FORTECO
ATTUATORE ELETTROMECCANICO 230V IRREVERSIBILE A
I
CREMAGLIERA PER CANCELLI SCORREVOLI FINO A 2200 KG
DI PESO
230V ELECTRO-MECHANICAL IRREVERSIBLE RACK
GB
ACTUATOR FOR SLIDING GATES UP TO 2200 KG
OPERATEUR ELECTROMECANIQUE 230V IRREVERSIBLE A
F
CREMAILLERE POUR PORTAILS COULISSANTS JUSQU'A
2200 KG DE POIDS
MOTOR ELECTROMECANICO 230V IRREVERSIBLES A
E
CREMALLERA PARA PUERTAS CORREDERAS HASTA
2200 KG DE PESO
V2 S.p.A.
Corso Principi di Piemonte, 65/67
12035 RACCONIGI (CN) ITALY
tel. +39 01 72 81 24 11 - fax +39 01 72 84 050
info@gatestore.co.uk - www.remotecontrolgates.co.uk
IL n. 284-1
EDIZ. 04/07/2012
Advertisement
Table of Contents
Related Manuals for V2 FORTECO
Summary of Contents for V2 FORTECO
- Page 1 V2 S.p.A. Corso Principi di Piemonte, 65/67 12035 RACCONIGI (CN) ITALY IL n. 284-1 tel. +39 01 72 81 24 11 - fax +39 01 72 84 050 EDIZ. 04/07/2012 info@gatestore.co.uk - www.remotecontrolgates.co.uk FORTECO ATTUATORE ELETTROMECCANICO 230V IRREVERSIBILE A CREMAGLIERA PER CANCELLI SCORREVOLI FINO A 2200 KG...
-
Page 3: Table Of Contents
INDEX IMPORTANT REMARKS..............................30 CONFORMITY TO REGULATIONS ..........................30 PARTS LIST ..................................31 TECHNICAL SPECIFICATIONS ............................31 INSTALLATION OF THE MOTOR ............................32 MOTOR OVERRIDING SYSTEM ............................34 INSTALLATION LAYOUT ..............................34 DESCRIPTION OF THE CONTROL UNIT ..........................35 INSTALLATION ................................35 POWER SUPPLY ................................35 BLINKER ..................................35 COURTESY LIGHT................................35 PHOTOCELLS ................................36 SAFETY RIBBONS ................................36 STOP ....................................37... -
Page 4: Important Remarks
V2 S.p.A. TEL. (+39) 01 72 81 24 11 www.v2home.com V2 S.p.A. has the right to modify the product without previous notice; it also declines any responsibility to EC DECLARATION OF INCORPORATION FOR... -
Page 5: Parts List
FORTECO FORTECO FORTECO TECHNICAL SPECIFICATIONS 1200-230V 1800-230V 2200-230V Gate maximum weight 1200 Kg 1800 Kg 2200 Kg Power supply 230VAC / 50Hz 230VAC / 50Hz 230VAC / 50Hz Maximum power 600 W 650 W 800 W Idling current 1.9 A... -
Page 6: Installation Of The Motor
6. Unscrew the bolts fixing the base to the clamps and put the motor on the plate POSITIONING OF THE MOTOR To fix FORTECO, follow the instructions below: 7. Insert the 4 grains with their nuts in the proper place. Adjust the 4 grains to make the motor be perfectly levelled 1. - Page 7 MOUNTING THE RACK FIXING OF THE MOTOR Release the motor and turn the gate completely open. Check the following points: Fix all the rack elements to the gate, making sure that they stand 1. the motor must be on a levelled surface and perfectly parallel at the same height than the motor pinion.
-
Page 8: Motor Overriding System
MOTOR OVERRIDING SYSTEM In case of absence of current, the gate can be released by operating on the motor: 1. Open the hatch of the lock J in front of the motor 2. Insert the key K in the lock and turn clockwise to open the hatch of the release on the side 3. -
Page 9: Description Of The Control Unit
UNIT Use the eyelet provided. The digital control unit PD18 is an innovative V2 S.p.A. product that guarantees a safe and reliable automation of sliding gates. The PD18 has been designed to realize a product that meets all kind of requirements, with a highly versatile control unit that satisfies all the necessary requirements for a functional and efficient installation. -
Page 10: Photocells
• Connect receiver output of photocells 1 between terminals P7 and P11 of the control unit and receiver output of photocells In addition, the V2 wireless edge system may be managed (see 2 between terminals P8 and P11 of the control unit. -
Page 11: Stop
STOP For a better safety, you can fit a stop switch that will cause the immediate gate stop when activated. This switch must have a normally close contact that will get open in case of operation. In case the stop switch is operated while the gate is open, the automatic closing function will always be disabled. -
Page 12: External Aerial
Safety ribbons type 1 (fixed). N.C. contact unit allows the connection to V2 optional modules. Safety ribbons type 2 (mobile). N.C. contact Refer to V2 catalogue or to the technical sheets to see which Common (-) optional modules with ADI interface are available for this control unit. - Page 13 PROGRAMMING WHEEL F1 = 10A...
