-HDDVI www.kvmswitchtech.com...
- Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
- Page 3 Contents < Part. 1 > RKD-KVM-17-HDDVI Package Content Structure Diagram & Dimension P.1 - 2 Installation P.3 - 5 Connection P.6 - 8 < Part. 2 > Specifications / OSD Product Specifications P.9 - 10 Keyboard / Mouse Specifications P.11 - 13 On-screen Display Operation ( OSD ) P.14 - 15 Picture In Picture ( PIP ) / Picture By Picture ( PBP )
-
Page 4: Before Installation
Before Installation It is very important to mount the equipment in a suitable cabinet or on a stable surface. Make sure the place has good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content. - Page 5 < Part 1 > < 1.1 > Package Content RKD-KVM-17-HDDVI RKD-KVM-17-HDDVI unit X 1 - CX-6 6ft DVI-D console cable X 1 ( Alternative : CB-6 6ft VGA console cable ) - Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the single console models.
- Page 6 < 1.2 > Dimension Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 441.6 x 480 x 44 mm 590 x 823 x 140 mm 15 kg 19 kg RKD-KVM-17- 23.2 x 32.4 x 5.5” 17.4 x 18.9 x 1.73"...
- Page 7 < 1.3 > Installation - How to install Installation Slides RKD-KVM-17-HDDVI UM-RKD-KVM-17-HDDVI www.kvmswitchtech.com...
- Page 8 < 1.3 > Installation - How to install 2 post rack brackets UM-RKD-KVM-17-HDDVI www.kvmswitchtech.com...
- Page 9 < 1.3 > Installation- How to use the drawer RKD-KVM-17-HDDVI Hold the handle and slide out the drawer. Flip up the LCD to a suitable angle. Operate the LCD console drawer. UM-RKD-KVM-17-HDDVI www.kvmswitchtech.com...
- Page 10 < 1.4 > Connection to via KVMCX-6 cable USB Server LCD Console Drawer Power HDMI DVI-D KVMCX-6 DVI-D console cable U S B DVI-D USB server < 1.4 > Connection to via KVMCX-6 cable external KVM LCD Console Drawer Power HDMI DVI-D KVM KVMCX-6 DVI-D console cable...
- Page 11 < 1.4 > Connection to via KVMCB-6 USB Server RKD-KVM-17-HDDVI cable LCD Console Drawer HDMI DVI-D KVM KVMCB-6 VGA console cable US B V G A USB server < 1.4 > Connection to via KVMCB-6 external KVM cable LCD Console Drawer HDMI DVI-D KVM KVMCB-6 VGA console cable...
- Page 12 < 1.4 > Connection to HDMI Device via *HDMI cable * HDMI cable is not provided. The LCD console drawer is hot-pluggable, but components of connected devices, such Caution : as the servers and KVM switch, may not be hot-pluggable. Plugging and unplugging cables while servers and KVM are powered on may cause irreversible damage to the servers, KVM and LCD console drawer.
- Page 13 < Part 2 > < 2.1 > Product Specifications RKD-KVM-17-HDDVI Panel Size ( diagonal ) 17.1-inch Widescreen TFT color LCD Panel Display pixel ( dots x lines ) 1920 x 1200 Brightness ( typ. ) Contrast Ratio ( typ. ) 600:1 Color 16.7 M, 8-bit...
- Page 14 Environmental Operating Temperature 0 to 50°C degree Conditions Humidity 20~90%, non-condensing Storage Temperature -5 to 60°C degree Humidity 5~90%, non-condensing Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random Product ( W x D x H ) Physical 441.6 x 480 x 44 mm Specification 17.4 x 18.9 x 1.73 inch Packing ( W x D x H )
- Page 15 < 2.2 > Standard Keyboard / Mouse Specifications RKD-KVM-17-HDDVI UM-RKD-KVM-17-HDDVI P.11 www.kvmswitchtech.com...
- Page 16 < 2.2 > MAC Keyboard / Mouse Options UM-RKD-KVM-17-HDDVI P.12 www.kvmswitchtech.com...
- Page 17 < 2.2 > SUN Keyboard / Mouse Options RKD-KVM-17-HDDVI c ll Comp os c ll Com o UM-RKD-KVM-17-HDDVI P.13 www.kvmswitchtech.com...
- Page 18 < 2.3 > On-screen Display Operation ( OSD ) Picture Picture mode : Standard / Vivid / Soft / User mode to choose Brightness : Adjust background black level of the screen image Contrast : Adjust the difference between the image background (black level) and the foreground (white level) Hue: Adjust the screen hue value...
- Page 19 < 2.3 > On-screen Display Operation ( OSD ) RKD-KVM-17-HDDVI Auto adjust : Automatically adjust sizes, centers and ne tunes the video signal to eliminate waviness and distortion. Clock : Adjust the clock value Phase : Adjust the phase value H.
- Page 20 < 2.4 > How to Use Picture In Picture ( PIP ) / Picture By Picture ( PBP ) < 2.4.1 > Picture in Picture ( PIP ) UM-RKD-KVM-17-HDDVI P.16 www.kvmswitchtech.com...
- Page 21 RKD-KVM-17-HDDVI < 2.4.2 > Picture By Picture ( PBP ) UM-RKD-KVM-17-HDDVI P.17 www.kvmswitchtech.com...
- Page 22 < Part 3 > < 3.1 > Options : 3G / HD / SD-SDI input Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberView Full HD 1080p and ultra high resolution 1920 x 1200 LCD displays, Austin Hughes provides a SDI input module without using additional space or power and it comes standard with a 2-year warranty.
- Page 23 < 3.2 > Options : RKD-KVM-17-HDDVI UM-RKD-KVM-17-HDDVI P.19 www.kvmswitchtech.com...
- Page 24 < 3.3 > Options : DC Power Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt 9 — 18V 18 — 36V 36 — 75V Input range: Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA 1220 mA...
