Leaving water temperature: Additional zone
Only applicable if 2 leaving water temperature zones are present.
# Code
[A.3.1.2.1] N/A LWT setpoint mode:
EHBH/X16
Daikin Altherma - Low Temperature Split
4P313776-1 – 2012.05
Description
Absolute (default)
The desired leaving water
temperature is:
NOT weather-dependent (i.e.
does not depend on the
outdoor ambient temperature)
fixed in time (i.e.,
scheduled)
Weather dep.: The desired leaving
water temperature is:
weather-dependent
depends on the outdoor
ambient temperature)
fixed in time (i.e.,
scheduled)
Abs + scheduled: The desired
leaving water temperature is:
NOT weather-dependent (i.e.,
does NOT depend on the
outdoor ambient temperature)
according a schedule. The
scheduled actions are On or
OFF.
Remark: This value can only
be set in leaving water
temperature control.
WD + scheduled: The desired
leaving water temperature is:
weather-dependent (i.e., does
depend on the outdoor
ambient temperature)
according a schedule. The
scheduled actions are On or
OFF
Remark: This value can only
be set in leaving water
temperature control.
#
[A.3.1.2.3] [0-03]
[0-02]
[0-01]
[0-00]
not
(i.e.
not
8 Configuration
Code Description
Set weather-dependent heating:
T t
[0-01]
[0-00]
[0-03]
T : Target
t
temperature (main)
T : Outdoor temperature
a
[0-03]: Low
temperature. –20°C~5°C (default:
–10°C)
[0-02]: High
temperature. 10°C~20°C (default:
15°C)
[0-01]: Desired
temperature when the outdoor
temperature equals or drops below
the low ambient temperature.
Between minimum and maximum
leaving water temperature (default:
40°C).
Note: This value should be higher
than [0-00] as for low outdoor
temperatures warmer water is
required.
[0-00]: Desired
temperature when the outdoor
temperature equals or rises above
the high ambient temperature.
Between minimum and maximum
leaving water temperature (default:
25°C).
Note: This value should be lower
than [0-01] as for high outdoor
temperatures less warm water is
required.
[0-02]
T a
leaving water
outdoor ambient
outdoor ambient
leaving water
leaving water