-
Page 14: Control Panel
CONTROL PANEL USE OF THE PROGRAMMING When power is on, the control unit checks that display correctly WHEEL operates by switching on all segments for 1.5 sec. 8.8.8.8. A special configuration menu – accessible and explorable by Firmware version, e.g. Pr I.6, will be viewed in the following 1.5 means of the small wheel on the right side of the display - allows sec. -
Page 15: Loading Of Default Parameters
LOADING OF DEFAULT SELF-LEARNING OF WORKING PARAMETERS TIMES If necessary, it is possible to restore all the parameters to their standard or default value (see table at the end) This menu allows the automatic learning of the times necessary to open and close the gate. During this phase, the control unit memorizes also the forces WARNING: This procedure causes the loss of all the necessary to open and close the gate: these values will be... -
Page 16: Obstacle Sensor Operation
OBSTACLE SENSOR Function menu setup Function menus allow selecting a function from among a group The PD18 control unit has two independent systems allowing of available options. When you enter into a function menu, the detection of whether gate movement is impeded by obstacles. current active option will be viewed;... - Page 17 Opening time The motor will be operated for the setup time in the opening phase; in case there is an obstacle or the end of stroke operates, the control unit can stop the opening phase before the relevant time expires. Partial opening time (pedestrian access) When the control unit receives a Start Pedestrian command, it will open the gate only, for a shorter time.
- Page 18 Gate Direction This menu allows to invert the opening direction of the gate without swapping motor wires and limit switch ones. the gate opens rightwards the gate opens leftwards WARNING: “opening direction of gate” means the direction you see from the inside. Motor power This menu allows adjusting the motor power.
- Page 19 Brake Function When a sliding motor is used with a very heavy gate, because of the inertia, the gate does not block immediately when stopped and its motion can last for another 10 cm, compromising the working of the safety devices. This menu allows enabling the brake function thanks to which it is possible to block immediately the gate after a control or the intervention of a safety device.
- Page 20 Start command during the closing phase This menu allows fixing the control unit conduct in case it receives a Start command during the closing phase. StoP The gate stops and its cycle is considered as finished APEr The gate opens again Select option StoP, to set up the “step-by-step”...
- Page 21 Closing after transit During the automatic operation, the pause count down starts from the set up value each time a photocell operates during the pause. If the photocell operates during the opening time, this time will be immediately stored as pause time. This function allows having a fast closing as soon as transit through the gate is completed, therefore, a time shorter than CH.AU is generally used.
- Page 22 Blinker during pause time Blinker usually operates during the gate motion only; however, if this function is enabled, blinker will be on during the pause time too (gate open with automatic closure activated). Start input function This menu allows selecting input operation modes (see paragraph “Activation inputs”): StAn Start and Pedestrian Start input standard operation,...
- Page 23 Otherwise, it will stand still and the flashing light will stay onfor 5 sec. The whole test cycle lasts less than one second WARNING: V2 suggests to keep activated the test of the photocells in order to grant a higher safety of the system.
- Page 24 Test enabled for conductive rubber safety edges W.L. Wireless edge system test enabled WARNING: V2 suggests to keep activated the test of the photocells in order to grant a higher safety of the system. End of Stroke Inputs PD18 control unit allows connecting magnetic limit switch which are activated by the door motion and showing to the control unit that each door reached its position of complete opening or closing.
- Page 25 Enabling the ADI device This menu makes it possible to enable operation of the device connected to the ADI connector. interface disabled, any signals will be ignored interface enabled PLEASE NOTE: selecting Si and pressing MENU accesses the configuration menu for the device connected to the ADI connector. This menu is managed by the device itself and is different for each device.
-
Page 26: Reading Of Cycle Counter
READING OF CYCLE COUNTER Area 2 is the reading of the number of cycles before the next request for service: its value is rounded down to the hundreds. PD18 control unit counts the completed opening cycles of the gate and, if requested, it shows that service is required after a Area 3 is the setup of this latter counter;... -
Page 27: Operation Defects
Change the end of stroke sensor or the broken wiring. If the error persists send the control unit to V2 S.p.A. for repair. Too long pre-blinking When a Start command is given and the blinker switches on... -
Page 28: Pd18 Function Table
PD18 FUNCTION TABLE MEMO DISPLAY DATA DESCRIPTION DEFAULT DATA t.AP 0.0" ÷ 5.0' Gate opening time 22.5" t.APP 0.0" ÷ t.AP Opening time of pedestrian gate 6.0" t.Ch 0.0" ÷ 5.0' Gate closing time 23.5" t.ChP 0.0" ÷ t.Ch Closing time of pedestrian gate 7.0"... - Page 29 PD18 FUNCTION TABLE MEMO DISPLAY DATA DESCRIPTION DEFAULT DATA Auxiliary channel - Time working 1’00 biSt - Bistable working - Monostable working LP.PA no/Si Flashlight in pause St.rt Operation modes StAn StAn - Start inputs from terminal board are disabled - Standard operation AP.CH - Separated opening and closing commands...
