Battery Case (Optional For Some Versions) - Icom IC-A15 Instruction Manual

D Rapid charging with the BC-121N+AD-106
The optional BC-121N allows up to 6 battery packs to be
simultaneously charged. The following are additionally re-
quired.
• Six AD-106 charger adapters.
• A power adapter (BC-157S) or the DC power cable (OPC-656).
Battery
pack
Power adapter
(User supplied)
IMPORTANT!:
OPC-656 DC power
Ensure the guide tabs
cable (Connect with
on the battery pack are
a DC power supply,
correctly aligned with
13.8 V/at least 7 A)
the guide rails inside
Red line : +
the charger adapter.
Black line : _
Transceiver
Turn OFF power
AD-106 charger
adapters are installed
in each slot.
Tabs
Guide rails
BATTERY PACKS AND CASE
■ Battery case
(optional for some versions)
D Precaution
NEVER incinerate used batteries since internal battery gas
may cause them to rupture.
NEVER expose a detached battery case to water. If the bat-
tery case gets wet, be sure to wipe it dry before using it.
NEVER short the terminals of the battery case. Also, cur-
rent may flow into nearby metal objects, such as a necklace,
etc. Therefore, be careful when carrying with, or placing near
metal objects, carrying in bags and so on.
When installing batteries, make sure they are all the same
brand, type and capacity. Also, do not mix new and old bat-
teries together.
Install conventional alkaline batteries only. Other type of bat-
teries, such as Ni-Cd, Ni-MH, Li-ion, are cannot be used.
Remove the alkaline batteries when leaving the battery case
unused for long time.
Keep battery contacts clean. It's a good idea to occasionally
clean the battery terminals.
Alkaline batteries have a shorter operating time compared
to Li-ion batteries. Also, the operating time differs by brand,
as well as the model type of the alkaline battery being used.
Therefore, it is recommended that you use the Li-ion battery
pack, or take spare alkaline batteries with you when intending
to use the transceiver frequently, or for long periods.
