T y p i c a l R a c k
T y p i c a l R a c k
I n s t a l l a t i o n
I n s t a l l a t i o n
The MIDAS System will not accept the Comtech EF Data SDM-300A
with Mux, Flex Mux, or the 100-pin J8 I/O connector installed.
IMPORTANT
W o r k s t a t i o n
W o r k s t a t i o n
The user shall construct a workstation to their specification, using the
equipment recommended by Comtech EF Data. Figure 3-1 illustrates a basic

workstation.

Note: Refer to MIDAS Software Installation Guide.
Connect supplied Y-Cable as follows:
1. Connect the supplied-cable base connector to the FASTCOM card.
2. Connect supplied-cable Port 1 connector to the Comtech EF Data supplied
EIA-422 cable from SNM-1001 Modem.
3. Cable Port 2 connector is not connected.
4. Connect 9-pin EIA-232 cable from Controller Server COM 1 port to SNM-1001
M&C port.
5. Connect 9-pin EIA-232 cable from Controller Server COM 2 port to SNM-1002
M&C port.
6. Connect 25-pin pre-programmed dongle to Controller Server 25-pin I/O port.
Rack Installation, Operator's Guide, Rev.1

Typical Rack Installation

3-2
