3x
#
Code
N/A
[E-08]
Power saving function for outdoor unit:
Power consumption control
Only
applicable
for
EHBH/X04+08
"5 Application guidelines" on page 6 for detailed information about
this functionality.
Pwr consumpt. control
#
Code
[A.6.3.1]
[4-08]
Mode:
[A.6.3.2]
[4-09]
Type:
[A.6.3.3]
N/A
Value: Only applicable in case of full
time power limitation mode.
0~50 A, step 1 A (default: 50 A)
[A.6.3.4]
N/A
Value: Only applicable in case of full
time power limitation mode.
0~20 kW, step 0.5 kW (default: 20 kW)
Amp. limits for DI: Only applicable in case of power limitation mode
based on digital inputs and based on current values.
[A.6.3.5.1]
[5-05]
Limit DI1
0~50 A, step 1 A (default: 50 A)
[A.6.3.5.2]
[5-06]
Limit DI2
0~50 A, step 1 A (default: 50 A)
[A.6.3.5.3]
[5-07]
Limit DI3
0~50 A, step 1 A (default: 50 A)
EHBH/X16
Daikin Altherma - Low Temperature Split
4P313776-1 – 2012.05
1 2 3
Description
0 (default): Disabled
1: Enabled
+
EHVH/X04+08.
Description
0 (No limitation)(default): Disabled.
1 (Continuous): Enabled: You can
set one power limitation value (in A
or kW) to which the system power
consumption will be limited for all
the time.
2 (Digital inputs): Enabled: You
can set up to four different power
limitation values (in A or kW) to
which
the
system
consumption will be limited when
the corresponding digital input
asks.
0 (Current): The limitation values
are set in A.
1 (Power)(default): The limitation
values are set in kW.
#
[A.6.3.5.4]
[5-08]
kW limits for DI: Only applicable in case of power limitation mode
based on digital inputs and based on power values.
[A.6.3.6.1]
[5-09]
[A.6.3.6.2]
[5-0A]
[A.6.3.6.3]
[5-0B]
[A.6.3.6.4]
[5-0C]
Priority: Only applicable in case of an optional EKHW*.
[A.6.3.7]
[4-01]
See
Note: power consumption control only based on heater priority is
possible for EHBH/X04+08 and EHVH/X04+08 models, but also for
EHBH/X16CA and EHVH/X16 models. Hereto you can limit the
operation of both electrical heaters (backup heater and booster
heater) by the following setting.
#
[A.6.3.7]
[4-01]
power
8 Configuration
Code
Description
Limit DI4
0~50 A, step 1 A (default: 50 A)
Limit DI1
0~20 kW, step 0.5 kW (default: 20 kW)
Limit DI2
0~20 kW, step 0.5 kW (default: 20 kW)
Limit DI3
0~20 kW, step 0.5 kW (default: 20 kW)
Limit DI4
0~20 kW, step 0.5 kW (default: 20 kW)
0 (None)(default): No heater is
prioritized.
If
consumption control is enabled,
the booster heater will be limited
first.
1 (BSH): The booster heater is
prioritized.
If
consumption control is enabled,
the backup heater (step 1 and/or
step 2) will be limited first, before
the booster heater is limited.
2 (BUH): The backup heater is
prioritized.
If
consumption control is enabled,
the booster heater will be limited
first, before the backup heater is
limited.
Code
Description
0 (None)(default): No heater is
prioritized.
If
consumption control is enabled,
the booster heater will be limited
first.
1 (BSH): The booster heater is
prioritized.
If
consumption control is enabled,
the backup heater (step 1 and/or
step 2) will be limited first, before
the booster heater is limited.
2 (BUH): The backup heater is
prioritized.
If
consumption control is enabled,
the booster heater will be limited
first, before the backup heater is
limited.
the
power
the
power
the
power
the
power
the
power
the
power
Installer reference guide
50
