- Page 1 PROLINE Top-MounT Air CondiTioner 2000/4000 BTu/Hr. INSTRUCTION MANUAL © 2016 Pentair Equipment Protection 87567377 Rev. E P/N 11359799...
-
Page 2: Table Of Contents
50 F (10 C) minimum to 125 F (52 C) maximum. Operation outside this range without prior modification or approval from Pentair Equipment Protection will void the warranty. For applications where the ambient will be below 50 F (10 C), consult the factory. -
Page 3: Design Data
31.19 x 23.61 (792 x 400) 50/60 14.7/13.6 125 (52) 140 (63) R134A 13.0 (1172) 4000 PAC426T85 31.19 x 23.61 (792 x 400) 50/60 8.0/7.5 125 (52) 140 (63) R134A 13.0 (1172) © 2016 Pentair Equipment Protection 87567377 - 3 -... -
Page 4: Receiving The Air Conditioner
Damage evident upon receipt should be noted on the freight bill. Damage should be brought to the attention of the delivering carrier -- NOT to Pentair Equipment Protection -- within 15 days of delivery. Save the carton and packing material and request an inspection. Then file a claim with the delivering carrier. -
Page 5: Power Connection
The thermal overload switch will actuate and stop compressor operation. Blowers will continue to operate, however, and the compressor will restart when it has cooled to within the thermal overload cut−in temperature setting. © 2016 Pentair Equipment Protection 87567377 - 5 -... -
Page 6: Installation Instructions
When lifting the installed air conditioner and PROLINE frame via the lifting eyes, a spreader bar must be used. ® PROLINE * Hardware included with frame. ® ** Hardware included with PROLINE *** Optional hardware. © 2016 Pentair Equipment Protection 87567377 - 6 -... -
Page 7: Maintenance Procedures
• Disconnect all power supplies to the air conditioner before performing any service inside the unit. • Operation of the air conditioner in areas containing airborne caustics or chemicals can rapidly deteriorate filters, condenser coils, blowers and motors, etc. Contact Pentair Equipment Protection for special recommendations. -
Page 8: Filter Cleaning Instructions
The condenser coil is not visible through the filter opening, so protect it with a clean filter. REPLACEMENT FILTERS Replacement air filters are available from Pentair Equipment Protection. Order by air conditioner catalog number and description of filter. Contact Pentair Customer Service. -
Page 9: Components List
Service Cord 52-6035-140 52-6035-143 52-6035-141 52-6035-141 Terminal Block 10-1003-31 10-1003-31 10-1003-31 10-1003-31 Thermal Overload, Compressor 10-1007-45 10-1007-51 Thermostat, SPST, 55-100F 10-1061-16 10-1061-16 10-1061-16 10-1061-16 Transformer, 10 VAC Secondary 10-1006-114 10-1006-114 10-1006-115 10-1006-115 © 2016 Pentair Equipment Protection 87567377 - 9 -... -
Page 10: Warranty
Equipment Protection approval. Pentair Equipment Protection must be notified of a claim in writing not later than fourteen (14) days from the date when Buyer has become aware of such occurrence, or where the defect is such that it may cause damage, immediately, such notice containing a description of how the defect manifests itself. -
Page 11: Limitation Of Liability
B. All returns to Pentair Equipment Protection must be securely packed, using original cartons if possible. All returns must have the RMA number visible on the outside of the carton. Pentair Equipment Protection is not responsible for material damaged in transit. Any refrigerant-bearing Goods must be shipped upright for return. -
Page 12: Pentair Equipment Protection
Pentair Equipment Protection 2100 Ho man Way Minneapolis, MN 55303 USA +1.763.422.2211 +1.763.576.3200 PentairProtect.com © 2016 Pentair Equipment Protection 87567377 Rev. E P/N 11359799...
